Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
001 |
88937088 |
ДВЕРЬ, ПЕРЕДНЯЯ SI (W/O HINGES)
| ST1 (06) |
2005-2009 |
01 |
001 |
88937089 |
ДВЕРЬ, ПЕРЕДНЯЯ SI (W/O HINGES)
| ST1 (06) |
2005-2009 |
01 |
002 |
15206920 |
WINDOW, FRT S/D
| ST1 (06) (X88, Z88) (EXC B4U, Y91) |
2006-2009 |
01 |
002 |
25930348 |
WINDOW, FRT S/D
| ST1 (06) (X88, Z88) (EXC B4U, Y91) |
2006-2009 |
01 |
003 |
10386316 |
INSULATOR, FRT S/D |
ST158 |
2006-2006 |
02 |
004 |
15944000 |
REGULATOR, FRT S/D WDO (INCLS 5-8) (INCLS MOTOR) (16.260)
| ST1 (06) |
2002-2009 |
01 |
004 |
15944000 |
REGULATOR, FRT S/D WDO (INCLS 5-8) (INCLS MOTOR)
| ST1 (06) |
2002-2009 |
01 |
004 |
15944001 |
REGULATOR, FRT S/D WDO (INCLS 5-8) (INCLS MOTOR) (16.260) (ACDelco #15944001) |
ST1 (06) |
2002-2009 |
01 |
004 |
15944001 |
REGULATOR, FRT S/D WDO (INCLS 5-8) (INCLS MOTOR) (ACDelco #15944001) |
ST1 (06) |
2002-2009 |
01 |
005 |
|
БОЛТ, FRT S/D WDO REG MOT (PART OF 4) |
|
2006-2009 |
|
006 |
89046086 |
MOTOR, FRT S/D WDO REG (PART OF 4) (ACDelco #89046086)
| ST158 |
2006-2006 |
01 |
006 |
89046087 |
MOTOR, FRT S/D WDO REG (PART OF 4) (ACDelco #89046087) |
ST158 |
2006-2006 |
01 |
007 |
11519381 |
БОЛТ, WASHER M6X1X15, 5.75 THD, 17 OD, 8.8, GMW3359, M-POINT, 1.65 CON SPRWA (PART OF 4) |
|
2002-2009 |
04 |
008 |
03530297 |
ГАЙКА, HFH, M6X1, 5.85THK, 14.2 O.D., 10, ZOR (PART OF 4)
| |
2002-2009 |
04 |
009 |
11519381 |
БОЛТ, WASHER M6X1X15, 5.75 THD, 17 OD, 8.8, GMW3359, M-POINT, 1.65 CON SPRWA (FRT S/D WDO REG) |
|
2002-2009 |
06 |
010 |
15042820 |
ГАЙКА, FRT S/D I/S HDL (M6X1, 19X14) (9.665)
| ST1 |
2005-2009 |
02 |
011 |
25868201 |
HANDLE, FRT S/D I/S (INCLS 13, 14) (EBONY) (W/O LOCK/HNDL RODS) (WHEN REPLG 15044612 W/CHROME LOCK KNOB REPL BOTH SIDES) |
ST1 (X88) |
2005-2007 |
01 |
011 |
25868201 |
HANDLE, FRT S/D I/S (INCLS 13, 14) (EBONY) (W/O LOCK/HNDL RODS) (WHEN REPLG 15044612 W/CHROME LOCK KNOB REPL BOTH SIDES) (16.345) |
ST1 (X88) |
2005-2007 |
01 |
011 |
25868338 |
HANDLE, FRT S/D I/S (INCLS 13, 14) (EBONY) (W/O LOCK/HNDL RODS) (WHEN REPLG 15044613 W/CHROME LOCK KNOB REPL BOTH SIDES)
| ST1 (06) (X88) |
2005-2007 |
01 |
012 |
11519806 |
БОЛТ, HEX W/CON WA, M6X1X22, 14.88 THD, 17 OD, 9.8, 6280M, MACH, MAT-PT (FRT S/D I/S HDL)
| |
2002-2009 |
02 |
013 |
10292364 |
CLIP, FRT S/D I/S HDL ROD (PART OF 11) (BLACK) (10.512)
| ST1 |
2005-2009 |
01 |
013 |
10292365 |
CLIP, FRT S/D I/S HDL ROD (INSIDE) (PART OF 11) (WHITE) (10.512) |
ST1 |
2005-2009 |
01 |
014 |
10292364 |
CLIP, FRT S/D LKG ROD (INSIDE) (PART OF 11) (BLACK) (10.512)
| ST1 |
2002-2009 |
01 |
014 |
10292365 |
CLIP, FRT S/D LKG ROD (INSIDE) (PART OF 11) (WHITE) (10.512) |
ST1 |
2002-2009 |
01 |
015 |
15081427 |
ROD, FRT S/D I/S HDL (BLACK) |
ST1 |
2005-2009 |
01 |
015 |
15081429 |
ROD, FRT S/D I/S HDL (BLACK) |
ST1 |
