| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
19151127 |
PANEL, PLNM UPR |
N2 |
2008-2009 |
01 |
| 002 |
11517518 |
БОЛТ, HFH, M6X1X20, 17.9 THD, 14.2 O.D., 9.8, TIN ZN (WSW SYS MDL SUPT) (ACDelco #11517518)
|
2008-2009 |
04 |
|
| 003 |
15073838 |
SUPPORT, WSW SYS MDL |
N2 |
2008-2009 |
01 |
| 004 |
15070067 |
COVER, PLNM UPR PNL OPG |
N2 |
2008-2009 |
01 |
| 005 |
15060931 |
PANEL, PLNM UPR RR |
N2 |
2008-2009 |
01 |
| 006 |
15063612 |
EXTENSION, PLNM UPR PNL |
N2 |
2008-2009 |
01 |
| 006 |
15063613 |
EXTENSION, PLNM UPR PNL |
N2 |
2008-2009 |
01 |
| 007 |
88979787 |
PANEL, PLNM LWR |
N2 |
2008-2009 |
01 |
| 008 |
15061964 |
SUPPORT, W/S
| N2 |
2008-2009 |
02 |
|
| 009 |
11609625 |
STUD, BODY WRG HARN GND (PART OF 20) (M5 X 1.6 X 57.0) (RIVET STYLE) (4.047) |
N257 |
2008-2009 |
01 |
| 010 |
11609625 |
STUD, BODY WRG HARN GND (PART OF 15) (M5 X 1.6 X 57.0) (RIVET STYLE) (4.047) |
N257 |
2008-2009 |
01 |
| 011 |
15079095 |
BRACKET, BRK ; ACCEL PED (INCLS 12) (W/BRKT ; NUT) (TO LWR PLNM PNL) (4.634) |
N257 (JH6) |
2008-2009 |
01 |
| 011 |
15079095 |
BRACKET, BRK ; ACCEL PED (INCLS 12) (W/BRKT ; NUT) (TO LWR PLNM PNL) |
N257 (JH6) |
2008-2009 |
01 |
| 011 |
25863989 |
BRACKET, BRK ; ACCEL PED (INCLS 12) (ПЕДАЛЬ ТОМОЗА) (4.634) |
N2 (JH6) |
2008-2009 |
01 |
| 011 |
25863989 |
BRACKET, BRK ; ACCEL PED (INCLS 12) (ПЕДАЛЬ ТОМОЗА) |
N2 (JH6) |
2008-2009 |
01 |
| 012 |
|
NUT, BRK PED BRKT (PART OF 11) |
|
2008-2009 |
|
| 013 |
25932602 |
PANEL, COWL SI (INCLS 14)
| N2 |
2008-2009 |
01 |
|
| 014 |
15241351 |
BRACKET, INST CARR (PART OF 13) |
N2 |
2008-2009 |
01 |
| 015 |
20807298 |
PANEL, DA (INCLS 10) |
N2 |
2008-2009 |
01 |
| 016 |
15049377 |
SHIELD, EXH HT (AT DA PNL) |
N2 |
2008-2009 |
01 |
| 017 |
10388833 |
SHIELD, EXH HT (AT DA PNL) |
N2 |
2008-2009 |
01 |
| 018 |
88979790 |
PANEL, COWL SI (INCLS 19) |
N2 |
2008-2009 |
01 |
| 019 |
15713180 |
BRACKET, INST CARR (PART OF 18) |
N2 |
2008-2009 |
01 |
| 020 |
88979810 |
PANEL, PLNM FRT (INCLS 9) |
N2 |
2008-2009 |
01 |
| 021 |
15073838 |
SUPPORT, WSW SYS MDL |
N2 |
2008-2009 |
01 |
| 022 |
15122195 |
COVER, COWL S/PNL OPG |
N2 |
2008-2009 |
01 |
| 022 |
15181100 |
COVER, COWL S/PNL OPG |
N2 |
2008-2009 |
01 |
| 023 |
11517518 |
БОЛТ, HFH, M6X1X20, 17.9 THD, 14.2 O.D., 9.8, TIN ZN (WSW SYS MDL) (ACDelco #11517518)
|
2008-2009 |
04 |
|
| 024 |
25809428 |
DEFLECTOR, PLNM LWR PNL WAT (INCLS 25, 26) |
N2 |
2008-2009 |
01 |
| 025 |
|
SEALER, PLNM LWR PNL (PART OF 24) |
|
2008-2009 |
|
| 026 |
15607103 |
RETAINER, PLNM PNL (PART OF 24) (LWR WATER DEFLECTOR) (9.264) |
N2 |
2008-2009 |
04 |
