| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
11516078 |
ГАЙКА, HFH, M12X1.75, 14THK, 25 O.D., 10, PZOR (ENG MT)
|
2002-2009 |
02 |
|
| 002 |
15062379 |
BRACKET, ENG MT (ENG SIDE) |
ST1 (LL8) |
2005-2009 |
01 |
| 002 |
15062380 |
BRACKET, ENG MT (ENG SIDE)
| ST1 (LL8) |
2005-2009 |
01 |
|
| 003 |
11519083 |
БОЛТ, HEX W/CON WA, M10X1.5X36, 23.3 THD, 20 OD, 10.9, 7114M, MACH, MAT-PT (ENG MT ENG SI BRKT)
|
2002-2009 |
08 |
|
| 004 |
15062381 |
MOUNT, ENG
| ST1 (LL8) |
2005-2009 |
02 |
|
| 005 |
88964337 |
BRACKET, ENG MT (FRAME SIDE) |
ST1 (LL8) |
2005-2009 |
01 |
| 005 |
88964338 |
BRACKET, ENG MT (FRAME SIDE) |
ST1 (LL8) |
2005-2009 |
01 |
| 006 |
11516078 |
ГАЙКА, HFH, M12X1.75, 14THK, 25 O.D., 10, PZOR (ENG MT)
|
2002-2009 |
02 |
|
| 007 |
25642453 |
RETAINER, OIL FLTR DRN DFL (PUSH IN) (6MM DIA) (3.671)
| ST1 (LL8) |
2005-2009 |
02 |
|
| 008 |
15095165 |
DEFLECTOR, OIL FLTR DRN |
ST1 (LL8) |
2005-2009 |
01 |
| 009 |
11589247 |
BOLT-HFH, M14X2X165.5, 58.2 THD, 30.5 ID, 10.9, 7114M, MACH, CONE-PT (ENG MT FRM SI BRKT) |
|
2002-2009 |
06 |
| 010 |
15875691 |
SHIELD, ENG MT |
ST1 (LL8) |
2002-2009 |
01 |
| 012 |
11518388 |
БОЛТ, TRANS MT (M10X1.5X45)
| T1 |
2005-2009 |
02 |
|
| 013 |
11516747 |
ГАЙКА, HEX LOCK W/CON WA, M10X1.5X13.37, 10, 7111M, ALL METAL PREV TORQ (TRANS MT)
|
2002-2009 |
02 |
|
| 014 |
89040447 |
BRACKET, EXH PIPE HNGR
| ST1 (LL8, M30) |
2005-2009 |
01 |
|
| 015 |
89040448 |
MOUNT, TRANS (W/O EXH BRKT ASM)
| T1 (LL8, M30) |
2005-2009 |
01 |
|
