| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15803711 |
HARNESS, FWD LP WRG (INCLS 2-18) |
ST155 (CE4, DD5, DF5, UA2, X88) (EXC U68) |
2007-2007 |
01 |
| 001 |
15803711 |
HARNESS, FWD LP WRG (INCLS 2-18) |
ST155 (CE4, DD5, DF5, X88) (EXC UA2, U68) |
2007-2007 |
01 |
| 001 |
15803711 |
HARNESS, FWD LP WRG (INCLS 2-18) |
ST155 (CE4, U42, X88) (EXC DD5, DF5, U68) |
2007-2007 |
01 |
| 001 |
15803711 |
HARNESS, FWD LP WRG (INCLS 2-18) |
ST155 (CE4, U68, X88) (EXC UA2) |
2007-2007 |
01 |
| 001 |
15803711 |
HARNESS, FWD LP WRG (INCLS 2-18) |
ST155 (CE4, UA2, U68, X88) |
2007-2007 |
01 |
| 001 |
15870195 |
HARNESS, FWD LP WRG (INCLS 2-18) |
ST155 (DD5, DF5, T96, X88) (EXC CE4) |
2007-2007 |
01 |
| 001 |
15870195 |
HARNESS, FWD LP WRG (INCLS 2-18) |
ST155 (T96, U68, X88) (EXC CE4) |
2007-2007 |
01 |
| 001 |
15870195 |
HARNESS, FWD LP WRG (INCLS 2-18) |
ST155 (T96, X88) (EXC CE4, DD5, DF5, U68) |
2007-2007 |
01 |
| 001 |
15870195 |
HARNESS, FWD LP WRG (INCLS 2-18) |
ST155 (X88) (EXC DD5, DF5, T96) |
2007-2007 |
01 |
| 002 |
15306302 |
CONNECTOR, SW-A/C CYCLING SW (PART OF 1) (GRAY) (2-WAY FEMALE) (W/LEADS) (4.710) (ACDelco #PT1357)
| ST1 |
2002-2007 |
01 |
|
| 003 |
15319893 |
CONNECTOR, BLK-ACSRY WRG JUNC (PART OF 1) (GRAY) (32-WAY FEMALE) |
ST1 |
2002-2007 |
01 |
| 004 |
15326842 |
CONNECTOR, INLINE-TO I/P HARN (PART OF 1) (BLACK) (10-WAY FEMALE) (W/O LEADS) (W/O CPA) (13.100) |
ST1 |
2002-2007 |
01 |
| 005 |
15306156 |
CONNECTOR, LP-SI MKR (PART OF 1) (BLACK) (2-WAY FEMALE) (W/LEADS) (3.682) (ACDelco #PT1315)
| ST1 |
2002-2007 |
02 |
|
| 006 |
15306398 |
CONNECTOR, LP-T/SIG (PART OF 1) (GRAY) (3-WAY FEMALE W/LEADS) (ACDelco #PT1451) |
ST1 |
2002-2007 |
01 |
| 006 |
15306398 |
CONNECTOR, LP-PARK T/SIG (PART OF 1) (GRAY) (3-WAY FEMALE W/LEADS) (2.596) (ACDelco #PT1451) |
ST1 |
2002-2007 |
01 |
| 007 |
12102664 |
CONNECTOR, LP-FOG (PART OF 1) (BLACK) (2-WAY FEMALE) (W/LEADS) (M/P 280 W/ORANGE SEAL) (ROUND) (2.535) (ACDelco #PT331)
| ST1 |
2002-2007 |
02 |
|
| 008 |
15306392 |
CONNECTOR, SW-A/C CMPR REFRIG PRESS (PART OF 1) (3-WAY FEMALE) (W/LEADS) (ACDelco #PT1145) |
ST155 (CE4, U68, X88) (EXC UA2) |
2007-2007 |
02 |
| 009 |
15306009 |
CONNECTOR, LP-HDLP (PART OF 1) (BLACK) (4-WAY FEMALE M/P150) (W/LEADS) (OVAL) (2.530) (ACDelco #PT1136) |
ST1 |
2002-2007 |
02 |
| 010 |
15306302 |
CONNECTOR, СИГНАЛ (PART OF 1) (GRAY) (2-WAY FEMALE) (W/LEADS) (4.710) (ACDelco #PT1357)
| ST1 |
2002-2007 |
01 |
|
| 011 |
15326829 |
CONNECTOR, MOT-ENG COOL FAN (PART OF 1) (BLACK) (6-WAY FEMALE GT150) (W/O LEADS) (HAS FULL SHROUD) (2.530) |
ST1 |
2004-2007 |
01 |
| 012 |
12101856 |
CONNECTOR, SEN-AMB AIR TEMP (PART OF 1) (GREEN) (2-WAY FEMALE) (W/LEADS) (OUTSIDE) (2.535) (ACDelco #PT248) |
ST1 |
2002-2007 |
01 |
| 013 |
88987993 |
CONNECTOR, SW-WSWA SOLV LVL (PART OF 1) (GRAY) (2-WAY FEMALE) (W/LEADS) (4.651) (ACDelco #PT1798) |
ST1 |
2005-2009 |
01 |
| 014 |
15306394 |
CONNECTOR, MOT-HDLP WA PUMP (PART OF 1) (2-WAY FEMALE) (W/LEADS) (ACDelco #PT1447) |
ST1 |
2002-2007 |
01 |
| 015 |
12102747 |
CONNECTOR, SW-WSWA (PART OF 1) (BLACK) (ACCEPTS 1.5MM TERMS) (2-WAY FEMALE) (M/P150) (W/LEADS) (REAR) (1.203) (ACDelco #PT374)
| ST1 |
2002-2007 |
01 |
|
| 016 |
12102664 |
CONNECTOR, MOT-WSWA PUMP (PART OF 1) (BLACK) (2-WAY FEMALE) (W/LEADS) (M/P 280 W/ORANGE SEAL) (ROUND) (2.535) (ACDelco #PT331)
| ST1 |
2002-2007 |
01 |
|
| 017 |
11588337 |
БОЛТ, HEX W/FL WA, M6X1X20, 9 THD, 17 OD, 6202M, GMW3200, TAP, DOG PT. (PART OF 1)
|
2002-2009 |
01 |
|
| 018 |
12102747 |
CONNECTOR, SW-КАПОТ AJAR IND (PART OF 1) (BLACK) (ACCEPTS 1.5MM TERMS) (2-WAY FEMALE) (M/P150) (W/LEADS) (REAR) (1.203) (ACDelco #PT374)
| ST1 |
2002-2007 |
01 |
|
