| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 209 |
17122490 |
LIFTER, VLV (RLR) (NON-ACTIVE FUEL MANAGEMENT LIFTER) (ACDelco #HL124)
| ST1 (LH6) |
2005-2008 |
08 |
|
| 210 |
12571596 |
GUIDE, VLV LFTR (FRT) |
ST1 (LH6) |
2005-2008 |
01 |
| 210 |
12571608 |
GUIDE, VLV LFTR (RR) |
ST1 (LH6) |
2005-2008 |
01 |
| 211 |
12551163 |
БОЛТ, VLV LFTR GDE (M6X1.0X19) |
ST1 (LH6) |
2005-2008 |
04 |
| 212 |
10238852 |
ROD, VLV PUSH
| ST1 (LH6) |
2005-2008 |
16 |
|
| 213 |
10214664 |
ARM, VLV RKR
| ST1 (LH6) |
2005-2008 |
16 |
|
| 214 |
12560961 |
БОЛТ, VLV RKR ARM PIV SUPT (M8X1.25X52.5) |
ST1 (LH6) |
2005-2008 |
16 |
| 215 |
12552203 |
SUPPORT, VLV RKR ARM PIV
| ST1 (LH6) |
2005-2008 |
02 |
|
| 216 |
11562126 |
PLUG, CYL HD CORE HOLE (PART OF 218) (CUP, 32.03X7.88X1.27, S30400 SS PER SAE J405.)
| ST1 (LH6) |
2005-2008 |
04 |
|
| 217 |
12589226 |
ПРОКЛАДКА, CYL HD |
ST1 (LH6) |
2005-2008 |
02 |
| 218 |
12615363 |
HEAD, CYL (INCLS 216) (INCLS GUIDES, SEATS, PLUG) |
ST1 (LH6) |
2005-2008 |
02 |
| 219 |
12571595 |
LIFTER, VLV (ACTIVE FUEL MANAGEMENT LIFTER) (ACDelco #HL178)
| ST1 (LH6) |
2005-2008 |
08 |
|
| 220 |
11571134 |
БОЛТ, CYL HD (M11X2X100) |
ST1 (LH6) |
2005-2008 |
20 |
| 221 |
12558840 |
БОЛТ, CYL HD (M8X1.25X45)
| ST1 (LH6, M30) |
2005-2008 |
10 |
|
| 222 |
12482062 |
SEAL KIT, EXH VLV STEM OIL (22.8MM) (INCLS 8 SEALS)
| ST1 (LH6) |
2005-2008 |
01 |
|
| 222 |
12482063 |
SEAL KIT, INT VLV STEM OIL (SEPARATE SEAL AND (RUBBER COATED) SPRING SHIM) (14.4MM) (INCLS 8 SEALS)
| ST1 (LH6) |
2005-2008 |
01 |
|
| 223 |
12589774 |
ПРУЖИНА, VLV
| ST1 (LH6) |
2005-2008 |
16 |
|
| 224 |
10166344 |
CAP, VLV SPR
| ST1 (LH6) |
2005-2008 |
16 |
|
| 225 |
10166345 |
KEY, VLV STEM
| ST1 (LH6) |
2005-2008 |
16 |
|
| 227 |
12563064 |
КЛАПАН, ВЫПУСКНОЙ (STD)
| ST1 (LH6) |
2005-2008 |
08 |
|
| 228 |
12563063 |
КЛАПАН, ВПУСКНОЙ (STD) |
ST1 (LH6, M30) |
2005-2008 |
08 |
| 229 |
12553191 |
PLUG, CYL HD CORE HOLE (M12X1.5X21) (HEX, SOC) |
ST1 (LH6, M30) |
2005-2008 |
01 |
| 230 |
12570326 |
PIN, CYL HD LOC
| ST1 (LH6) |
2005-2008 |
04 |
|
| 422 |
24100002 |
SEAL, OIL FIL TUBE (O RING) (27.94MM I.D.) (SIZE #320)
| ST1 (LH6) |
2005-2008 |
01 |
|
| 423 |
12574386 |
TUBE, OIL FIL
| ST1 (LH6) |
2005-2008 |
01 |
|
| 424 |
12573337 |
CAP, OIL FIL (SAE 5W30, NON-VENTED, SEAL) (INCLS 450) (ACDelco #FC208)
| ST1 (LH6) |
2005-2008 |
01 |
|
| 450 |
24100002 |
SEAL, OIL FIL CAP (O RING) (PART OF 424) (27.94MM I.D.) (SIZE #320) (1.745)
| ST1 (LH6) |
2005-2008 |
01 |
|
| 504 |
12612045 |
ПРОКЛАДКА, VLV RKR ARM CVR (PART OF 505)
| ST1 (LH6) |
2005-2008 |
02 |
|
| 505 |
12570427 |
COVER, VLV RKR ARM (INCLS 504, 515, 516, 900) (INCLSCOVER, GASKET, BOLT, DEFLECTOR, FITTING) |
ST1 (LH6) |
2005-2008 |
01 |
| 505 |
12582224 |
COVER, VLV RKR ARM (INCLS 504, 515, 516, 900) (INCLSCOVER, GASKET, BOLT, DEFLECTOR, FITTING) |
ST1 (LH6) |
2005-2008 |
01 |
| 515 |
|
GROMMET, CYL HD CVR (PART OF 505, 516) |
|
2005-2008 |
|
| 516 |
12577215 |
БОЛТ, VLV RKR ARM CVR (INCLS 515) (PART OF 505) (M6.0X1.0) (W/GROMMET, SLEEVE) |
ST1 (LH6) |
2005-2008 |
04 |
| 700 |
12594124 |
TUBE, PCV (FRESH AIR TUBE) |
ST1 (LH6) |
2005-2008 |
01 |
| 716 |
12611592 |
TUBE, PCV (DIRTY AIR TUBE)
| ST1 (LH6) |
2005-2008 |
01 |
|
| 720 |
12554211 |
STUD, IGN COIL BRKT (HFH, M6X1X18) (3.330) (ACDelco #12554211) |
ST1 (LH6) |
2005-2008 |
10 |
| 722 |
|
КАТУШКА, ЗАЖИГАНИЯ (СМ. ГРУППУ 02.000 КАТУШКА И МОДУЛЬ ЗАЖИГАНИЯ FOR DETAILED ILLUSTRATED VIEW) |
|
2005-2008 |
|
| 724 |
89018057 |
WIRE, SPLG (*KIT1) (ACDelco #356F)
| ST1 (LH6) |
2005-2008 |
08 |
|
| 725 |
12608814 |
ДАТЧИК, ENG COOL TEMP (2-WAY MALE) (ACDelco #213-4333)
| ST1 (LH6) |
2005-2006 |
01 |
|
| 725 |
12608814 |
ДАТЧИК, ENG COOL TEMP (2-WAY MALE) (1.150) (ACDelco #213-4333)
| ST1 (LH6) |
2005-2006 |
01 |
|
| 726 |
12609877 |
СВЕЧА ЗАЖИГАНИЯ, (GAP 0.040) (ACDelco #41-985) (IRIDIUM)
| ST1 (LH6) |
2005-2008 |
08 |
|
| 900 |
12567915 |
FITTING, PCV (PART OF 505) |
ST1 (LH6) |
2005-2006 |
01 |
| K01 |
89018058 |
WIRE KIT, SPLG (INCLS 724) (INCLS SET OF 8 LEADS) (ACDelco #748RR)
| ST1 (LH6) |
2005-2008 |
01 |
|
