| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25996496 |
MODULE, RF S/RL INFL RST
| N2 (ASF) |
2008-2009 |
01 |
|
| 001 |
25996497 |
MODULE, RF S/RL INFL RST
| N2 (ASF) |
2008-2009 |
01 |
|
| 002 |
11519502 |
NUT, INFL RST RF S/RL MDL (FRONT) (M6X1, 23.5X12.5, 13.5) (8.921) |
N2 (ASF) |
2008-2009 |
02 |
| 002 |
25640395 |
NUT, INFL RST RF S/RL MDL (TO AIRBAG STRAP) (COPPER) (9.647) |
N2 |
2008-2009 |
01 |
| 003 |
|
HARNESS, RR S/D DR WRG (SEE GROUP 16.000 DOOR HARDWARE/REAR FOR DETAILED ILLUSTRATED VIEW) |
|
2008-2009 |
|
| 004 |
|
HARNESS, BODY WRG (SEE GROUP 02.000 ПРОВОДКА-КУЗОВ FOR DETAILED ILLUSTRATED VIEW) |
|
2008-2009 |
|
| 005 |
25854193 |
ДАТЧИК, INFL RST SI IMP (FRONT) |
N2 (ASF) |
2008-2009 |
02 |
| 006 |
|
HARNESS, FRT S/D DR WRG (SEE GROUP 16.000 DOOR HARDWARE/FRONT FOR DETAILED ILLUSTRATED VIEW) |
|
2008-2009 |
|
| 007 |
10366054 |
MODULE, INFL RST SEN ; DIAGN |
N2 |
2008-2009 |
01 |
| 008 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (INFL RST SEN ; DIAGN MDL)
|
2008-2009 |
03 |
|
| 009 |
03530297 |
ГАЙКА, HFH, M6X1, 5.85THK, 14.2 O.D., 10, ZOR (INFL RST VEH ROLLOVER SEN) |
|
2008-2009 |
03 |
| 010 |
25963388 |
ДАТЧИК, INFL RST VEH ROLLOVER
| N2 (ASF) |
2009-2009 |
01 |
|
| 011 |
25854194 |
MODULE, INFL RST SI IMP SEN (REAR) |
N2 (ASF) |
2008-2009 |
02 |
