| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
94703558 |
PANEL, HDLNG TR (INCLS 2-32) (GRAY) |
N155 (43) (CF5, YC0, YC3, 19I) (EXC UE1) |
2009-2009 |
01 |
| 001 |
94703559 |
PANEL, HDLNG TR (INCLS 2-32) (CASHMERE) |
N155 (43) (CF5, YC0, YC3, 27I) (EXC UE1) |
2009-2009 |
01 |
| 001 |
94703566 |
PANEL, HDLNG TR (INCLS 2-32) (GRAY) |
N155 (43) (CF5, UE1, YC0, YC3, 19I) (EXC DH6) |
2009-2009 |
01 |
| 001 |
94703567 |
PANEL, HDLNG TR (INCLS 2-32) (CASHMERE) |
N155 (43) (CF5, UE1, YC0, YC3, 27I) (EXC DH6, UG1) |
2009-2009 |
01 |
| 002 |
|
HARNESS, DM LP WRG (PART OF 1) |
|
2009-2010 |
|
| 003 |
15285400 |
SPACER, ASST HDL (PART OF 1) (ASST HNDL SPACER RTNR) (16.346) |
N1 (43) |
2009-2010 |
03 |
| 004 |
15867647 |
RETAINER, ASST HDL (PUSH ON) (PART OF 1) |
N1 |
2009-2010 |
06 |
| 005 |
15281856 |
HANDLE, R/RL RR ASST (PART OF 1) (INCLS 6, 7) (GRAY) |
N155 (43) (YC0, YC3, 19I) |
2009-2009 |
02 |
| 005 |
15296745 |
HANDLE, R/RL RR ASST (PART OF 1) (INCLS 6, 7) (CASHMERE) |
N155 (43) (YC0, YC3, 27I) |
2009-2009 |
02 |
| 006 |
11518944 |
SCREW, PAN HD, M6X1X25, 20.9 THD, 11 OD, 8.8, GMW3359, 6 LOBED T-30 M-POINT (PART OF 1, 5) (8.913) |
|
2009-2010 |
04 |
| 007 |
|
COVER, R/RL RR ASST HDL HOLE (PART OF 1, 5) |
|
2009-2010 |
|
| 008 |
15281856 |
HANDLE, R/RL FRT ASST (PART OF 1) (INCLS 9, 10) (GRAY) |
N155 (43) (YC0, YC3, 19I) |
2009-2010 |
01 |
| 008 |
15296745 |
HANDLE, R/RL FRT ASST (PART OF 1) (INCLS 9, 10) (CASHMERE) |
N155 (43) (YC0, YC3, 27I) |
2009-2010 |
01 |
| 009 |
11518944 |
SCREW, PAN HD, M6X1X25, 20.9 THD, 11 OD, 8.8, GMW3359, 6 LOBED T-30 M-POINT (PART OF 1, 8) (8.913) |
|
2009-2010 |
02 |
| 010 |
|
COVER, R/RL RR ASST HDL HOLE (PART OF 1, 8) |
|
2009-2010 |
|
| 011 |
15032587 |
HOUSING, DM ; RDG LP (PART OF 1, 14) |
N1 |
2009-2009 |
01 |
| 012 |
15166059 |
SWITCH, DM LP (PART OF 1, 14) (EBONY) |
N1 |
2009-2010 |
02 |
| 013 |
15166059 |
PUSHBUTTON, RDG LP SW (PART OF 1, 14) (EBONY) |
N1 |
2009-2010 |
02 |
| 014 |
15296734 |
LAMP, DM ; RDG (PART OF 1) (INCLS 11-13, 15, 16) (CASHMERE) |
N1 (27I) |
2009-2010 |
01 |
| 014 |
25965486 |
LAMP, DM ; RDG (PART OF 1) (INCLS 11-13, 15, 16) (GRAY) |
N1 (19I) |
2009-2010 |
01 |
| 015 |
15774270 |
LENS, DM LP (FRONT/READING) (PART OF 1, 14) |
N1 |
2009-2010 |
01 |
| 016 |
12450074 |
BULB, TRADE #578 (PART OF 1, 14) (ACDelco #578)
|
2009-2010 |
06 |
|
| 017 |
15125380 |
RETAINER, HDLNG T/PNL (PART OF 1) (GRAY) (19.2MM X DIA 35.0) (LENGTH FROM BASE TO TIP IS 2.00 CM)
| N155 (43) (DH6, UG1, YC0, YC3, 19I) |
2009-2009 |
02 |
|
| 017 |
15297259 |
RETAINER, HDLNG T/PNL (PART OF 1) (CASHMERE) (19.2MM X DIA 35.0) |
N155 (43) (YC0, YC3, 27I) (EXC BRM) |
2009-2009 |
02 |
| 018 |
15272047 |
SUPPORT, S/S (PART OF 1) (GRAY) |
N155 (43) (YC0, YC3, 19I) |
2009-2010 |
02 |
| 018 |
15296740 |
SUPPORT, S/S (PART OF 1) (CASHMERE) |
N155 (43) (YC0, YC3, 27I) |
2009-2010 |
02 |
| 019 |
11610271 |
SCREW, PAN HD, M4.2X1.41X25, 20.5 THD, 8 OD, 6010M, GMW4205, T15 TORX, AB-PT (PART OF 1) |
|
2009-2010 |
06 |
| 020 |
15818454 |
SWITCH, SUN RF (PART OF 1) (EBONY) |
N1 (CF5, 19I) |
2009-2010 |
01 |
| 020 |
15818457 |
