| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
|
HARNESS, BODY WRG (SEE GROUP 02.000 ПРОВОДКА-КУЗОВ FOR DETAILED ILLUSTRATED VIEW) |
|
2009-2010 |
|
| 002 |
24300626 |
MIRROR, I/S RR VIEW (INCLS 3)
| N1 (06) (BRM, DF5, UVC) (EXC UE1) (EXPORT) |
2009-2010 |
01 |
|
| 002 |
25814286 |
MIRROR, I/S RR VIEW (INCLS 3) (INCLS SLIDING LCD VIDEO W/GRID DISPLAY)
| N153 (06) (DF5, UVC) (EXC BRM, UE1, UVF) |
2009-2010 |
01 |
|
| 002 |
25814287 |
MIRROR, I/S RR VIEW (INCLS 3) (INCLS SLIDING LCD VIDEO W/GRID DISPLAY)
| N153 (DF5, UE1, UVC) (EXC BRM, UVF) |
2009-2010 |
01 |
|
| 002 |
25958623 |
MIRROR, I/S RR VIEW (INCLS 3) |
N155 (43) (DF5, UVC) (EXC UE1, UVF) |
2009-2010 |
01 |
| 002 |
94725971 |
MIRROR, I/S RR VIEW (INCLS 3) |
N155 (43) (DF5, UE1, UVC) (EXC UVF) |
2009-2010 |
01 |
| 003 |
|
БОЛТ, I/S RR VIEW MIR (PART OF 2) |
|
2009-2010 |
|
| 004 |
11514517 |
ГАЙКА, HEX, W/CON SPR WA, M6X1, 5.7THK, 18 O.D., 9, 7111M (I/P CTR LWR BR)
|
2009-2010 |
04 |
|
| 005 |
15806901 |
MODULE, RR VIEW CAMERA IMAGE DISPLAY |
N1 (LH8, LLR, BRM, UVC) (EXPORT) |
2009-2009 |
01 |
| 005 |
15806901 |
MODULE, RR VIEW CAMERA IMAGE DISPLAY |
N153 (06) (UVC) (EXC BRM) |
2009-2009 |
01 |
| 006 |
|
HARNESS, I/P WRG (SEE GROUP 02.000 ЖГУТЫ ПРОВОДОВ-ПАНЕЛЬ ПРИБОРОВ FOR DETAILED ILLUSTRATED VIEW) |
|
2009-2010 |
|
| 007 |
15929217 |
BRACKET, RR VIEW CAMERA IMAGE DISPLAY MDL |
N1 (LH8, LLR, UVC) |
2009-2009 |
01 |
| 008 |
|
HARNESS, CHAS WRG (SEE GROUP 02.000 ЖГУТ ПРОВОДОВ/CHASIS FOR DETAILED ILLUSTRATED VIEW) |
|
2009-2010 |
|
| 009 |
15912158 |
HARNESS, RR LIC PLT LP WRG (SEE GROUP 07.000 БАМПЕР ЗАДНИЙ FOR DETAILED ILLUSTRATED VIEW)
| N153 (06) (BRM) (EXPORT) |
2009-2010 |
01 |
|
| 009 |
25820095 |
HARNESS, RR LIC PLT LP WRG (SEE GROUP 07.000 БАМПЕР ЗАДНИЙ FOR DETAILED ILLUSTRATED VIEW) |
N153 (06) (UVC, Z82) (EXC BRM) |
2009-2009 |
01 |
| 009 |
93356109 |
HARNESS, RR LIC PLT LP WRG (SEE GROUP 07.000 БАМПЕР ЗАДНИЙ FOR DETAILED ILLUSTRATED VIEW) |
N155 (43) (UVC, Z82) |
2009-2010 |
01 |
| 010 |
|
ПАНЕЛЬ, БАМПЕР ЗАДНИЙ IMP (SEE GROUP 07.000 БАМПЕР ЗАДНИЙ FOR DETAILED ILLUSTRATED VIEW) |
|
2009-2010 |
|
| 011 |
15874795 |
COVER, RR VIEW CAMERA
| N153 (06) (UVC, Z82) (EXC BRM) |
2009-2010 |
01 |
|
| 011 |
94730196 |
COVER, RR VIEW CAMERA |
N155 (43) (UVC, Z82) |
2009-2010 |
01 |
| 012 |
|
БОЛТ, RR VIEW CAMERA (PART OF 13) |
|
2009-2010 |
|
| 013 |
15874794 |
CAMERA, RR VIEW (INCLS 12)
| N153 (06) (UVC, Z82) (EXC BRM) |
2009-2009 |
01 |
|
| 014 |
24300672 |
COVER, RR VIEW CAMERA |
N153 (06) (BRM, UVC) (NOT YET AVAILABLE) (EXPORT) |
2009-2010 |
01 |
| 015 |
15173619 |
CAMERA PKG, RR VIEW (INCLS 18, 19) (INCLS SMALL HARNESS)
| N1 (BRM, UVC) (EXPORT) |
2009-2009 |
01 |
|
| 016 |
24300673 |
BRACKET, RR VIEW CAMERA |
N153 (06) (BRM, UVC) (NOT YET AVAILABLE) (EXPORT) |
2009-2010 |
01 |
| 017 |
11609509 |
SCREW, LG RD WA HD, C/R, HI-LO, 4.2X1.41X13, 11.35-OD, B PT, 6010, GMW4205 (RR VIEW CAMERA) |
|
2009-2009 |
03 |
| 018 |
|
БОЛТ, RR VIEW CAMERA (PART OF 15) |
|
2009-2010 |
|
| 019 |
|
CABLE, RR VIEW CAMERA (PART OF 15) |
|
2009-2010 |
|
