| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25814774 |
SWITCH, TRFER CASE SEL |
N2 |
2008-2008 |
01 |
| 002 |
25841299 |
BEZEL, I/P CTR AIR OTLT (SEE GROUP 16.000 INSTRUMENT PANEL ; RELATED PARTS TRIM FOR DETAILED ILLUSTRATED VIEW) (BRONZE) (ASSEMBLY) |
N257 |
2008-2008 |
01 |
| 003 |
15093913 |
BRACKET, BCM (INCLS 5) |
N2 |
2008-2009 |
01 |
| 004 |
24244539 |
MODULE, TRFER CASE SHFT CONT |
N2 |
2008-2008 |
01 |
| 005 |
11610157 |
NUT, PNL, M4.2X1.41, 8.5X11.9, 2.3-2.8 PNL, FITS 11.2X9.2 HOLE, 1050, GMW33 (PART OF 3) (10.701)
|
2008-2009 |
02 |
|
| 006 |
11589012 |
БОЛТ, HWH, M4.2X1.41X25, 16.4 THD, 12.5 OD, GM6010M STL, GMW4205 (BCM BRKT) (9.665)
|
2008-2009 |
02 |
|
