| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
21997041 |
DOOR, F/FLR CNSL COMPT (W/A/RST) (INCLS 2, 4-9) (EBONY) |
N1 (YC3, 19I) |
2006-2010 |
01 |
| 001 |
21997042 |
DOOR, F/FLR CNSL COMPT (W/A/RST) (INCLS 2, 4-9) (MOROCCO) |
N1 (YC3) |
2006-2010 |
01 |
| 001 |
21997042 |
DOOR, F/FLR CNSL COMPT (W/A/RST) (INCLS 2, 4-9) (MOROCCO) |
N1 (YC3, 42I) |
2006-2010 |
01 |
| 001 |
21997043 |
DOOR, F/FLR CNSL COMPT (W/A/RST) (INCLS 2, 4-9) (CASHMERE) |
N1 (YC3, 313) |
2006-2010 |
01 |
| 001 |
15111830 |
DOOR, F/FLR CNSL COMPT (W/A/RST) (INCLS 2, 4-9) (EBONY) |
N1 (YC0, 19J, 31J) |
2010-2010 |
01 |
| 002 |
15111834 |
LATCH, F/FLR CNSL COMPT DR (PART OF 1) |
N1 |
2006-2010 |
01 |
| 003 |
15783110 |
LINER, F/FLR CNSL CUP HLDR (PART OF 24) (EBONY) |
N1 |
2006-2010 |
01 |
| 004 |
15683368 |
BUMPER, F/FLR CNSL COMPT DR (PART OF 1) (16MM STEM, 8MM DIA) (CLOSED-STOP) (FRAME) |
N1 |
2006-2010 |
02 |
| 004 |
10446032 |
BUMPER, F/FLR CNSL COMPT DR (PART OF 1) (8.80 DIA) (CLOSED-STOP) (FRAME) (10.263) |
N1 |
2006-2010 |
02 |
| 005 |
11609539 |
SCREW, RD CROWNED WA HD, M4.2X1.41X16, STL ISO 2702, GMW4205 (PART OF 1) |
|
2006-2010 |
04 |
| 006 |
11517228 |
NUT, PANEL, M4.2X1.41, 8.5X11.9, 2.3-2.8 THICK PNL, FITS 11.2X9.2 HOLE 1050, 4250M (PART OF 1) |
|
2006-2010 |
03 |
| 007 |
|
PLATE, F/FLR CNSL COMPT DR ANC (PART OF 1) |
|
2009-2010 |
|
| 008 |
11609539 |
SCREW, RD CROWNED WA HD, M4.2X1.41X16, STL ISO 2702, GMW4205 (PART OF 1, 14) |
|
2006-2010 |
06 |
| 009 |
15174863 |
HINGE, F/FLR CNSL COMPT DR (PART OF 1) |
N1 |
2006-2010 |
01 |
| 010 |
25814236 |
TRAY, F/FLR CNSL STOW (PART OF 14) (EBONY) |
N1 (YC3, 193, 313) |
2010-2010 |
01 |
| 010 |
25814236 |
TRAY, F/FLR CNSL STOW (PART OF 14) (EBONY) |
N1 (YC0, 19J, 31J) (EXC RHD) |
2010-2010 |
01 |
| 011 |
11609539 |
SCREW, RD CROWNED WA HD, M4.2X1.41X16, STL ISO 2702, GMW4205 (PART OF 14) |
|
2006-2010 |
12 |
| 012 |
11517228 |
NUT, PANEL, M4.2X1.41, 8.5X11.9, 2.3-2.8 THICK PNL, FITS 11.2X9.2 HOLE 1050, 4250M (PART OF 14) |
|
2006-2010 |
15 |
| 013 |
25815274 |
LINER, F/FLR CNSL STOR TRAY (PART OF 14) |
N1 (YC0, YC3, 19I, 31I, 42I) |
2010-2010 |
01 |
| 014 |
25814234 |
CONSOLE, F/FLR (INCLS 8, 10-13, 15, 16, 20, 23) (EBONY) |
N1 (19I) (EXC RHD) |
2007-2010 |
01 |
| 014 |
25814234 |
CONSOLE, F/FLR (INCLS 8, 10-13, 15, 16, 20, 23) (EBONY) |
N1 (19I, 42I) (EXC RHD) |
2007-2010 |
01 |
| 014 |
25814235 |
CONSOLE, F/FLR (INCLS 8, 10-13, 15, 16, 20, 23) (CASHMERE) |
N153 (06) (YC3, 313) (EXC RHD) |
2007-2010 |
01 |
| 014 |
25815273 |
CONSOLE, F/FLR (INCLS 8, 10-13, 15, 16, 20, 23) (NO FINISH) |
N1 (YC0, 19J, 31J) (EXC RHD) |
2010-2010 |
01 |
| 015 |
|
BRACKET, F/FLR CNSL RR (PART OF 14) |
|
2009-2010 |
|
| 016 |
11609509 |
SCREW, LG RD WA HD, C/R, HI-LO, 4.2X1.41X13, 11.35-OD, B PT, 6010, GMW4205 (PART OF 14) |
|
2006-2010 |
05 |
| 017 |
11519940 |
BOLT, HEX W/CON WA, M12X1.75X34.5, 28 OD, 6202M, 4345M, TAP, TR-PT (D/SEAT) |
|
2006-2010 |
04 |
| 017 |
11519940 |
BOLT, HEX W/CON WA, M12X1.75X34.5, 28 OD, 6202M, 4345M, TAP, TR-PT (P/SEAT) |
|
2006-2010 |
04 |
| 018 |
15124901 |
BRACKET, F/FLR CNSL FRT |
N1 |
2006-2010 |
01 |
| 019 |
11609411 |
NUT, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (F/FLR CNSL SUPT FRT BRKT) |
|
2006-2010 |
02 |
| 020 |
15274608 |
CLIP, F/FLR CNSL (PART OF 14) (22 X 13 MM) (PUSH NUT) |
N1 |
2006-2010 |
02 |
| 021 |
11609411 |
NUT, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (F/FLR CNSL BRKT) |
|
2006-2010 |
01 |
| 022 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 24) |
|
2006-2010 |
06 |
| 023 |
11589012 |
BOLT, HWH, M4.2X1.41X25, 16.4 THD, 12.5 OD, GM6010M STL, GMW4205 (PART OF 14) (9.665) |
|
2006-2010 |
02 |
| 024 |
25795885 |
PLATE, F/FLR PNL (INCLS 3, 22) |
N1 (M30, MD8) (EXC RHD) |
2010-2010 |
01 |
| 025 |
15818699 |
HANDLE, A/TRNS CONT LVR (INCLS 26) |
N1 (EXC RHD) |
2007-2010 |
01 |
| 026 |
11589266 |
BOLT, A/TRNS CONT LVR KNOB (PART OF 25) |
N1 (MD8, M30) |
2010-2010 |
01 |
