| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
88937088 |
ДВЕРЬ, ПЕРЕДНЯЯ SI (W/O HINGES)
| ST1 (06) |
2002-2009 |
01 |
|
| 002 |
25779163 |
DEFLECTOR, FRT S/D WAT |
ST155 |
2005-2009 |
01 |
| 003 |
15123254 |
SWITCH, O/S R/CON RR VIEW MIR (GRAY) (W/O POWER FOLD) |
ST1 (DK2, DK9, DP2, DS3, X88, 28I) |
2006-2009 |
01 |
| 003 |
15123255 |
SWITCH, O/S R/CON RR VIEW MIR (EBONY) (W/O POWER FOLD) |
ST1 (DK2, DK9, DP2, DS3, X88, 48I) |
2008-2009 |
01 |
| 003 |
15123258 |
SWITCH, O/S RR VIEW MIR FLDG (GRAY) (W/POWER FOLD)
| ST1 (DL2, X88, 28I) |
2005-2009 |
01 |
|
| 003 |
15123259 |
SWITCH, O/S RR VIEW MIR FLDG (EBONY) (W/POWER FOLD)
| ST1 (DL2, X88, 48I) |
2008-2009 |
01 |
|
| 004 |
15239424 |
PANEL, FRT S/D TR (INCLS 5, 7-10) (GRAY) |
ST1 (DR1, X88, 28I) |
2005-2009 |
01 |
| 004 |
25933507 |
PANEL, FRT S/D TR (INCLS 5, 7-10) (GRAY) |
ST1 (DK2, DK9, DL2, DP2, DS3, X88, 28I) |
2006-2009 |
01 |
| 004 |
25933508 |
PANEL, FRT S/D TR (INCLS 5, 7-10) (EBONY)
| ST1 (DK2, DK9, DL2, DP2, DR1, DS3, X88, 48I) |
2006-2009 |
01 |
|
| 005 |
11519031 |
RETAINER, PUSH IN, 19.5X26.1X1.8, ACETAL, NATURAL, FOAM SEALER (PART OF 4)
|
2002-2009 |
08 |
|
| 006 |
15214501 |
BEZEL, FRT S/D I/S HDL (EBONY)
| ST1 (06) (X88, 48I) (EXC AAB) |
2008-2009 |
01 |
|
| 006 |
15214503 |
BEZEL, FRT S/D I/S HDL (EBONY)
| ST1 (06) (AAB, X88, 48I) |
2008-2009 |
01 |
|
| 006 |
25894590 |
BEZEL, FRT S/D I/S HDL (GRAY) |
ST1 (X88, 28I) (EXC AAB) |
2008-2009 |
01 |
| 006 |
25894592 |
BEZEL, FRT S/D I/S HDL (GRAY)
| ST1 (AAB, X88, 28I) |
2008-2009 |
01 |
|
| 007 |
15055841 |
REFLECTOR, FRT S/D WRNG (PART OF 4) |
ST155 |
2005-2009 |
01 |
| 008 |
11609461 |
БОЛТ, HX W/FL WA, M4.2X1.41X16, 9 THD, 12.5 OD, 6010M STL, GMW4205, SELFTA (PART OF 4)
|
2002-2009 |
03 |
|
| 009 |
15109982 |
ARMREST, FRT S/D (PART OF 4) (GRAY) |
ST1 (X88, 28I) |
2005-2009 |
01 |
| 009 |
15109983 |
ARMREST, FRT S/D (PART OF 4) (EBONY) |
ST1 (X88, 48I) |
2005-2009 |
01 |
| 009 |
15109983 |
ARMREST, FRT S/D (PART OF 4) (EBONY) |
ST1 (X88, 28I) |
2007-2009 |
01 |
| 010 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 4)
|
2002-2009 |
02 |
|
| 011 |
11517342 |
БОЛТ, HEX HD, W/FL WA, M6X1X20, 9.53 THD, 17 O.D., P-PT, 9.8, 6280M (FRT S/D T/PNL) |
|
2002-2009 |
04 |
| 012 |
25866999 |
SWITCH, DR LK SI WDO (INCLS 13) (GRAY) |
ST1 (DL2, KA1, X88, 28I) (EXPORT) |
2009-2009 |
01 |
| 012 |
25867000 |
SWITCH, DR LK SI WDO (INCLS 13) (EBONY) (ACDelco #D1457G) |
ST1 (DK2, DP2, DS3, KA1, X88, 48I) |
2006-2009 |
01 |
| 012 |
25867001 |
SWITCH, DR LK SI WDO (INCLS 13) (GRAY) |
ST1 (DK2, DP2, DS3, KA1, X88, 28I) |
2006-2009 |
01 |
| 012 |
25867002 |
SWITCH, DR LK SI WDO (INCLS 13) (EBONY) (ACDelco #D1458G) |
ST1 (DL2, X88, 48I) (EXC KA1) (EXPORT) |
2009-2009 |
01 |
| 012 |
25867003 |
SWITCH, DR LK SI WDO (INCLS 13) (GRAY) |
ST1 (DL2, X88, 28I) (EXC KA1) (EXPORT) |
2009-2009 |
01 |
| 012 |
25867004 |
SWITCH, DR LK SI WDO (INCLS 13) (EBONY) (ACDelco #D1459G) |
ST1 (DK2, DK9, DP2, DR1, X88, 48I) (EXC KA1) |
2006-2009 |
01 |
| 012 |
25867005 |
SWITCH, DR LK SI WDO (INCLS 13) (GRAY) (REQUIRES PROGRAMMING) |
ST1 (DK2, DK9, DP2, DR1, X88, 28I) (EXC KA1) |
2009-2009 |
01 |
| 012 |
25867006 |
SWITCH, DR LK SI WDO (INCLS 13) (EBONY) (ACDelco #D1460G)
| ST1 (DL2, KA1, X88, 48I) (EXPORT) |
2009-2009 |
01 |
|
| 013 |
15748479 |
RETAINER, GARNISH MOLDING TYPE, FITS SLOT 6.0MM, SPR STL, ZC (PART OF 12) |
|
2002-2009 |
03 |
| 014 |
15908702 |
SWITCH, D/SEAT ADJR MEMORY
| ST1 (06) (AAB) |
2005-2009 |
01 |
|