SWITCH, SUN RF (PART OF 1) (CASHMERE) |
N1 (CF5, 27I) |
2009-2010 |
01 |
| 021 |
20826753 |
BEZEL, SUN RF SW (PART OF 1) (GRAY) |
N155 (43) (19I) |
2009-2010 |
01 |
| 021 |
20826754 |
BEZEL, SUN RF SW (PART OF 1) (CASHMERE) |
N155 (43) (27I) |
2009-2010 |
01 |
| 021 |
25972843 |
BEZEL, SUN RF SW (PART OF 1) (GRAY) |
N1 (CF5, 19I) |
2009-2010 |
01 |
| 021 |
25972844 |
BEZEL, SUN RF SW (PART OF 1) (CASHMERE) |
N1 (CF5, 27I) |
2009-2010 |
01 |
| 022 |
15264477 |
MICROPHONE, MOBILE TEL (PART OF 1) (GRAY) |
N1 (19I) |
2009-2010 |
01 |
| 022 |
15781014 |
MICROPHONE, MOBILE TEL (PART OF 1) (CASHMERE) |
N1 (27I) |
2009-2010 |
01 |
| 023 |
15296747 |
BEZEL, MOBILE TEL MIC (PART OF 1) (CASHMERE) |
N1 (UE1, YC0, YC3, 27I) |
2009-2010 |
01 |
| 023 |
22666403 |
BEZEL, MOBILE TEL MIC (PART OF 1) (GRAY) |
N1 (UE1, YC0, YC3, 19I) |
2009-2010 |
01 |
| 024 |
12503323 |
LENS, S/S ILLUM MIR LP (PART OF 1, 26) (LEFT SIDE OF MIRROR) (10.195) |
N1 |
2009-2010 |
02 |
| 025 |
09442395 |
BULB, TRADE # 7065 (PART OF 1, 26) (ACDelco #L7065) |
|
2009-2010 |
04 |
| 026 |
15296723 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (PART OF 1) (INCLS 24, 25, 27) (GRAY) |
N155 (43) (DH6, YC0, 19I) |
2009-2010 |
01 |
| 026 |
15296724 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (PART OF 1) (INCLS 24, 25, 27) (CASHMERE) |
N155 (43) (DH6, YC0, YC3, 27I) |
2009-2010 |
01 |
| 026 |
15296725 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (PART OF 1) (INCLS 24, 25, 27) (GRAY) |
N155 (43) (DH6, YC0, YC3, 19I) |
2009-2010 |
01 |
| 026 |
15296726 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (PART OF 1) (INCLS 24, 25, 27) (CASHMERE) |
N155 (43) (DH6, UG1, YC0, YC3, 27I) |
2009-2010 |
01 |
| 026 |
15296729 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (PART OF 1) (INCLS 24, 25, 27) (GRAY) |
N155 (43) (YC0, YC3, 19I) (EXC DH6, UG1) |
2009-2010 |
01 |
| 026 |
15296730 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (PART OF 1) (INCLS 24, 25, 27) (CASHMERE) |
N155 (43) (YC0, YC3, 27I) (EXC DH6, UG1) |
2009-2010 |
01 |
| 026 |
15833741 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (PART OF 1) (INCLS 24, 25, 27) (GRAY) |
N155 (43) (YC0, YC3, 19I) (EXC DH6, UG1) |
2009-2010 |
01 |
| 026 |
15833742 |
СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК, (PART OF 1) (INCLS 24, 25, 27) (CASHMERE) |
N155 (43) (YC0, YC3, 27I) (EXC DH6, UG1) |
2009-2010 |
01 |
| 027 |
15006352 |
LABEL, INFL RST SYS WRNG (PART OF 1, 26) (ENGLISH/FRENCH) |
N1 |
2009-2010 |
02 |
| 027 |
15116388 |
LABEL, INFL RST SYS WRNG (PART OF 1, 26) (ENGLISH/SPANISH)
| N1 |
2009-2010 |
02 |
|
| 027 |
15815407 |
LABEL, INFL RST SYS WRNG (PART OF 1, 26) (ENGLISH/ARABIC) |
N1 (VBX) (EXPORT) |
2009-2010 |
02 |
| 028 |
11610271 |
SCREW, PAN HD, M4.2X1.41X25, 20.5 THD, 8 OD, 6010M, GMW4205, T15 TORX, AB-PT (PART OF 1) |
|
2009-2010 |
06 |
| 029 |
11609314 |
NUT, S/S SUPT (PART OF 1) (4.2 X 1.41) (12.8 HOLE) |
N155 (43) |
2009-2009 |
08 |
| 030 |
|
SPACER, S/S (PART OF 1) |
|
2009-2010 |
|
| 031 |
|
WIRE, SUN RF SW (PART OF 1) |
|
2009-2010 |
|
| 032 |
15296732 |
CLIP, S/S SUPT (PART OF 1) |
N155 (43) |
2009-2009 |
02 |
