| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15201798 |
АНТЕННА, ELEK NAVIGATION (*GPS ANTENNA*) (ACDelco #15201798) |
N2 (UVB) |
2008-2009 |
01 |
| 002 |
|
CABLE, M/TEL ; NAVN ANT COAX (PART OF 3) |
|
2008-2009 |
|
| 003 |
|
HARNESS, I/P WRG (INCLS 2) (SEE GROUP 02.000 ЖГУТЫ ПРОВОДОВ-ПАНЕЛЬ ПРИБОРОВ FOR DETAILED ILLUSTRATED VIEW) |
|
2008-2009 |
|
| 004 |
11610157 |
NUT, PNL, M4.2X1.41, 8.5X11.9, 2.3-2.8 PNL, FITS 11.2X9.2 HOLE, 1050, GMW33 (I/P CARR) (10.701)
|
2008-2009 |
27 |
|
| 005 |
11589012 |
БОЛТ, HWH, M4.2X1.41X25, 16.4 THD, 12.5 OD, GM6010M STL, GMW4205 (RDO) (9.665)
|
2008-2009 |
04 |
|
| 006 |
25846421 |
RADIO, AM/FM STEREO ; AUDIO DISC PLYR ; NAVN (INCLS 9, 11) (ACDelco #25846421) |
N2 (UVB) |
2008-2008 |
01 |
| 006 |
25856154 |
RADIO, AM/FM STEREO ; AUDIO DISC PLYR ; NAVN (INCLS 9, 11) |
N2 (UL8, UVB) |
2008-2008 |
01 |
| 007 |
25841299 |
BEZEL, I/P CTR AIR OTLT (INCLS 8) (SEE GROUP 16.000 INSTRUMENT PANEL ; RELATED PARTS FOR DETAILED ILLUSTRATED VIEW) (BRONZE) (ASSEMBLY) |
N257 |
2008-2008 |
01 |
| 008 |
11589329 |
CLIP, 12X8.9X15.5, SAE 1050 SPR STL, GMW3044 (PART OF 7)
|
2008-2009 |
10 |
|
| 009 |
|
KNOB, RDO TUNING CONT (PART OF 6) |
|
2008-2009 |
|
| 010 |
|
DISC, NAVN DATA (FOR SERVICE SEE GM PARTS PROCESS/POLICY BULLETIN FOR LATEST SERVICE INFORMATION) |
|
2008-2009 |
|
| 011 |
|
KNOB, RDO VOL CONT (PART OF 6) |
|
2008-2009 |
|
| 012 |
25840249 |
RADIO, AM/FM STEREO ; CLK ; CD PLYR (INCLS 13-16) (ACDelco #25840249) |
N2 (UVA) |
2008-2008 |
01 |
| 012 |
25941920 |
RADIO, AM/FM STEREO ; CLK ; CD PLYR (INCLS 13-16) (LABELED 25941920, 25799568 OR 25864960) (ACDelco #25941920) (USED ON VEHICLES BUILT 9/17/07 AND AFTER.) |
N2 (UQA, US9) |
2008-2008 |
01 |
| 013 |
|
KNOB, RDO TUNING CONT (PART OF 12) |
|
2008-2009 |
|
| 014 |
|
PUSHBUTTON, RDO TUNE (PART OF 12) |
|
2008-2009 |
|
| 015 |
|
PUSHBUTTON, RDO PWR (PART OF 12) |
|
2008-2009 |
|
| 016 |
|
KNOB, RDO VOL CONT (PART OF 12) |
|
2008-2009 |
|
