| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
|
HARNESS, DM LP WRG (INCLS 5, 6) (СМ. ГРУППУ 16.000 ВНУТРЕННЯЯ ОТДЕЛКА - КРЫША И СОЛНЦЕЗАЩИТНЫЙ КОЗЫРЕК FOR DETAILED ILLUSTRATED VIEW) |
|
2006-2008 |
|
| 002 |
15796797 |
АНТЕННА, M/TEL VEH LOC (INCLS 3) (ACDelco #15796797) (WITH BLUE 3-CAVITY CONN) (SEE 15837587 FOR 2ND DES) |
ST1 (UE1) (EXC U2K) (1ST DES) |
2006-2006 |
01 |
| 002 |
15837587 |
АНТЕННА, M/TEL VEH LOC (INCLS 3) (ACDelco #15837587) (WITH TAN 3-CAVITY CONN) (SEE 15796797 FOR 1ST DES) |
ST1 (UE1) (EXC U2K) (2ND DES) |
2006-2006 |
01 |
| 003 |
|
ГАЙКА, M/TEL BASE (PART OF 2) |
|
2006-2008 |
|
| 004 |
15120584 |
COVER, MOBILE TEL XCVR TR (GRAY) |
ST155 (UE1, W49, X88, Z88, Z89, 28I) |
2006-2007 |
01 |
| 004 |
15120585 |
COVER, MOBILE TEL XCVR TR (EBONY) |
ST155 (UE1, 27I, 48I) |
2006-2008 |
01 |
| 005 |
19116071 |
CABLE, M/TEL VEH LOC ANT (PART OF 1) (9.769) (HAS A BLUE 3-CAVITY CONN. FOR 2ND DES SEE 19116072.) |
ST1 (UE1) (1ST DES) |
2006-2006 |
01 |
| 005 |
19116072 |
CABLE, M/TEL VEH LOC ANT (PART OF 1) (9.769) (ACDelco #19116072) (HAS A TAN 3-CAVITY CONN. FOR 1ST DES SEE 19116071.) |
ST1 (UE1) (2ND DES) |
2006-2006 |
01 |
| 006 |
19116072 |
CABLE, M/TEL ANT (PART OF 1) (9.769) (ACDelco #19116072) |
ST1 (DK7, UE1) (EXC CE1, CF5, U42) |
2006-2006 |
01 |
| 007 |
|
MODULE, COMN INTERFACE (W/MOBILE TEL XCVR) |
|
2006-2006 |
|
| 008 |
25886921 |
BRACKET, NAVIGATION CTL PROCESSOR |
ST155 (UE1) |
2006-2008 |
01 |
| 009 |
|
ГАЙКА, M/TEL XCVR BRKT (PART OF 10) |
|
2006-2008 |
|
| 010 |
25849755 |
BRACKET, NAVN RCVR (INCLS 9) |
ST1 (UE1) |
2006-2008 |
01 |
| 011 |
|
БОЛТ, I/S RR VIEW MIR (PART OF 12) |
|
2006-2008 |
|
| 012 |
15144156 |
MIRROR, I/S RR VIEW (INCLS 11) (INSIDE) |
ST1 (06) (UE1, VCG) (EXC DD7, DF5) |
2006-2008 |
01 |
| 012 |
15144157 |
MIRROR, I/S RR VIEW (INCLS 11) (INSIDE) |
ST1 (06) (UE1) (EXC DD7, DF5, VCG) |
2006-2008 |
01 |
| 012 |
15144162 |
MIRROR, I/S RR VIEW (INCLS 11) |
ST1 (06) (DD5, UE1) (EXC VCG) |
2006-2006 |
01 |
| 012 |
15144166 |
MIRROR, I/S RR VIEW (INCLS 11) |
ST1 (06) (DD5, UE1, VCG) |
2006-2006 |
01 |
| 012 |
15237545 |
MIRROR, I/S RR VIEW (INCLS 11) (LT SEN, COMPASS, TEMP, FRT PRESENCE DETECTOR, GPS) |
ST1 (06) (DF5, UE1, VCG) |
2006-2008 |
01 |
| 012 |
15237546 |
MIRROR, I/S RR VIEW (INCLS 11) (LT SEN, COMPASS, TEMP, FRT PASS/CHILD PRESENCE DETECTOR, GPS) |
ST1 (06) (DF5, UE1) (EXC VCG) |
2006-2008 |
01 |
| 012 |
15812021 |
MIRROR, I/S RR VIEW (INCLS 11) |
ST1 (06) (DD7, UE1) (EXC VCG) |
2006-2008 |
01 |
| 012 |
15812022 |
MIRROR, I/S RR VIEW (INCLS 11) |
ST1 (06) (DD7, UE1, VCG) |
2006-2008 |
01 |
| 013 |
20626174 |
BRACKET, I/S RR VIEW MIR (10.187) |
ST1 |
2006-2008 |
01 |
