| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
88892974 |
MOTOR, AUX BLO (ACDelco #15-80206) |
ST158 (06) |
2004-2006 |
01 |
| 001 |
88892974 |
MOTOR, AUX BLO (8.855) (ACDelco #15-80206) |
ST158 (06) |
2004-2006 |
01 |
| 002 |
88892988 |
БОЛТ, AUX A/C EVPR BLO CASE (PAN HEAD 10-16 HI/LO THREAD) |
ST158 (06) (CJ2, CJ3) |
2004-2006 |
41 |
| 003 |
88892975 |
ACTUATOR, MODE VLV (AUX) (ACDelco #15-72811) |
ST158 (06) (CJ2, CJ3) |
2004-2006 |
01 |
| 004 |
88892995 |
HARNESS, A/C CONT WRG |
ST158 (06) (CJ2, CJ3) |
2004-2006 |
01 |
| 005 |
88892976 |
MODULE, BLO MOT CONT (AUX HTR) (ACDelco #15-72813)
| ST158 (06) (CJ2, CJ3) |
2004-2006 |
01 |
|
| 006 |
88892989 |
БОЛТ, HTR A/C CONT |
ST158 (06) (CJ2, CJ3) |
2004-2006 |
02 |
| 007 |
|
SPACER, A/C EVPR CASE (*KIT1) |
|
2005-2006 |
|
| 008 |
|
SPACER, A/C EVPR CASE (*KIT1) |
|
2005-2006 |
|
| 009 |
|
CASE, AUX HTR CORE (*KIT1) |
|
2005-2006 |
|
| 010 |
|
INSULATOR, A/C EVPR MDL (PART OF 11) |
|
2005-2006 |
|
| 011 |
89023467 |
CASE, AUX A/C EVPR (INCLS 10) |
ST158 (06) (CJ2, CJ3) |
2004-2006 |
01 |
| 012 |
88986239 |
TUBE, A/C EVPR CASE DRN (9.211) (ACDelco #15-33364) |
ST158 (06) (CJ2, CJ3) |
2004-2006 |
01 |
| 012 |
88986239 |
TUBE, A/C EVPR CASE DRN (ACDelco #15-33364) |
ST158 (06) (CJ2, CJ3) |
2004-2006 |
01 |
| 013 |
89024921 |
SEAL, AUX A/C EVPR PIPE (INCLS 4 SEAL DESIGNS) (ACDelco #15-33261) |
ST158 (06) (CJ2, CJ3) |
2004-2006 |
01 |
| 014 |
88892994 |
STUD, HTR A/C EVPR BLO MDL RET |
ST158 (06) (CJ2, CJ3) |
2004-2006 |
02 |
| 015 |
88892985 |
SEAL, A/C EVPR TUBE (62.5 X 50.9 RECTANGLE) (ACDelco #15-31964) |
ST158 (06) (CJ2, CJ3) |
2004-2006 |
01 |
| 016 |
89023466 |
EVAPORATOR KIT, AUX A/C (INCLS 17) (ACDelco #15-63249) |
ST158 (06) (CJ2, CJ3) |
2005-2006 |
01 |
| 017 |
|
SEAL, AUX A/C EVPR (PART OF 16) |
|
2005-2006 |
|
| 018 |
88892986 |
VALVE, AUX A/C EVPR THERMAL EXPN (INCLS 19-28, 38) (ACDelco #15-5900)
| ST158 (06) (CJ2, CJ3) |
2004-2006 |
01 |
|
| 019 |
|
INSULATOR, A/C EVPR TXV (PART OF 18) |
|
2005-2006 |
|
| 020 |
|
FILTER, A/C EVPR AIR (PART OF 18) |
|
2005-2006 |
|
| 021 |
|
SEAL, A/C EVPR TXV (O RING) (PART OF 18) |
|
2005-2006 |
|
| 022 |
|
SEAL, A/C EVPR TXV (O RING) (PART OF 18) |
|
2005-2006 |
|
| 023 |
|
INSULATOR, A/C EVPR INL TUBE CLA (PART OF 18) |
|
2005-2006 |
|
| 024 |
|
CLAMP, AUX A/C EVPR OTLT TUBE (PART OF 18) |
|
2005-2006 |
|
| 025 |
|
INSULATOR, A/C EVPR TUBE (PART OF 18) |
|
2005-2006 |
|
| 026 |
|
INSULATOR, AUX A/C EVPR TUBE (PART OF 18) |
|
2005-2006 |
|
| 027 |
|
SEAL, AUX A/C EVPR INL TUBE (O RING) (PART OF 18) |
|
2005-2006 |
|
| 028 |
|
SEAL, AUX A/C EVPR OTLT TUBE (O RING) (PART OF 18) |
|
2005-2006 |
|
| 029 |
88986238 |
GROMMET, AUX A/C EVPR HOSE |
ST158 (06) (CJ2, CJ3) |
2004-2006 |
01 |
| 030 |
|
BRACKET, AUX A/C EVPR TUBE (SERVICED WITH AUX HTR A/C EVPR BLO MODULE IN GROUP 09.169) |
|
2005-2006 |
|
| 031 |
88892993 |
STUD, AUX A/C EVPR TUBE CLIP |
ST158 (06) (CJ2, CJ3) |
2004-2006 |
02 |
| 032 |
89023464 |
COVER, AUX HTR |
ST158 (06) (CJ2, CJ3) |
2005-2006 |
01 |
| 033 |
88892975 |
ACTUATOR, TEMP VLV (AUX) (ACDelco #15-72811) |
ST158 (06) (CJ2, CJ3) |
2004-2006 |
01 |
| 034 |
89023339 |
CORE, AUX HTR (ACDelco #15-63083) (IF VEHICLE CONTAINS BLOCK FTG ALSO REQUIRES 89023336 CONVERSION KIT 89024921 SEAL) |
ST158 (06) (CJ2, CJ3) |
2004-2006 |
01 |
| 035 |
|
CASE, AUX HTR CORE (*KIT1) |
|
2005-2006 |
|
| 036 |
|
VALVE, TEMP (*KIT1) |
|
2005-2006 |
|
| 037 |
|
VALVE, MODE (*KIT1) |
|
2005-2006 |
|
| 038 |
|
TUBE, AUX A/C EVPR INL (PART OF 18) |
|
2005-2006 |
|
| K01 |
89023340 |
CASE, HTR A/C EVPR (INCLS 7-9, 35-37) |
ST158 (06) (CJ2, CJ3) |
2004-2006 |
01 |
