| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
89046938 |
HOSE, WSWA PUMP (PART OF HARNESS ASM-BODY WRG) |
ST158 |
2005-2006 |
01 |
| 002 |
15003571 |
HOSE, R/WDO WA PUMP (PART OF 5) (RESERVOIR) |
ST1 |
2002-2006 |
01 |
| 003 |
|
BRACKET, WSWA PUMP (PART OF 5) |
|
2006-2006 |
|
| 004 |
10386728 |
PUMP, R/WDO WA (PART OF 5) (ACDelco #10386728)
| ST1 |
2005-2006 |
01 |
|
| 005 |
|
CONTAINER, WSWA SOLV (W/PUMP) (СМ. ГРУППУ 16.000 ЕМКОСТЬ/СТЕКЛООЧИСТИТЕЛЬ FOR DETAILED ILLUSTRATED VIEW) (INCLS 2-4, 6) |
|
2002-2006 |
|
| 006 |
22039457 |
GROMMET, WSWA PUMP (PART OF 5) (18MM) (10.153)
| ST1 |
2005-2006 |
AR |
|
| 007 |
88987515 |
HOSE, R/WDO WA PUMP (PART OF 17) (LIFTGATE)
| ST158 (06) |
2002-2006 |
01 |
|
| 008 |
11609859 |
SCREW - HEX HEAD HI-LO TORQ ROB, GM 6010M, BLACK ZINK GM 4345M (R/WDO WPR ARM PARK RAMP) |
|
2002-2006 |
02 |
| 009 |
88958107 |
SPACER, R/WDO WPR MOT |
ST1 |
2005-2006 |
01 |
| 010 |
|
WIPER, R/WDO (INSERT) (PART OF 11) |
|
2006-2006 |
|
| 011 |
15160740 |
BLADE, R/WDO WPR (INCLS 10)
| ST1 (06) (X88, Z88, Z89) |
2006-2006 |
01 |
|
| 012 |
15908046 |
ARM, R/WDO WPR (INCLS 13) (METAL) (INCLS HOSE) (WITH NOZZLE)
| ST1 (06) (X88, Z88, Z89) |
2005-2006 |
01 |
|
| 013 |
88944481 |
COVER, WSW ARM (PART OF 12)
| ST1 (06) |
2002-2006 |
01 |
|
| 014 |
11589150 |
ГАЙКА, HEX, W/ADH, M8X1.25X6.80, 5, GMW3359 (R/WDO WPR ARM)
|
2002-2006 |
01 |
|
| 015 |
15195917 |
RAMP, R/WDO WPR ARM PARK
| ST1 (06) (X88, Z88, Z89) |
2006-2006 |
01 |
|
| 016 |
22101215 |
ГАЙКА, R/WDO WPR MOT (BLACK) (13/16-16X9.6, 34 OD PLASTIC) (12.188)
| ST1 |
2005-2006 |
01 |
|
| 017 |
|
HARNESS, L/GATE WRG (СМ. ГРУППУ 2.000 HARNESS/LIFTGATE FOR DETAILED ILLUSTRATED VIEW) (INCLS 7) |
|
2002-2006 |
|
| 018 |
25805561 |
MOTOR, R/WDO WPR (ACDelco #25805561)
| ST1 (06) |
2002-2006 |
01 |
|
| 019 |
11516932 |
БОЛТ, HEX HD, W/CON WA, M6X1X25, 9.8, 6138M (R/WDO WPR MOT) |
|
2002-2006 |
02 |
