| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
94740337 |
HARNESS, BODY WRG |
N155 (43) (AG1, UQ3, UVC, YC0) |
2010-2010 |
01 |
| 001 |
94740337 |
HARNESS, BODY WRG |
N155 (43) (AG1, UQ3, YC0) (EXC UVC) |
2010-2010 |
01 |
| 001 |
94740339 |
HARNESS, BODY WRG |
N155 (43) (UQ3, UVC, YC0) (EXC AG1) |
2010-2010 |
01 |
| 001 |
94740339 |
HARNESS, BODY WRG |
N155 (43) (UQ3, YC0) (EXC AG1, UVC) |
2010-2010 |
01 |
| 001 |
94740340 |
HARNESS, BODY WRG |
N155 (43) (AG1, UQA, UVC, YC0) |
2010-2010 |
01 |
| 001 |
94740340 |
HARNESS, BODY WRG |
N155 (43) (AG1, UQA, YC0) (EXC UVC) |
2010-2010 |
01 |
| 001 |
94740342 |
HARNESS, BODY WRG |
N155 (43) (UQA, UVC, YC0) (EXC AG1) |
2010-2010 |
01 |
| 001 |
94740342 |
HARNESS, BODY WRG |
N155 (43) (UQA, YC0) (EXC AG1, UVC) |
2010-2010 |
01 |
| 001 |
94740345 |
HARNESS, BODY WRG |
N155 (43) (KA1, UQA, UVC, YC3) |
2010-2010 |
01 |
| 001 |
94740345 |
HARNESS, BODY WRG |
N155 (43) (KA1, UQA, YC3) (EXC UVC) |
2010-2010 |
01 |
| 002 |
10375330 |
COVER, R/WDO DEFG WRG HARN CONN (FOR RR DEFOG CONNECTOR) |
N155 (43) |
2009-2010 |
02 |
| 003 |
11588337 |
BOLT, HEX W/FL WA, M6X1X20, 9 THD, 17 OD, 6202M, GMW3200, TAP, DOG PT. (BODY WRG HARN GND) |
|
2009-2010 |
02 |
| 004 |
|
HARNESS, I/P WRG (SEE GROUP 02.000 WIRING HARNESS/INSTRUMENT PANEL FOR DETAILED ILLUSTRATED VIEW) |
|
2009-2010 |
|
| 005 |
11609989 |
BOLT, HEX W/FLAT WASHER, M6X1X25, 15 THD, 17 OD, 6202M STL, GMW3200, TAPTITE (BODY WRG HARN GND) |
|
2009-2010 |
02 |
