| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25882410 |
MODULE, RF S/RL INFL RST (INCLS 2) |
N153 (06) (ASF) |
2006-2010 |
01 |
| 001 |
25882411 |
MODULE, RF S/RL INFL RST (INCLS 2) |
N153 (06) (ASF) |
2006-2010 |
01 |
| 002 |
|
БОЛТ, RF S/RL INFL RST MDL (PART OF 1) |
|
2009-2010 |
|
| 003 |
15850867 |
MODULE, I/P INFL RST (EBONY) |
N1 (RHD, 19I) (EXC HH3) (EXPORT) |
2007-2010 |
01 |
| 003 |
15850867 |
MODULE, I/P INFL RST (EBONY) |
N1 (RHD, 27I) (EXC HH3) (EXPORT) |
2008-2010 |
01 |
| 003 |
25809845 |
MODULE, I/P INFL RST (EBONY) |
N1 (19I, 27I) |
2006-2010 |
01 |
| 004 |
11519502 |
NUT, TYPE U, M6X1, 23.5X12.5, 13.5 C/E, 0.8-4.0 PNL, GM7111M (INFL RST RF S/RL MDL AIRBAG STRP) |
|
2006-2010 |
12 |
| 005 |
|
HARNESS, BODY WRG (SEE GROUP 13.000 ПРОВОДКА-КУЗОВ FOR DETAILED ILLUSTRATED VIEW) (2.525) |
|
2006-2010 |
|
| 006 |
03530297 |
ГАЙКА, HFH, M6X1, 5.85THK, 14.2 O.D., 10, ZOR (INFL RST VEH ROLLOVER SEN) |
|
2006-2010 |
03 |
| 007 |
25809367 |
ДАТЧИК, INFL RST VEH ROLLOVER (LABELED 25809367)
| N153 (06) (ASF) |
2006-2010 |
01 |
|
| 007 |
25973140 |
ДАТЧИК, INFL RST VEH ROLLOVER (LABELED 25973140) |
N153 (06) (ASF) |
2006-2010 |
01 |
| 008 |
03530297 |
ГАЙКА, HFH, M6X1, 5.85THK, 14.2 O.D., 10, ZOR (INFL RST SEN ; DIAGN MDL) |
|
2006-2010 |
03 |
| 009 |
24300601 |
MODULE, INFL RST SEN ; DIAGN (USE ON VEHICLES BUILT WITH 24300601) (FOR 2ND DES SEE 24300984) |
N153 (06) (BRM) (EXC ASF) (1ST DES) (EXPORT) |
2009-2009 |
01 |
| 009 |
24300984 |
MODULE, INFL RST SEN ; DIAGN (USE ON VEHICLES BUILT WITH 24300984) (FOR 1ST DES SEE 24300601) |
N153 (06) (BRM) (EXC ASF) (2ND DES) (EXPORT) |
2009-2009 |
01 |
| 009 |
24300985 |
MODULE, INFL RST SEN ; DIAGN (LABELED 24300985) |
N153 (06) (ASF, TUM) |
2009-2009 |
01 |
| 009 |
25846739 |
MODULE, INFL RST SEN ; DIAGN (LABELED 25846739) |
N153 (06) (ASF, TUM) |
2009-2009 |
01 |
| 009 |
25984299 |
MODULE, INFL RST SEN ; DIAGN
| N153 (06) (ASF) (EXC TUM) |
2009-2010 |
01 |
|
| 010 |
25809839 |
MODULE, STRG WHL INFL RST (EBONY) (INCLS СИГНАЛ CONTACTS) (16.712) |
N1 (19I, 27I) (EXC Y92) |
2008-2010 |
01 |
| 010 |
25809839 |
MODULE, STRG WHL INFL RST (EBONY) (INCLS СИГНАЛ CONTACTS) |
N1 (19I, 27I) (EXC Y92) |
2008-2010 |
01 |
| 010 |
25809843 |
MODULE, STRG WHL INFL RST (EBONY) (16.712) |
N1 (Y92, 19I, 27I) |
2008-2010 |
01 |
| 010 |
25809843 |
MODULE, STRG WHL INFL RST (EBONY) |
N1 (Y92, 19I, 27I) |
2008-2010 |
01 |
| 011 |
11517484 |
BOLT-HEX, M6X1X20, 9 THD, 17 OD, 9.8, 6280M, MACH, P-PT (I/P INFL RST MDL) |
|
2006-2010 |
02 |
| 012 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (COMMUNICATION INTERFACE MDL)
|
2006-2010 |
02 |
|
| 013 |
|
HARNESS, I/P WRG (SEE GROUP 02.000 ЖГУТ ПРОВОДОВ, INSTRUMENT PANEL FOR DETAILED ILLUSTRATED VIEW) |
|
2006-2010 |
|
| 014 |
|
HARNESS, FRT S/D DR WRG (SEE GROUP 16.000 DOOR HARDWARE/FRONT FOR DETAILED ILLUSTRATED VIEW) |
|
2006-2010 |
|
| 015 |
10383629 |
ДАТЧИК, INFL RST SI IMP
| N1 (ASF) |
2007-2010 |
02 |
|
| 016 |
|
HARNESS, FWD LP WRG (SEE GROUP 02.000 ЖГУТ ПРОВОДОВ/FWD LAMPS FOR DETAILED ILLUSTRATED VIEW) |
|
2006-2010 |
|
| 017 |
25836760 |
ДАТЧИК, F/END INFL RST DISCRM |
N153 (06) |
2008-2010 |
02 |
