| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
94734119 |
LINER, PUBX (GRAY) |
N155 (43) |
2009-2010 |
01 |
| 002 |
94723110 |
RETAINER, PUBX LNR |
N155 (43) |
2009-2010 |
20 |
| 003 |
|
LINER, PUBX (PART OF 5, 6) |
|
2009-2010 |
|
| 004 |
|
LATCH, CARGO BOX CVR (PART OF 5, 6) |
|
2009-2010 |
|
| 005 |
19202229 |
COVER, PUBX (PART OF 6) (INCLS 3, 4) (BLACK) (EMBOSSED H3T LOGO) (17.090) (SERV CMP OF COVER PKG 19165937) |
N1 (43) |
2009-2010 |
01 |
| 005 |
94733864 |
COVER, PUBX (PART OF 6) (INCLS 3, 4) (GRAY) |
N155 (43) |
2009-2010 |
02 |
| 006 |
94734551 |
LINER, PUBX (INCLS 3-5) (GRAY) (LINER PUBX-SIDE) |
N155 (43) |
2009-2010 |
01 |
| 006 |
94734553 |
LINER, PUBX (INCLS 3-5) (GRAY) |
N155 (43) |
2009-2010 |
01 |
| 007 |
94717569 |
БОЛТ, CARGO CARR PUBX TIE DN LOOP |
N155 (43) |
2009-2010 |
04 |
| 008 |
15749157 |
HOOK, CARGO TIE DN (BLACK) (17.090) |
N155 (43) |
2009-2010 |
04 |
| 009 |
11589293 |
RETAINER, PUSH-IN, FITS 8.5 DIA HOLE, 4.5-7 THK PNL, NYLON 6/6 GMP.PA66.0 (FRT BPR FASCIA UPR (PUSH IN))
|
2009-2010 |
02 |
|
| 010 |
11611084 |
БОЛТ, PUBX LNR (M6X1X20.15) |
N155 (43) |
2009-2010 |
04 |
| 011 |
|
BOX, PICK UP (SEE GROUP 17.000 PICKUP BOX/FLEETSIDE FOR DETAILED ILLUSTRATED VIEW) |
|
2009-2010 |
|
| 012 |
11609396 |
БОЛТ, HFH, M12X1.75X61.25, 30.3 THD, CAM POINT, 26.6 O.D., 10.9, 7114M (PUBX) |
|
2009-2010 |
06 |
| 013 |
94723188 |
LINER, PUBX (GRAY) (FRONT) |
N155 (43) |
2009-2010 |
01 |