2005-2009 |
01 |
016 |
15291850 |
ROD, FRT S/D LKG |
ST1 |
2005-2009 |
01 |
016 |
15291851 |
ROD, FRT S/D LKG |
ST1 (06) |
2005-2009 |
01 |
017 |
15336498 |
GROMMET, FRT S/D DR WRG HARN (PART OF 18) |
ST1 |
2005-2009 |
02 |
018 |
|
HARNESS, FRT S/D DR WRG (СМ. ГРУППУ 02.000 ЖГУТ ПРОВОДОВ/ПЕРЕДНЯЯ ДВЕРЬ FOR DETAILED ILLUSTRATED VIEW) (INCLS 17) |
|
2002-2009 |
|
019 |
15110505 |
LOCK, FRT S/D (INCLS 20-23) (INCLS ACTUATOR) |
ST1 (06) (EXC UA2, UA6) |
2002-2009 |
01 |
019 |
15110506 |
LOCK, FRT S/D (INCLS 20-23) (INCLS ACTUATOR) |
ST1 (06) (EXC AU0, AU5, AU8) |
2002-2009 |
01 |
019 |
15110507 |
LOCK, FRT S/D (INCLS 20-23) (INCLS ACTUATOR, DR AJAR SW)
| ST1 (06) (UA2, UA6) |
2002-2009 |
01 |
019 |
15110508 |
LOCK, FRT S/D (INCLS 20-23) (INCLS ACTUATOR, DR AJAR SW) |
ST1 (06) (AU0, AU5, AU8) |
2002-2009 |
01 |
020 |
16633853 |
CLIP, FRT S/D O/S HDL (PART OF 19) (YELLOW) (PLASTIC) (10.527)
| ST1 |
2005-2009 |
AR |
020 |
16640343 |
CLIP, FRT S/D O/S HDL (PART OF 19) (YELLOW) (10.527)
| ST1 (06) |
2005-2009 |
01 |
021 |
16640343 |
CLIP, FRT S/D O/S HDL (PART OF 19) (YELLOW) (10.527)
| ST1 |
2002-2009 |
02 |
022 |
|
ACTUATOR KIT, FRT S/D LK (PART OF 19) |
|
2006-2009 |
|
023 |
16606574 |
БОЛТ, FRT S/D LAT (FRM TO HSG) (PART OF 19) (M2.3X1.34X9) (TORX HD) (10.474) |
ST1 |
2005-2009 |
02 |
024 |
15075020 |
ROD, FRT S/D LK CYL |
ST1 (06) |
2005-2009 |
01 |
024 |
15075021 |
ROD, FRT S/D LK CYL |
ST1 |
2005-2009 |
01 |
025 |
15065805 |
PLUG, FRT S/D DRN HOLE |
ST1 |
2002-2006 |
04 |
026 |
15041919 |
GUIDE, FRT S/D LKG ROD (16.157) |
ST1 |
2002-2009 |
02 |
027 |
11516075 |
ГАЙКА, HFH SELF LK, M6X1, 7.7THK, 14.2 O.D., 9, PZOR (FRT S/D O/S HDL)
| |
2002-2009 |
04 |
028 |
11517230 |
БОЛТ, TORX, W/WA, W/ADH, M6X1X20, 16.2 O.D., DOG PT, 10.9, GM6138M (FRT S/D LK)
| |
2002-2009 |
06 |
029 |
|
CYLINDER KIT, FRT S/D LK (UNCODED) (СМ. ГРУППУ 16.000 ЗАМОК БОКОВОЙ ДВЕРИ FOR DETAILED ILLUSTRATED VIEW) (10.552) |
|
2002-2009 |
|
030 |
15075201 |
ROD, FRT S/D O/S HDL (PART OF 34) |
ST1 (06) |
2005-2009 |
01 |
030 |
15075202 |
ROD, FRT S/D O/S HDL (PART OF 34) |
ST1 |
2005-2009 |
01 |
031 |
52371986 |
CLIP, FRT S/D LKG ROD (OUTSIDE) (PART OF 34) |
ST1 |
2002-2009 |
01 |
031 |
52371987 |
CLIP, FRT S/D LKG ROD (OUTSIDE) (PART OF 34) |
ST1 |
2002-2009 |
01 |
032 |
|
SEAL, FRT S/D O/S HDL (PART OF 34) |
|
2006-2009 |
|
033 |
|
CLIP, FRT S/D LK CYL (PART OF 34) |
|
2006-2009 |
|
034 |
15291303 |
HANDLE, FRT S/D O/S (INCLS 30-33) (BLACK) |
ST1 (06) (X88) (EXC B4U, YC5, YC6) |
2006-2007 |
01 |
034 |
15291304 |
HANDLE, FRT S/D O/S (INCLS 30-33) (BLACK) (WITHOUT KEY) |
ST1 (06) (AU0, AU5, AU8, X88) (EXC B4U, YC5, YC6) |
2006-2007 |
01 |
034 |
15291305 |
HANDLE, FRT S/D O/S (INCLS 30-33) (BLACK) (W/KEY) |
ST1 (X88) (EXC AU0, AU5, AU8, B4U, YC5, YC6) |
2006-2007 |
01 |
