| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
88980212 |
WINDOW, M/GATE (*KIT2) |
N2 (36) (E55) |
2005-2009 |
01 |
| 002 |
15871403 |
WEATHERSTRIP, M/GATE WDO (BLACK) |
N257 (36) |
2005-2009 |
01 |
| 003 |
88980210 |
PANEL, M/GATE OTR (*KIT2) |
N257 (36) (E55) |
2005-2009 |
01 |
| 004 |
|
PANEL, M/GATE DR HGE (*KIT2) |
|
2005-2009 |
|
| 005 |
|
RIVET, M/GATE DR HGE PNL (*KIT2) |
|
2005-2009 |
|
| 006 |
|
RIVET, M/GATE DR HGE PNL (*KIT2) |
|
2005-2009 |
|
| 007 |
|
HINGE, FOLDING RR PNL DR (*KIT2) |
|
2005-2009 |
|
| 008 |
15097704 |
HARNESS, FOLDING RR PNL (*KIT2) |
N2 (36) (E55) |
2005-2009 |
01 |
| 009 |
15204480 |
STRIKER, FLDG RR PNL DR LAT (*KIT1) |
N2 (36) (E55) |
2005-2009 |
02 |
| 010 |
09442471 |
БОЛТ, TORX HD, W/FLAT CSK, M8X1.25X35, 28 THD, 15.2 O.D., 9.8, NO (FLDG RR PNL LAT STKR) (*KIT1) |
|
2005-2009 |
04 |
| 011 |
15124103 |
VALVE, R/FLR PNL DRN HOLE FRT (ROUND SHAPED VALVE) (16.160) |
N2 (36) |
2005-2009 |
02 |
| 012 |
|
PIN, M/GATE HINGE SLAVE (*KIT2) |
|
2005-2009 |
|
| 013 |
11516781 |
ГАЙКА, HEX W/TT CON WA M10X1.5X10 24-OD 9 PC (M/GATE) (*KIT2) (8.917)
|
2005-2009 |
04 |
|
| 014 |
88980216 |
HINGE, M/GATE (*KIT2) (16.565) |
N2 (36) (E55) |
2005-2009 |
01 |
| 015 |
10392681 |
MOLDING, E/GATE CTR (SEE GROUP 16.000 INTERIOR TRIM FOR DETAILED ILLUSTRATED VIEW) (EBONY) |
N2 (36) |
2005-2009 |
01 |
| 016 |
10358747 |
COVER, REMOVABLE M/GATE HGE FIN (SEE GROUP 16.000 INTERIOR TRIM FOR DETAILED ILLUSTRATED VIEW) (EBONY) |
N2 (36) |
2005-2009 |
01 |
| 016 |
10358749 |
COVER, REMOVABLE M/GATE HGE FIN (SEE GROUP 16.000 INTERIOR TRIM FOR DETAILED ILLUSTRATED VIEW) (EBONY) |
N2 (36) |
2005-2009 |
01 |
| 017 |
88980211 |
PANEL, M/GATE INR (*KIT2) |
N2 (36) (E55) |
2005-2009 |
01 |
| 018 |
15173158 |
LABEL, M/GATE OPERG INSTR (*KIT2) |
N2 (36) (E55) |
2005-2009 |
02 |
| 019 |
15204482 |
SWITCH, FLDG RR PNL DR POSN (WHEAT) (*KIT2) |
N2 (36) (E55) |
2005-2009 |
02 |
| 020 |
11517515 |
BOLT-HFH, M6X1X10, THD 8.5, OD 14.2, 9.8, GM6280, HDR PT. (M/GATE OTR PNL) (*KIT2) |
|
2005-2009 |
09 |
| 021 |
25632772 |
NUT, W/CON WA, M8X1.25, 6.5THK, 25.4 O.D., 10, ZF (M/GATE) (*KIT2)
|
2005-2009 |
04 |
|
| 022 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (M/GATE WDO REG) (*KIT2)
|
2005-2009 |
04 |
|
| 023 |
|
WASHER, M/GATE OTR PANEL (*KIT2) |
|
2005-2009 |
|
| 024 |
|
RETAINER, M/GATE OTR PANEL (*KIT2) |
|
2005-2009 |
|
| 025 |
88980244 |
SEAL, R/WDO (*KIT2) |
N257 (36) (E55) |
2005-2009 |
02 |
| 026 |
88980214 |
CHANNEL, M/GATE WDO (*KIT2) |
N2 (36) (E55) |
2005-2009 |
01 |
| 026 |
88980215 |
CHANNEL, M/GATE WDO (*KIT2) |
N2 (36) (E55) |
2005-2009 |
01 |
| 027 |
15184907 |
LATCH, M/GATE (*KIT2) |
N2 (36) (E55) |
2005-2009 |
01 |
| 027 |
15184908 |
LATCH, M/GATE (*KIT2) |
N2 (36) (E55) |
2005-2009 |
01 |
| 028 |
|
БОЛТ, M/GATE WDO CHAN (PART OF 34) (*KIT2) |
|
2005-2009 |
|
| 029 |
|
БОЛТ, M/GATE LAT (PART OF 34) (*KIT2) |
|
2005-2009 |
|
| 030 |
89046084 |
MOTOR, WDO REG MDL (INCLS SWITCH) (*KIT2) (ACDelco #89046084) |
N2 (36) (E55) |
2006-2009 |
01 |
| 031 |
88980213 |
REGULATOR, M/GATE WDO (*KIT2) (16.460) (ACDelco #88980213) |
N2 (36) (E55) |
2005-2009 |
01 |
| 032 |
|
БОЛТ, FLDG RR PNL WDO REGULATOR (*KIT2) |
|
2005-2009 |
|
| 033 |
|
БОЛТ, M/GATE WDO (PART OF 34) (*KIT2) |
|
2005-2009 |
|
| 034 |
88980210 |
PANEL, M/GATE OTR (INCLS 28, 29, 33) (*KIT2) |
N2 (36) (E55) |
2005-2009 |
01 |
| 035 |
15243840 |
SEALING STRIP, M/GATE WDO OTR (*KIT2) |
N257 (36) (E55) |
2005-2009 |
01 |
| 036 |
15119972 |
БОЛТ, M/GATE OTR PNL (*KIT2) |
N2 (36) (E55) |
2005-2009 |
02 |
| K01 |
15204480 |
STRIKER, FLDG RR PNL DR LAT (INCLS 9, 10) |
N2 (36) (E55) |
2005-2009 |
02 |
| K02 |
25850329 |
GATE, MID (INCLS 1, 3-8, 12-14, 17-36) |
N2 (36) (E55) |
2007-2009 |
01 |
