| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
12599822 |
COVER, UPR INT MANIF (INCLS 11, 13, 16) |
N1 (06-43) (LH8, JJA) |
2009-2009 |
01 |
| 002 |
12606111 |
COVER, INT MANIF RR (INCLS 4) |
N153 (LH8, JJA) |
2008-2009 |
01 |
| 003 |
11516075 |
ГАЙКА, HFH SELF LK, M6X1, 7.7THK, 14.2 O.D., 9, PZOR (UPR INT MANIF CVR)
|
2008-2010 |
01 |
|
| 004 |
12559065 |
GROMMET, UPR INT MANIF SIGHT SHLD (PART OF 2) (12.0 DIA X 2.4 DEEP) |
N1 (06-43) (LH8, JJA) |
2009-2009 |
01 |
| 005 |
11609908 |
STUD, INT MANIF SIGHT SHLD (M6X1X50.35 W/SHLDR) (3.275) |
N153 (06) (LH8, JJA) |
2008-2009 |
01 |
| 006 |
12621893 |
BRACKET, UPR INT MANIF CVR |
N1 (LH8, JJA) |
2009-2009 |
01 |
| 007 |
11588564 |
БОЛТ, HEX W/FL WA, M8X1.25X25, 15.85 THD, 17 OD, 9.8, GMW3200M, MACH, MAT-PT (UPR INT MANIF CVR BRKT) |
|
2008-2010 |
02 |
| 008 |
15858430 |
RETAINER, UPR INT MANIF SIGHT SHLD (INCLS 10) |
N1 (LH8, JJA) (EXC BRM) |
2008-2009 |
01 |
| 009 |
11514623 |
БОЛТ, HEX W/CON WA, M6X1X20 (UPR INT MANIF SIGHT SHLD) |
|
2008-2010 |
03 |
| 010 |
|
GROMMET, UPR INT MANIF SIGHT SHLD (PART OF 8) |
|
2008-2009 |
|
| 011 |
12591715 |
GROMMET, UPR INT MANIF SIGHT SHLD (PART OF 1) (32MM OD @ TOP) (ROUND AT TOP/TAPERED CONICAL BOTTOM) |
N1 (06-43) (LH8) |
2009-2009 |
02 |
| 012 |
11609530 |
STUD, INT MANIF SIGHT SHLD (M6X1X20) (8.981) |
N1 (LH8, JJA) |
2009-2009 |
01 |
| 013 |
12591714 |
GROMMET, UPR INT MANIF SIGHT SHLD (PART OF 1) (60MM OD @ TOP) (ROUND TOP ; BOTTOM) |
N1 (06-43) (LH8) |
2009-2009 |
01 |
| 014 |
24100002 |
SEAL, OIL FIL CAP (O RING) (PART OF 15) (27.94MM I.D.) (SIZE #320) (1.745)
| N1 (LH8) |
2008-2009 |
01 |
|
| 015 |
12573337 |
CAP, OIL FIL (SAE 5W30, NON-VENTED, SEAL) (INCLS 14) (ACDelco #FC208) |
N1 (LH8) |
2008-2009 |
01 |
| 016 |
25769543 |
EMBLEM, F/END UPR TIE BAR (PART OF 1) (GM PERFORMANCE DIVISION) |
N1 (LH8) |
2008-2009 |
01 |
