| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15818699 |
HANDLE, A/TRNS CONT LVR (INCLS 12) |
N1 (M30) (EXC RHD) |
2007-2008 |
01 |
| 001 |
25808539 |
HANDLE, A/TRNS CONT LVR (INCLS 12) |
N1 (M30, RHD) (EXPORT) |
2007-2008 |
01 |
| 002 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (A/TRNS RANGE SEL LVR CBL BRKT)
|
2006-2008 |
04 |
|
| 003 |
15823064 |
CONTROL, A/TRNS (INCLS 13, 14)
| N1 (M30) (EXC RHD) |
2007-2008 |
01 |
|
| 003 |
15823064 |
CONTROL, A/TRNS (INCLS 13, 14) (4.004)
| N1 (M30) (EXC RHD) |
2007-2008 |
01 |
|
| 003 |
25808540 |
CONTROL, A/TRNS (INCLS 13, 14) |
N1 (M30, RHD) (EXPORT) |
2007-2008 |
01 |
| 003 |
25808540 |
CONTROL, A/TRNS (INCLS 13, 14) (4.004) |
N1 (M30, RHD) (EXPORT) |
2007-2008 |
01 |
| 004 |
25800702 |
CABLE, A/TRNS RANGE SEL LVR
| N1 (M30) |
2006-2007 |
01 |
|
| 005 |
10217245 |
RETAINER, A/TRNS RANGE SEL LVR CBL (U-SHAPE)
| N1 (M30) |
2006-2007 |
01 |
|
| 006 |
11514603 |
ГАЙКА, M10X1.5 15MM SOCKET (A/TRNS RANGE SEL LVR EQLZR LVR)
|
2006-2008 |
01 |
|
| 007 |
15082892 |
LEVER, A/TRNS RANGE SEL LVR EQLZR
| N1 (M30) |
2006-2007 |
01 |
|
| 008 |
11509640 |
БОЛТ, HEX W/CON WA, M8X1.25X16, 9.8, PZOR, 17.0-OD, W/DOG PT, TT WASH (PARK/NEU POSN ; B/U LP SW) |
|
2006-2008 |
02 |
| 009 |
24221125 |
SWITCH, PARK/NEU POSN ; B/U LP (12-PIN CONN) (4.054) (ACDelco #D2257C)
| N1 (M30) |
2006-2008 |
01 |
|
| 009 |
24221125 |
SWITCH, PARK/NEU POSN ; B/U LP (12-PIN CONN) (ACDelco #D2257C)
| N1 (M30) |
2006-2008 |
01 |
|
| 010 |
15200802 |
BRACKET, A/TRNS RANGE SEL LVR CBL (ACDelco #15200802) |
N1 (M30) |
2006-2007 |
01 |
| 011 |
11519505 |
BOLT-HEX HD W/CON WA, M8X1.25X22, 18.74 THD, 17OD, 8.8, GMW3359, HDR PT. (A/TRNS RANGE SEL LVR CBL BRKT) |
|
2006-2008 |
02 |
| 012 |
11589266 |
БОЛТ, A/TRNS CONT LVR KNOB (PART OF 1) |
N1 (M30) |
2006-2008 |
01 |
| 013 |
|
БОЛТ, A/TRNS SHFT LK CONT SOL (PART OF 3) |
|
2006-2007 |
|
| 014 |
88967140 |
SOLENOID, A/TRNS SHFT LK CONT (PART OF 3)
| N1 (M30) |
2006-2008 |
01 |
|
