| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15819356 |
HARNESS, CHAS RR WRG (INCLS 2) |
S158 (06) (LL8, G67, Z88) |
2006-2006 |
01 |
| 001 |
15819356 |
HARNESS, CHAS RR WRG (INCLS 2) |
S158 (06) (LL8, X88) |
2006-2006 |
01 |
| 001 |
15819356 |
HARNESS, CHAS RR WRG (INCLS 2) |
S158 (06) (LL8, Z88) (EXC G67) |
2006-2006 |
01 |
| 005 |
11588337 |
БОЛТ, HEX W/FL WA, M6X1X20, 9 THD, 17 OD, 6202M, GMW3200, TAP, DOG PT. (CHAS RR WRG HARN GRD)
|
2002-2006 |
02 |
|
| 006 |
88987250 |
TUBE, AUTO LVL CONT AIR CMPR |
ST158 |
2005-2006 |
01 |
| 007 |
88987249 |
TUBE, AUTO LVL CONT AIR CMPR |
ST158 |
2005-2006 |
01 |
| 009 |
88986451 |
CONNECTOR, SEN-F/TNK PRESS (BLACK) (3-WAY FEMALE MP150) (W/LEADS) (2.535) (ACDelco #PT1604) |
ST1 |
2002-2006 |
01 |
| 010 |
12101858 |
CONNECTOR, SOL-EVAP EMIS CNSTR VENT VLV (RED) (2-WAY FEMALE) (W/LEADS) (2.535) (ACDelco #PT250)
| ST1 (LH6, LL8, LS2) |
2006-2006 |
01 |
|
| 011 |
15306441 |
CONNECTOR, SDR-FUEL (GRAY) (4-WAY FEMALE) (W/LEADS) (PRIMARY) (ACDelco #PT1537) |
ST1 |
2002-2006 |
01 |
| 012 |
11588337 |
БОЛТ, HEX W/FL WA, M6X1X20, 9 THD, 17 OD, 6202M, GMW3200, TAP, DOG PT. (CHAS RR WRG HARN F/PMP GRD)
|
2002-2006 |
01 |
|
| 016 |
88987993 |
CONNECTOR, SEN-VEH SPD (FRT, LH RH RR) (GRAY) (2-WAY FEMALE) (W/LEADS) (4.651) (ACDelco #PT1798) |
ST1 |
2005-2006 |
03 |
| 017 |
12102490 |
CONNECTOR, INLINE-TO ENG HARN (LH, RH) (GRAY) (7-WAY MALE) (W/LEADS) (ACDelco #PT281) |
ST1 (LH6, LS2) |
2006-2006 |
02 |
| 017 |
12167120 |
CONNECTOR, INLINE-TO ENG HARN (M/P 150) (BLACK) (2-WAY MALE) (W/LEADS) (OVAL) (4.720) (ACDelco #PT786) |
ST1 (LH6) |
2005-2006 |
01 |
| 017 |
15305889 |
CONNECTOR, INLINE-TO ENG HARN (BLACK) (3-WAY MALE) (W/LEADS) (ACDelco #PT1033) |
ST1 (LH6, LS2) |
2006-2006 |
01 |
| 017 |
15326840 |
CONNECTOR, INLINE-TO ENG HARN (BLACK) (8-WAY MALE) (W/O LEADS)
| ST1 (LL8) |
2006-2006 |
01 |
|
| 017 |
15326842 |
CONNECTOR, INLINE-TO ENG HARN (BLACK) (10-WAY FEMALE) (W/O LEADS) (W/O CPA) (13.100) |
ST1 (LL8) |
2005-2006 |
01 |
| 017 |
15326843 |
CONNECTOR, INLINE-TO ENG HARN (BLACK) (10-WAY FEMALE) (W/O LEADS) (W/ CPA) |
ST1 (LL8) |
2005-2006 |
01 |
| 017 |
19151508 |
CONNECTOR, INLINE-TO ENG HARN (BLACK) (38-WAY MALE) (W/STABILIZER, TPA CAVITY PLUGS) (ACDelco #PT2389) |
ST1 (LH6) |
2005-2006 |
01 |
| 017 |
89046633 |
CONNECTOR, INLINE-TO ENG HARN (GT150) (BLACK) (2-WAY MALE W/LEADS) (ACDelco #PT1669) |
ST1 |
2002-2006 |
01 |
| 018 |
19151499 |
CONNECTOR, SEN-WHL SPD (ROUND) (BLACK) (2-WAY MALE) (GT 150 SERIES) (SEALED) (3.682) (ACDelco #PT2267)
| ST1 (06) |
2002-2006 |
02 |
|
| 018 |
19151499 |
CONNECTOR, SEN-WHL SPD (ROUND) (BLACK) (2-WAY MALE) (GT 150 SERIES) (SEALED) (3.682) (ACDelco #PT2267)
| ST1 |
2005-2006 |
02 |
|
