| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15788793 |
MOUNT, ENG (INCLS 2-4, 6, 7) |
S1 (LH6) |
2005-2009 |
01 |
| 001 |
15788794 |
MOUNT, ENG (INCLS 2-4, 6, 7) |
S1 (LH6) |
2005-2009 |
01 |
| 002 |
11517996 |
ГАЙКА, HFH, M10X1.5, 11.2THK, 21.5 O.D., 7111M (PART OF 1)
|
2005-2009 |
08 |
|
| 003 |
|
BRACKET, ENG MT (PART OF 1) |
|
2005-2006 |
|
| 003 |
|
BRACKET, ENG MT (PART OF 1) |
|
2006-2006 |
|
| 004 |
|
SHIELD, ENG MT (PART OF 1) |
|
2005-2006 |
|
| 004 |
|
SHIELD, ENG MT (PART OF 1) |
|
2006-2006 |
|
| 005 |
11519083 |
БОЛТ, HEX W/CON WA, M10X1.5X36, 23.3 THD, 20 OD, 10.9, 7114M, MACH, MAT-PT (ENG MT ENG SI BRKT)
|
2005-2009 |
14 |
|
| 006 |
|
BRACKET, ENG MT (PART OF 1) |
|
2005-2006 |
|
| 006 |
|
BRACKET, ENG MT (PART OF 1) |
|
2006-2006 |
|
| 007 |
|
БОЛТ, ENG MT ENG SI BRKT (PART OF 1) |
|
2005-2006 |
|
| 007 |
|
БОЛТ, ENG MT ENG SI BRKT (PART OF 1) |
|
2006-2006 |
|
| 008 |
15195378 |
SPACER, ENG MT BRKT |
S1 (06) (LH6, LS2) |
2006-2009 |
01 |
| 008 |
15195379 |
SPACER, ENG MT BRKT |
S1 (06) (LH6, LS2) |
2006-2009 |
01 |
| 009 |
15110790 |
SPACER, TRANS SUPT |
S155, 158 |
2005-2006 |
01 |
| 010 |
15195376 |
MOUNT, TRANS |
S1 (06) (LH6, M30, W49, X88, Z88, Z89) (EXC B4U) |
2006-2007 |
01 |
| 011 |
11518388 |
БОЛТ, TRANS MT (M10X1.5X45)
| S155, 158 |
2005-2006 |
04 |
|
| 012 |
11516747 |
ГАЙКА, HEX LOCK W/CON WA, M10X1.5X13.37, 10, 7111M, ALL METAL PREV TORQ (TRANS MT)
|
2005-2009 |
02 |
|
| 013 |
11518726 |
БОЛТ, HFH M14X2X157, 35.7 THD, 30.5 OD, 10.9, 7114M, MACH, CONE-PT (ENG MT FRM SI BRKT)
|
2005-2009 |
06 |
|
