| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15851474 |
HOSE, TRANS FLUID CLR INL
| N153 (06) (M30, JJA) |
2006-2006 |
01 |
|
| 002 |
15226661 |
CONNECTOR, TRANS FLUID CLR PIPE (INCLS 3, 4) (9/16-18) (3/8 BODY QUICK CONNECT) (AT RAD) (ACDelco #15226661) |
N1 (M30) |
2006-2007 |
02 |
| 003 |
24205103 |
RETAINER, TRANS FLUID CLR PIPE FTG (PART OF 2) (EXPANDING SPRING WIRE) (ACDelco #24205103)
| N1 (M30) |
2006-2007 |
02 |
|
| 004 |
|
SEAL, TRANS FLUID CLR PIPE FTG (PART OF 2) |
|
2006-2007 |
|
| 005 |
15196327 |
HOSE, TRANS FLUID CLR OTLT
| N153 (06) (M30, JJA) |
2006-2006 |
01 |
|
| 006 |
15068848 |
CLIP, TRANS FLUID CLR PIPE (HOLDS 2-9.5MM (3/8) DIA PIPES, CLIP TOP) |
N153 (06) (M30, JJA) |
2006-2007 |
01 |
| 007 |
11515755 |
БОЛТ, HEX, M8X1.25X16, 15 THD, 18 O.D., 10.9, 7114M (TRANS FLUID CLR PIPE CLIP) (T/W 12345493 REPLCS 25534835)
|
2006-2010 |
01 |
|
| 008 |
15120863 |
CLIP, TRANS FLUID CLR PIPE (MAX LOAD 25005N/5621LBS) |
N153 (06) (M30, JJA) |
2006-2007 |
01 |
| 009 |
24233366 |
FITTING, TRANS FLUID CLR PIPE (INCLS 10) (INCLS O-RING) (1/4-18 NPS THD) (QUICK CONN, NON BALL CK INCLS RETAINER, TRANS END) (STL BODY) (ACDelco #24233366)
| N1 (M30) |
2006-2007 |
02 |
|
| 010 |
24205103 |
RETAINER, TRANS FLUID CLR PIPE FTG (PART OF 9) (EXPANDING SPRING WIRE) (ACDelco #24205103)
| N1 (M30) |
2006-2007 |
02 |
|
