| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
11570341 |
CLIP, ENG OIL CLR HOSE (CLIP-HOLDS TWO 12.7 TUBES, FITS 7.3 HOLEIN 3.0 THK PNL, NYLON 6/6) ( CHG..>) |
N2 |
2008-2009 |
01 |
| 002 |
|
BRACKET, ENG OIL CLR HOSE (PART OF 8) |
|
2009-2009 |
|
| 003 |
15203889 |
GASKET, ENG OIL CLR (PART OF 8)
| N2 (L9H) |
2009-2009 |
01 |
|
| 004 |
|
PLUG, ENG OIL CLR ADAP HOLE (PART OF 8) |
|
2009-2009 |
|
| 005 |
25014006 |
VALVE, OIL FLTR BYPASS (PART OF 8) (W/CAGE, SEAT, SPRING ; VALVE) (OPENING PRESSURE 11 PSI NOMINAL) (ACDelco #25014006) |
N2 (L9H) |
2009-2009 |
01 |
| 006 |
11517521 |
БОЛТ, HFH, M6X1X35, 17 THD, 14.2 OD, 9.8, 6280M, MACH, HDR-PT (PART OF 8) |
|
2008-2009 |
02 |
| 007 |
11515755 |
БОЛТ, HEX, M8X1.25X16, 15 THD, 18 O.D., 10.9, 7114M (ENG OIL CLR HOSE BRKT) (T/W 12345493 REPLCS 25534835)
|
2008-2009 |
01 |
|
| 008 |
25887191 |
HOSE, ENG OIL CLR (INCLS 2-6, 9) |
N2 (L9H) |
2009-2009 |
01 |
| 009 |
|
CAP, ENG OIL CLR HOSE CONN (PART OF 8) |
|
2009-2009 |
|
| 010 |
15724727 |
RETAINER, ENG OIL CLR CONN (PART OF 11) (1/2 WIRE CLIP)
| N2 |
2009-2009 |
01 |
|
| 011 |
15190249 |
CONNECTOR, ENG OIL CLR HOSE (INCLS 10, 12) (ALUMINUM)
| N2 |
2008-2009 |
02 |
|
| 012 |
|
SEAL, ENG OIL CLR CONN (O RING) (PART OF 11) |
|
2009-2009 |
|
