| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
24235619 |
CYLINDER, CLU MAS (INCLS 2-5, 11-14) (W/ HOSE) (202.39MM PUSHROD) |
CK1, 2 (LU3, MG5, TZ0) |
2003-2005 |
01 |
| 001 |
24235619 |
CYLINDER, CLU MAS (INCLS 2-5, 11-14) (W/ HOSE) (202.39MM PUSHROD) |
CK1, 2, 3 (LQ4, LR4, L31, MG5, MW3, M96, TZ0) |
2003-2005 |
01 |
| 002 |
89048534 |
CAP, CLU M/CYL RSVR (PART OF 1) (W/ISO) |
CK1, 2, 3 (M96, TZ0) (EXPORT) |
2003-2007 |
01 |
| 002 |
89048534 |
CAP, CLU M/CYL RSVR (PART OF 1) (W/ISO) |
CK1, 2, 3 (MG5, MW3) |
2003-2007 |
01 |
| 003 |
15027967 |
SWITCH, CLU PED POSN (PART OF 1) (AT MASTER CYL) (ACDelco #D2205C) |
CK1, 2, 3 (M96, TZ0) (EXPORT) |
2003-2007 |
01 |
| 003 |
15027967 |
SWITCH, CLU PED POSN (PART OF 1) (AT MASTER CYL) (ACDelco #D2205C) |
CK1, 2, 3 (MG5, MW3) |
2003-2007 |
01 |
| 004 |
|
PUSHROD, CLU MASTER CYL (PART OF 1) |
|
2003-2005 |
|
| 005 |
12473050 |
BUSHING, CLU M/CYL PUSH ROD (PART OF 1) |
CK1, 2, 3 (M96, TZ0) (EXPORT) |
2003-2007 |
01 |
| 005 |
12473050 |
BUSHING, CLU M/CYL PUSH ROD (PART OF 1) |
CK1, 2, 3 (MG5, MW3) |
2003-2007 |
01 |
| 006 |
|
ГАЙКА, BRK PED BRKT (PART OF 7) |
|
2003-2005 |
|
| 007 |
15713209 |
BRACKET, CLU PED (INCLS 6) (L=45 W=80 H=80) (DASH PANEL) |
CK1 (LU3) |
2003-2007 |
01 |
| 007 |
15713209 |
BRACKET, CLU PED (INCLS 6) (L=45 W=80 H=80) (DASH PANEL) |
CK1, 2, 3 (LQ4, LR4, LLY, L18, L31) |
2005-2006 |
01 |
