| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 005 |
12498487 |
LAMP, OFF ROAD (INCLS 1-4, 6-11, 13-16) (CLEAR) (INSTALL 1.5) (CVR W/HUMMER LOGO) (GRAY HSG) (INCLS LIGHTBAR) (9005 BULB 60W) (2.575) |
N153 (UNJ) |
2007-2010 |
01 |
| 006 |
|
COVER, LIGHT BAR FSTN (PART OF 5) |
|
2009-2010 |
|
| 007 |
|
BOLT, LIGHT BAR MTG (PART OF 5) |
|
2009-2010 |
|
| 008 |
|
NUT, OFF ROAD LP MTG (PART OF 5) |
|
2009-2010 |
|
| 009 |
|
HARNESS, OFF ROAD (PART 0F 5) |
|
2009-2010 |
|
| 010 |
|
RETAINER, OFF ROAD LP RELAY (PART OF 5) |
|
2009-2010 |
|
| 011 |
88861352 |
FUSE, 20A, MINI, YELLOW (PART OF 5) (ACDelco #ATM20) |
|
2007-2010 |
01 |
| 012 |
|
BLOCK, FUSE (SEE GROUP 02.000 BLOCK/UNDERHOOD BEC FOR DETAILED ILLUSTRATED VIEW) |
|
2007-2010 |
|
| 013 |
19168446 |
SPLICE SLEEVE KIT, (SEALED) (SALMON) (20-18 GA) (PART OF 5) (ACDelco #19168446) |
|
2007-2010 |
AR |
| 014 |
|
HARNESS, OFF ROAD SWITCH (PART 0F 5) |
|
2009-2010 |
|
| 015 |
88963884 |
SWITCH, OFF ROAD LP (PART OF 5) (2.575) |
N1 (BRM, UNJ) (EXPORT) |
2007-2010 |
AR |
| 016 |
19131226 |
WRENCH, ADJMT (PART OF 5) (8.821) (SERV CMP OF PKG 12498487, 19132765, 19159112, 19159110, 19171860) |
N1 |
2007-2010 |
AR |
| 001 |
|
COVER KIT, OFF ROAD LP (PART OF 5) |
|
2009-2010 |
|
| 002 |
|
LAMP ASM, OFF ROAD (PART OF 5) |
|
2009-2010 |
|
| 003 |
|
BULB, OFF ROAD LP (PART OF 5) |
|
2010-2010 |
|
| 004 |
12355066 |
STRAP, PLASTIC ADJ TIE (215MM LG) (PART OF 5) (8.965) (ACDelco #16TS825) |
|
2007-2010 |
AR |
| 005 |
12498487 |
LAMP, OFF ROAD (INCLS 1-4, 6-11, 13-16) (CLEAR) (INSTALL 1.5) (CVR W/HUMMER LOGO) (GRAY HSG) (INCLS LIGHTBAR) (9005 BULB 60W) (2.575) |
N153 (BRN, UNJ) |
2007-2010 |
01 |
