| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15093039 |
MIRROR, I/S RR VIEW (INCLS 2) |
ST1 (06) (DD7, VCG) (EXC AL0, UE1) |
2002-2007 |
01 |
| 001 |
15125007 |
MIRROR, I/S RR VIEW (INCLS 2) (FRT PASS/CHILD PRESENCE DETECTOR) |
ST1 (06) (EXC DD4, DD5, DD7, UE1, VCG) |
2005-2005 |
01 |
| 001 |
15125008 |
MIRROR, I/S RR VIEW (INCLS 2) (FRT PASS/CHILD PRESENCE DETECTOR)
| ST1 (06) (VCG) (EXC DD4, DD5, DD7, UE1) |
2005-2005 |
01 |
|
| 001 |
15144156 |
MIRROR, I/S RR VIEW (INCLS 2) (INSIDE) |
ST1 (06) (UE1, VCG) (EXC DD4, DD5, DD7) |
2005-2005 |
01 |
| 001 |
15144157 |
MIRROR, I/S RR VIEW (INCLS 2) (INSIDE) |
ST1 (06) (UE1) (EXC DD4, DD5, DD7, VCG) |
2005-2005 |
01 |
| 001 |
15144162 |
MIRROR, I/S RR VIEW (INCLS 2) |
ST1 (06) (DD5, UE1) (EXC VCG) |
2005-2006 |
01 |
| 001 |
15144166 |
MIRROR, I/S RR VIEW (INCLS 2) |
ST1 (06) (DD5, UE1, VCG) |
2005-2006 |
01 |
| 001 |
15144167 |
MIRROR, I/S RR VIEW (INCLS 2) |
ST1 (06) (DD4, UE1) (EXC VCG) |
2005-2005 |
01 |
| 001 |
15144168 |
MIRROR, I/S RR VIEW (INCLS 2) |
ST1 (06) (DD4, UE1, VCG) |
2005-2005 |
01 |
| 001 |
15144169 |
MIRROR, I/S RR VIEW (INCLS 2) |
ST1 (06) (DD4, VCG) (EXC UE1) |
2005-2005 |
01 |
| 001 |
15144170 |
MIRROR, I/S RR VIEW (INCLS 2) |
ST1 (06) (DD4) (EXC UE1, VCG) |
2005-2005 |
01 |
| 001 |
15144171 |
MIRROR, I/S RR VIEW (INCLS 2) |
ST1 (06) (DD5) (EXC UE1, VCG) |
2005-2006 |
01 |
| 001 |
15144172 |
MIRROR, I/S RR VIEW (INCLS 2) |
ST1 (06) (DD5, VCG) (EXC UE1) |
2005-2006 |
01 |
| 002 |
|
БОЛТ, I/S RR VIEW MIR (PART OF 1) |
|
2004-2005 |
|
| 003 |
25653132 |
BRACKET, I/S RR VIEW MIR (PART OF 14) (10.187) |
ST1 |
2005-2005 |
01 |
| 004 |
15095432 |
MOLDING, W/S UPR RVL
| ST1 (06) |
2005-2008 |
01 |
|
| 005 |
12346392 |
ADHESIVE KIT, GLASS URETHANE (GLS URETHANE) (FOR INSTALLATION OF ALL STATIONARY WINDOW GLASS) |
|
2002-2008 |
AR |
| 006 |
15100759 |
MOLDING, W/S SI RVL
| ST1 (06) |
2005-2008 |
01 |
|
| 006 |
15100760 |
MOLDING, W/S SI RVL
| ST1 (06) |
2005-2008 |
01 |
|
| 007 |
11609539 |
SCREW, RD CROWNED WA HD, M4.2X1.41X16, STL ISO 2702, GMW4205 (W/S SI R/MLDG)
|
2002-2008 |
08 |
|
| 008 |
|
RIVET, VIN PLT |
|
2004-2005 |
|
| 009 |
|
PLATE, VIN (CONTACT APPROPRIATE AUTHORITY GOVERNING MOTOR VEHICLES FOR REPLACEMENT PROCESS) |
|
2004-2005 |
|
| 010 |
15061964 |
SUPPORT, W/S
| ST1 (06) |
2002-2008 |
02 |
|
| 011 |
|
PANEL, AIR INL GRL (СМ. ГРУППУ 16.000 СИСТЕМА СТЕКЛООЧИСТИТЕЛЯ/ЛОБОВОЕ СТЕКЛО FOR DETAILED ILLUSTRATED VIEW) |
|
2002-2008 |
|
| 012 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (AIR INL GRL PNL)
|
2002-2008 |
02 |
|
| 013 |
11561878 |
RETAINER, PUSH PIN W/SEAL, FITS 8.0-8.25 DIA HOLE IN 3-7MM THK PNL (AIR INL GRL PNL)
|
2002-2008 |
02 |
|
| 014 |
15892616 |
WINDSHIELD, (INCLS 3) (INCLUDES RAIN SENSOR MOUNTING RING) (WINDSHIELD NO LONGER HAS SUNSHADE LINE DUE TO PRODUCTION CHANGE) |
ST1 (CE1) (EXC A26) |
2002-2006 |
01 |
| 014 |
15892617 |
WINDSHIELD, (INCLS 3)
| ST1 (A26, CE1) (EXPORT) |
2002-2006 |
01 |
|
| 014 |
15892620 |
WINDSHIELD, (INCLS 3) |
ST1 (Y91) (EXC A26, CE1) |
2005-2006 |
01 |
| 014 |
25799187 |
WINDSHIELD, (LESS RAIN SENSOR MTG RING) (INCLS 3) (LESS SUNSHADE BAND ON WINDSHIELD) |
ST1 (06) (X88) (EXC A26, CE1, Y91) |
2005-2005 |
01 |
| 014 |
25974700 |
WINDSHIELD, (INCLS 3)
| ST1 (A26) (EXC CE1) (EXPORT) |
2002-2006 |
01 |
|
| 015 |
|
HARNESS, DM LP WRG (СМ. ГРУППУ 16.000 TRIM/INTERIOR ROOF FOR DETAILED ILLUSTRATED VIEW) |
|
2002-2008 |
|
| 016 |
10397579 |
COVER, I/S RR VIEW MIR WRG HARN
| ST1 |
2005-2008 |
01 |
|
