| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25956266 |
HEATER, WSWA SOLV (INCLS 3) |
N2 (CHW) |
2009-2009 |
01 |
| 002 |
11570136 |
БОЛТ, HEX HD, W/CON SPR WA, M6X1X23, 14 THD, 17 O.D., 8.8, GMW3359 (R/WDO WA SOLV CNTNR BRKT) |
|
2008-2009 |
01 |
| 003 |
11518121 |
NUT, U, M6X1, MULTI THD, .5-4.0 THK PNL (PART OF 1) |
|
2008-2009 |
01 |
| 004 |
|
CLAMP, DUCT (TO EL) (PART OF 5) |
|
2009-2009 |
|
| 005 |
10359025 |
DUCT, A/CL OTLT (INCLS 4, 6-8) |
N2 (L9H) |
2009-2009 |
01 |
| 006 |
25346092 |
INSULATOR, A/CL RESO (PART OF 5) (3.270) |
N2 (L9H) |
2009-2009 |
01 |
| 007 |
15929826 |
INDICATOR, A/CL AIR RSTN (PART OF 5) |
N2 (L9H) |
2009-2009 |
01 |
| 008 |
25178714 |
GROMMET, A/CL AIR RSTN IND (PART OF 5) |
N2 (L9H) |
2009-2009 |
01 |
| 009 |
11562129 |
БОЛТ, A/CL OTLT DUCT |
N2 (L9H) |
2009-2009 |
01 |
| 010 |
|
ADAPTER, MASS AIRFLOW SEN OTLT (PART OF 11) |
|
2009-2009 |
|
| 011 |
15904068 |
ДАТЧИК, MASS AIRFLOW (INCLS 10) (INCLS AIR TEMP SENSOR) (ACDelco #213-4160)
| N2 |
2008-2009 |
01 |
|
| 012 |
|
CLAMP, A/CL HSG (PART OF 13) |
|
2009-2009 |
|
| 013 |
88944150 |
SEAL, A/CL OTLT DUCT (PART OF 15) (INCLS 12)
| N2 (L9H) |
2009-2009 |
01 |
|
| 014 |
|
INSULATOR, A/CL HSG (PART OF 15) |
|
2009-2009 |
|
| 015 |
19153610 |
CLEANER, AIR (INCLS BOLT, COVER, SEAL, RETAINER, GROMMET) (EXC ELEMENT, SENSOR) (INCLS 13, 14, 16, 17)
| N2 (L9H) |
2009-2009 |
01 |
|
| 016 |
11516424 |
БОЛТ, HFH, M6X1X25, 14.2 O.D., HDR PT, 9.8, ZE (PART OF 15)
|
2008-2009 |
02 |
|
| 017 |
|
COVER, A/CL HSG (PART OF 15) |
|
2009-2009 |
|
| 018 |
15286805 |
ELEMENT, A/CL (ACDelco #A3100C)
| N2 (L9H) |
2009-2009 |
01 |
|
| 019 |
11516725 |
БОЛТ, A/CL (M6X1X40) |
N2 (L9H) |
2009-2009 |
03 |
| 020 |
88944153 |
INSERT, A/CL HSG CVR BOLT THD |
N2 (L9H) |
2009-2009 |
03 |
| 021 |
15080962 |
COVER, F/FDR UPR REINF HOLE |
N2 |
2008-2009 |
01 |
| 022 |
15120856 |
RETAINER, F/FDR UPR REINF HOLE CVR (PUSH IN) (BLACK)
| N2 |
2008-2009 |
06 |
|
