| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
11518447 |
CLIP, C/PLR UPR T/PNL (PART OF 5) (TRIM TO BODY-UPR) (10.056) |
ST1 (CJ2) |
2005-2007 |
02 |
| 001 |
11518447 |
CLIP, C/PLR UPR T/PNL (PART OF 5) (TRIM TO BODY-UPR) (10.056) |
ST1 (CJ3) |
2005-2007 |
02 |
| 002 |
11609460 |
SCREW, RND WA, M4.2X1.41X10, 4.2 THD, 11 OD, GM6010M, GMW4205, C/R, TAP (PART OF 5)
|
2005-2007 |
02 |
|
| 003 |
10391817 |
CAP, C/PLR UPR T/PNL BOLT (PART OF 5) (CASHMERE) |
ST1 (ASF, CJ2, CJ3, 47I) |
2005-2007 |
02 |
| 003 |
10391818 |
CAP, C/PLR UPR T/PNL BOLT (PART OF 5) (GRAY) |
ST1 (CJ2, CJ3, 27I, 28I, 48I) |
2006-2007 |
02 |
| 004 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 5-7)
|
2005-2007 |
16 |
|
| 005 |
15233541 |
MOLDING, C/PLR UPR GARN (INCLS 1-4) (GRAY) |
ST1 (ASF, CJ2, CJ3, 27I, 28I, 48I) |
2005-2007 |
01 |
| 005 |
15233542 |
MOLDING, C/PLR UPR GARN (INCLS 1-4) (CASHMERE) |
ST1 (ASF, CJ2, CJ3, 47I) |
2005-2007 |
01 |
| 006 |
15110538 |
MOLDING, C/PLR LWR GARN (INCLS 4) (CASHMERE) |
ST1 (47I) |
2005-2007 |
01 |
| 006 |
15246142 |
MOLDING, C/PLR LWR GARN (INCLS 4) (EBONY) |
ST1 (27I, 48I) |
2005-2007 |
01 |
| 006 |
15246143 |
MOLDING, C/PLR LWR GARN (INCLS 4) (GRAY) |
ST1 (28I) |
2005-2007 |
01 |
| 007 |
15207502 |
MOLDING, C/PLR UPR GARN (INCLS 4) (CASHMERE) |
ST1 (CJ2, CJ3, 47I) (EXC ASF) |
2005-2007 |
01 |
| 007 |
15235689 |
MOLDING, C/PLR UPR GARN (INCLS 4) (GRAY) |
ST1 (06) (CJ2, CJ3, 27I, 28I, 48I) (EXC ASF) |
2006-2007 |
01 |
| 008 |
11588861 |
RETAINER, FRT S/D SILL TR PLT (PART OF 9) (SILVER) (STEEL) |
ST1 |
2005-2007 |
08 |
| 009 |
15828437 |
PLATE, FRT S/D SILL TR (INCLS 8) (EBONY)
| ST1 (06) (X88, 27I, 48I) |
2005-2007 |
01 |
|
| 009 |
15828438 |
PLATE, FRT S/D SILL TR (INCLS 8) (GRAY) |
ST1 (06) (X88, 28I) |
2005-2007 |
01 |
| 010 |
15117274 |
RETAINER, FRT S/D SILL TR PLT (GRAY) (PLASTIC) |
ST1 (06) (28I) |
2005-2007 |
02 |
| 010 |
15125627 |
RETAINER, FRT S/D SILL TR PLT (EBONY) (PLASTIC) |
ST1 (06) (27I, 48I) |
2005-2007 |
02 |
| 011 |
11609460 |
SCREW, RND WA, M4.2X1.41X10, 4.2 THD, 11 OD, GM6010M, GMW4205, C/R, TAP (PART OF 12)
|
2005-2007 |
02 |
|
| 012 |
15782066 |
MOLDING, W/S SI GARN (INCLS 11, 13, 14) (GRAY) |
ST1 (27I, 48I) |
2005-2007 |
01 |
| 012 |
15782066 |
MOLDING, W/S SI GARN (INCLS 11, 13, 14) (GRAY) |
ST1 (28I) |
2005-2007 |
01 |
| 013 |
10391655 |
CAP, W/S SI G/MLDG BOLT (PART OF 12) (GRAY) |
ST1 (27I, 48I) |
2005-2007 |
01 |
| 013 |
10391655 |
CAP, W/S SI G/MLDG BOLT (PART OF 12) (GRAY) |
ST1 (28I) |
2005-2007 |
01 |
| 014 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 12)
|
2005-2007 |
02 |
|
