| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
89048534 |
CAP, CLU M/CYL RSVR (PART OF 2) (W/ISO) |
N1 (MA5) |
2008-2010 |
01 |
| 002 |
24249143 |
CYLINDER, CLU MAS (INCLS 1, 3-6)
| N1 (MA5) (EXC RHD) |
2008-2010 |
01 |
|
| 003 |
93221087 |
BUSHING, CLU M/CYL PUSH ROD (PART OF 2) (INCLS RETAINER) |
N1 (MA5) |
2008-2010 |
01 |
| 004 |
|
SEAL, CLU ACTR CYL (O RING) (PART OF 2) |
|
2008-2010 |
|
| 005 |
|
PIPE, CLU ACTR CYL (PART OF 2) |
|
2008-2010 |
|
| 006 |
|
RETAINER, CLU M/CYL RSVR (PUSH IN) (PART OF 2) |
|
2008-2010 |
|
| 007 |
11514596 |
ГАЙКА, HFH, M8X1.25, 17.9 OD, 738 THK, 13MM HEX, 10, ZF (CLU PED BRKT) (8.915) (ACDelco #11514596) |
|
2008-2010 |
04 |
| 008 |
|
ДАТЧИК, CLU PED POSN (PART OF 9) |
|
2008-2010 |
|
| 009 |
15853191 |
PEDAL, CLU (W/BRKT) (INCLS 8, 10, 11) |
N1 (MA5) (EXC RHD) |
2008-2010 |
01 |
| 010 |
15108399 |
PAD, CLU PED (PART OF 9) |
N1 (MA5) |
2008-2010 |
01 |
| 011 |
11609999 |
SCREW, HEX HD FL WA, M4X0.7X20, 13 THD, 12 OD, 9.8, GMW3044, W/NYLON (PART OF 9) |
|
2008-2010 |
01 |
