| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
10358720 |
MOLDING, BK BODY OPG GARN (INCLS 2) (WHEAT)
| N2 (06) (50I) |
2003-2004 |
01 |
|
| 002 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 1)
|
2003-2007 |
11 |
|
| 003 |
11516630 |
SCREW, RD, M4.2X1.41X20, TYPE AB PT, GM6010M, GMW4205 (L/GATE SILL TR PLT) |
|
2003-2007 |
02 |
| 004 |
10358867 |
PLATE, L/GATE SILL TR (INCLS 5) (WHEAT)
| N2 (06) (E52, 50I) |
2003-2004 |
01 |
|
| 005 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 4)
|
2003-2007 |
09 |
|
| 006 |
11519497 |
NUT, PUSH IN, SPECIAL, 4.2X1.4 SINGLE THREAD, SAE 1050 STL, GM7111M (L/GATE SILL TR PLT)
|
2003-2007 |
02 |
|
| 007 |
88977015 |
GUIDE, ЗАДНЕЕ СИДЕНЬЕ SHLDR BELT (PART OF 8) (EBONY) |
N2 (06) |
2003-2007 |
02 |
| 008 |
10358704 |
MOLDING, BODY L/PLR GARN (INCLS 7, 9, 10) (WHEAT) |
N2 (06) (50I) |
2003-2004 |
01 |
| 008 |
10358707 |
MOLDING, BODY L/PLR GARN (INCLS 7, 9, 10) (WHEAT)
| N2 (06) (50I) |
2003-2004 |
01 |
|
| 009 |
15748479 |
RETAINER, GARNISH MOLDING TYPE, FITS SLOT 6.0MM, SPR STL, ZC (PART OF 8) |
|
2003-2007 |
14 |
| 010 |
12338108 |
CLIP, BODY L/PLR G/MLDG ENGY ABS (TYPE U SPR CLIP) (PART OF 8) (9.665) (ACDelco #12338108)
| N2 |
2003-2007 |
06 |
|
| 011 |
15076277 |
BRACKET, RR S/D SILL TR PLT (FRONT) |
N257 (06) |
2003-2004 |
02 |
| 012 |
15076278 |
BRACKET, RR S/D SILL TR PLT (REAR) |
N257 (06) |
2003-2004 |
02 |
| 013 |
21011332 |
ГАЙКА, HEX STAMPED TY DF FLG 14 (RR S/D SILL TR PLT BRKT) (8.921) |
|
2003-2007 |
06 |
| 014 |
15748479 |
RETAINER, GARNISH MOLDING TYPE, FITS SLOT 6.0MM, SPR STL, ZC (PART OF 15) |
|
2003-2007 |
06 |
| 015 |
10358855 |
PLATE, RR S/D SILL TR (INCLS 14) (WHEAT) |
N2 (06) (50I) |
2004-2004 |
01 |
| 015 |
10358858 |
PLATE, RR S/D SILL TR (INCLS 14) (WHEAT) |
N257 (06) (50I) |
2004-2004 |
01 |
