| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
17803467 |
ПОДНОЖКА, ASST (INCLS 2, 3, 4) (BLACK) (INSTALL .40) (17.0KGS) (MILD STEEL) (TEXTURED) (W/BLACK PAD) (RAISED RECT) |
N2 (BVE, DNR) |
2003-2005 |
01 |
| 001 |
17803467 |
ПОДНОЖКА, ASST (INCLS 2, 3, 4) (BLACK) (INSTALL .40) (17.0KGS) (MILD STEEL) (TEXTURED) (W/BLACK PAD) (RAISED RECT) (8.225) |
N2 (06) (SAME AS BVE) |
2003-2005 |
01 |
| 002 |
11514597 |
ГАЙКА, HFH, 10X1.5 THD, 9.8 THK, 21.8 OD, 510M (10) ZF 7111M (PART OF 1) (2.383) |
|
2003-2005 |
16 |
| 003 |
11516328 |
БОЛТ, HFH, M10X1.5X30, 22 O.D., HDR PT, 10.9, 7114M (PART OF 1)
|
2003-2005 |
16 |
|
| 004 |
12477568 |
PAD, ASST STEP FRT (INSERT -PLASTIC W/RETAINER) (PART OF 1) (W/BACK INBOARD TOE KICK) (FOR 2ND DESIGN SEE 88937278) |
N257 (1ST DES) |
2003-2003 |
02 |
| 004 |
88937278 |
PAD, ASST STEP (PART OF 1) (22 LONG) (W/O BACK INBOARD TOE KICK) (FOR 1ST DESIGN SEE 12477568) |
N257 (06) (BVE, DNR) (2ND DES) |
2003-2003 |
02 |
| 005 |
15172444 |
PROTECTOR, RKR PNL (SEE GROUP 08.000 GUARD/ROCKER PANEL FOR DETAILED ILLUSTRATED VIEW) (PAINT TO MATCH) |
N2 |
2003-2005 |
01 |
| 005 |
15172445 |
PROTECTOR, RKR PNL (SEE GROUP 08.000 GUARD/ROCKER PANEL FOR DETAILED ILLUSTRATED VIEW) (PAINT TO MATCH) |
N2 |
2003-2005 |
01 |
| 006 |
22651578 |
БОЛТ, HFH, M12X1.75X40, 26.6 O.D., FULL THD, 10.9, 7112M, PZOR (RKR PNL PROTR ASM) |
|
2003-2005 |
20 |
