| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
94734595 |
APPLIQUE, Q/PNL UPR (INCLS 2) (GRAY) |
N1 (43) |
2009-2010 |
01 |
| 001 |
94734596 |
APPLIQUE, Q/PNL UPR (INCLS 2) (GRAY) |
N1 (43) |
2009-2010 |
01 |
| 002 |
11562333 |
CLIP, Q/PNL UPR MLDG (PART OF 1) (22 X 16.3 MM) (FITS 8.5X14MM SLOT) |
N155 (43) |
2009-2010 |
12 |
| 003 |
|
NUT, BODY SI RR MLDG |
|
2009-2010 |
|
| 004 |
11609540 |
БОЛТ, HWASH, M6X1X20, 16.15 THD, 17 OD, 8.8, GMW4205, HDR PT. (RKR PNL FRT MLDG)
|
2009-2010 |
02 |
|
| 005 |
|
CAP, RKR PNL MLDG FRT END (PART OF 13) |
|
2009-2010 |
|
| 006 |
94703364 |
BRACKET, RKR PNL MLDG |
N155 (43) |
2009-2010 |
01 |
| 007 |
11570015 |
NUT, RKR PNL RR MLDG |
N155 (43) |
2009-2010 |
04 |
| 008 |
11609540 |
БОЛТ, HWASH, M6X1X20, 16.15 THD, 17 OD, 8.8, GMW4205, HDR PT. (RKR PNL RR MLDG)
|
2009-2010 |
04 |
|
| 009 |
11561329 |
CLIP, RKR PNL RR MLDG (PART OF 10) (NATURAL) (20 X 14 X 15.8) (PLASTIC TREE) (7.831)
| N155 (43) |
2009-2009 |
02 |
|
| 010 |
94723085 |
MOLDING, RKR PNL RR (INCLS 9, 12) (GRAY) |
N155 (43) |
2009-2010 |
01 |
| 010 |
94723086 |
MOLDING, RKR PNL RR (INCLS 9, 12) (GRAY) |
N155 (43) |
2009-2010 |
01 |
| 011 |
11589294 |
RETAINER, RKR PNL RR MLDG (BLACK) (M8.5 W/20.0MM HEAD) (8.133)
| N155 (43) |
2009-2009 |
04 |
|
| 013 |
94734735 |
MOLDING, RKR PNL FRT (INCLS 5, 14-16) (GRAY) |
N155 (43) |
2009-2010 |
01 |
| 013 |
94734736 |
MOLDING, RKR PNL FRT (INCLS 5, 14-16) (GRAY) |
N155 (43) |
2009-2010 |
01 |
| 014 |
25648693 |
CLIP, RKR PNL FRT MLDG (PART OF 13) (GRAY)
| N155 (43) |
2009-2009 |
10 |
|
| 015 |
11569973 |
CLIP, RKR PNL FRT MLDG (PART OF 13) (FITS 9 DIA HOLE.NATURAL COLOR W/BLACK SEALTL: 35MM) (16.742) |
N155 (43) |
2009-2009 |
02 |
| 016 |
11518988 |
CLIP, 20X19.8X2.5, ACETAL COPOLYMER (PART OF 13) (8.950) |
|
2009-2010 |
18 |
| 017 |
11562503 |
NUT, RKR PNL FRT MLDG (M6X1) (7.836) |
N155 (43) |
2009-2009 |
04 |
| 018 |
11508231 |
SCREW, RD CROWNED WA HD, SELF TAP, M4.2X1.41X16, POR (BODY SI RR MLDG)
|
2009-2010 |
08 |
|
| 019 |
11508231 |
SCREW, RD CROWNED WA HD, SELF TAP, M4.2X1.41X16, POR (W/S SI R/MLDG)
|
2009-2010 |
04 |
|
| 020 |
24300074 |
MOLDING, W/S SI RVL |
N1 (RHD, UVF) (EXPORT) |
2009-2010 |
01 |
| 020 |
24300075 |
MOLDING, W/S SI RVL |
N1 (UVF) (EXC RHD) |
2009-2010 |
01 |
| 021 |
11569711 |
NUT, PUSH-IN, M4.2X1.41, 0.7-2.15 PNL THK, SAE 1050-1065, GMW3359 W/ (W/S SI R/MLDG)
|
2009-2010 |
04 |
|
| 022 |
11609567 |
NUT-INSERT (RIVNUT)M6X1, 9.6 HOLE, 16.25 LEN, 14.65 OD, SAE1008 STL, GMW32 (LUGG CARR S/RL) (8.914) |
|
2009-2010 |
12 |
| 023 |
94723091 |
RAIL, LUGG CARR SI (GRAY) |
N155 (43) |
2009-2010 |
01 |
| 023 |
94723092 |
RAIL, LUGG CARR SI (GRAY) |
N155 (43) |
2009-2010 |
01 |
| 024 |
11518705 |
SCREW, PAN TORX HD, W/WA ; SEAL, M6X1X27, 21 THD, 12.5O.D., 9.8, 6138M (LUGG CARR SI RL) |
|
2009-2010 |
12 |
