| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15246161 |
MIRROR, I/S RR VIEW (INCLS 2)
| N1 (DF5) (EXC UE1) |
2006-2006 |
01 |
|
| 001 |
15269045 |
MIRROR, I/S RR VIEW (INCLS 2) (LT SEN, COMPASS, O/S TEMP DISPLAY, ONSTAR, ; GPS) |
N1 (DF5, UE1) |
2006-2006 |
01 |
| 001 |
20824386 |
MIRROR, I/S RR VIEW (INCLS 2) |
N1 (06) (DNS, UVC) (EXC UE1) |
2006-2007 |
01 |
| 002 |
|
БОЛТ, I/S RR VIEW MIR (PART OF 1) |
|
2006-2008 |
|
| 003 |
|
BRACKET, I/S RR VIEW MIR MT PLT (PART OF 6) |
|
2006-2008 |
|
| 004 |
|
MOLDING, W/S UPR RVL (PART OF 6) |
|
2006-2008 |
|
| 005 |
12346392 |
ADHESIVE, W/S |
(EXC BRM) |
2006-2008 |
AR |
| 006 |
15298546 |
WINDSHIELD, (INCLS 3, 4) (INCLS UPPER REVEAL MOLDING ; FOAM STRIP) (W/SHADE BAND)
| N1 (06) |
2006-2006 |
01 |
|
| 007 |
15840842 |
PANEL, AIR INL GRL (UPR) (PAINT TO MATCH) (SEE GROUP 16.000 СТЕКЛООЧИСТИТЕЛЬ ВЕТРОВОГО СТЕКЛО FOR DETAILED ILLUSTRATED VIEW) (INCLS 8)
| N1 |
2006-2006 |
01 |
|
| 008 |
11610266 |
CLIP, AIR INL GRL PNL (PART OF 7) (8.950) |
N1 |
2006-2008 |
10 |
| 009 |
15061964 |
SUPPORT, W/S
| N1 |
2006-2008 |
02 |
|
| 010 |
15326410 |
RETAINER, AIR INL GRL PNL (4.75 MM) (PUSH-IN CHRISTMAS TREE TYPE) (14.683)
| N153 (06) |
2006-2008 |
04 |
|
| 011 |
|
PANEL, AIR INL GRL (LWR) (SEE GROUP 16.000 СТЕКЛООЧИСТИТЕЛЬ ВЕТРОВОГО СТЕКЛО FOR DETAILED ILLUSRTATED VIEW) (BLACK) |
|
2006-2008 |
|
| 012 |
|
RIVET, VIN PLT |
|
2006-2008 |
|
| 013 |
|
PLATE, VIN (CONTACT APPROPRIATE AUTHORITY GOVERNING MOTOR VEHICLES FOR REPLACEMENT PROCESS) |
|
2006-2008 |
|
| 014 |
11589262 |
RETAINER, W/S SI R/MLDG
| N1 |
2006-2008 |
06 |
|
| 015 |
11569711 |
NUT, PUSH-IN, M4.2X1.41, 0.7-2.15 PNL THK, SAE 1050-1065, GMW3359 W/ (W/S SI R/MLDG)
|
2006-2008 |
04 |
|
| 016 |
15909801 |
MOLDING, W/S SI RVL (GRAY) |
N153 (06) (EXC RHD) |
2006-2008 |
01 |
| 016 |
15909802 |
MOLDING, W/S SI RVL (GRAY)
| N153 (06) (EXC RHD) |
2006-2008 |
01 |
|
| 017 |
11609539 |
SCREW, RD CROWNED WA HD, M4.2X1.41X16, STL ISO 2702, GMW4205 (W/S SI R/MLDG)
|
2006-2008 |
04 |
|
| 018 |
11519031 |
RETAINER, PUSH IN, 19.5X26.1X1.8, ACETAL, NATURAL, FOAM SEALER (PART OF 19)
|
2006-2008 |
08 |
|
| 019 |
15251222 |
COVER, FRT INT AIR DUCT HOLE (INCLS 18, 20-22) |
N1 (31U) |
2006-2006 |
01 |
| 019 |
15251224 |
COVER, FRT INT AIR DUCT HOLE (INCLS 18, 20-22)
| N1 (43U) |
2006-2006 |
01 |
|
| 019 |
15785155 |
COVER, FRT INT AIR DUCT HOLE (INCLS 18, 20-22) |
N1 (50U) |
2006-2006 |
01 |
| 019 |
19120871 |
COVER, FRT INT AIR DUCT HOLE (INCLS 18, 20-22) (PAINT TO MATCH) |
N1 |
2006-2008 |
01 |
| 020 |
15884135 |
INSULATOR, A/CL HSG CVR (PART OF 19) |
N1 |
2006-2008 |
01 |
| 021 |
15884125 |
SEAL, A/CL (LEFT SIDE/COVER, FRT INT AIR DUCT) (INCLS 22) (PART OF 19) |
N1 |
2006-2008 |
01 |
| 021 |
15884126 |
SEAL, A/CL (RIGHT SIDE/COVER, FRT INT AIR DUCT) (INCLS 22) (PART OF 19) |
N1 |
2006-2008 |
01 |
| 022 |
21121668 |
RETAINER, INT AIR BFL (PUSH IN) (FRT INT AIR DUCT-HOLE) (PART OF 19, 21) (12.804) |
N1 |
2006-2008 |
05 |
