| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 007 |
08680027 |
BUSHING, PROP SHF FRT SLIP YOKE (INSIDE DIA 1.506-1.509) (PART OF TRANS CASE) (4.104) |
CK1 (M30) |
2004-2007 |
01 |
| 600 |
08667424 |
ПРУЖИНА, 3RD 4TH CLU BOOST (INCLS RET (2) SPRINGS) (ACDelco #8667424) |
CK1 (M30) |
2004-2007 |
05 |
| 601 |
08642041 |
WASHER, REV INPUT CLU HSG THR (1.52-1.63MM) (4.226) (ACDelco #08642041) |
CK1 (M30) |
2004-2007 |
01 |
| 602 |
24232236 |
BAND, 2-4 (ACDelco #24232236)
| CK1 (M30) |
2004-2007 |
01 |
|
| 603 |
|
BUSHING, REV INPUT CLU HSG FRT (PART OF 605) |
|
2005-2007 |
|
| 605 |
08681295 |
HOUSING, REV INPUT CLU (INCLS 603, 606) (ACDelco #8681295) |
CK1 (M30) |
2004-2007 |
01 |
| 606 |
|
BUSHING, DIR CLU HSG RR (PART OF 605) |
|
2005-2007 |
|
| 607 |
08667841 |
PISTON, REV INPUT CLU (.095 HOLE) (ACDelco #8667841) |
CK1 (M30) |
2004-2007 |
01 |
| 608 |
08683960 |
SEAL KIT, REV INPUT CLU (ACDelco #8683960) |
CK1 (M30) |
2004-2007 |
01 |
| 609 |
08647284 |
ПРУЖИНА, REV INPUT CLU (ACDelco #8647284) |
CK1 (M30) |
2004-2007 |
01 |
| 610 |
08628059 |
RING, REV INPUT CLU SPR RET (*KIT4) (ACDelco #8628059) |
CK1 (M30) |
2004-2007 |
01 |
| 611 |
08663074 |
PLATE, REV INPUT CLU (WAVED) (ACDelco #8663074) |
CK1 (M30) |
2004-2007 |
01 |
| 612 |
08673605 |
PLATE, REV INPUT CLU (ILLUSTRATED AS 612B) (153MM DIA) (FIBER) (*KIT3) (ACDelco #8673605) |
CK1 (M30) |
2004-2007 |
04 |
| 612 |
24205267 |
PLATE, REV INPUT CLU (ILLUSTRATED AS 612A) (1.97MM THICK) (W/HOLES IN TURB PLATES) (STEEL) (ACDelco #24205267) |
CK1 (M30) |
2004-2007 |
04 |
| 613 |
24212463 |
PLATE, REV INPUT CLU BKG (5.787-5.947MM) (ACDelco #24212463) |
CK1 (M30) |
2004-2007 |
01 |
| 613 |
24212464 |
PLATE, REV INPUT CLU BKG (6.518-6.678MM) (ACDelco #24212464) |
CK1 (M30) |
2004-2007 |
01 |
| 613 |
24212465 |
PLATE, REV INPUT CLU BKG (7.409-7.249MM) (ACDelco #24212465) |
CK1 (M30) |
2004-2007 |
01 |
