| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 005 |
24210605 |
SEAL, A/TRNS FLUID PUMP (O RING) (*KIT1, KIT2, KIT3) (ACDelco #24210605)
| CK1, 2, 3 (MT1) |
2001-2007 |
01 |
|
| 201 |
24209839 |
SEAL, T/CV FLUID (EXT BUSH LUBE) (*KIT1, KIT2, KIT3) (ACDelco #24209839) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 202 |
|
BUSHING, T/CV (*KIT3) |
|
2001-2007 |
|
| 203 |
|
BODY, A/TRNS FLUID PUMP (*KIT3) |
|
2001-2007 |
|
| 204 |
|
GEAR, A/TRNS FLUID PUMP DRVN (*KIT3) |
|
2001-2007 |
|
| 205 |
|
GEAR, A/TRNS FLUID PUMP DRV (*KIT3) |
|
2001-2007 |
|
| 206 |
24232405 |
COVER, A/TRNS FLUID PUMP (INCLS 207-217, 221-238) (ACDelco #24232405) |
CK1, 2, 3 (MT1) |
2004-2007 |
01 |
| 207 |
08661701 |
PLUG, A/TRNS FLUID PUMP CVR (PART OF 206) (.263 O.D.) (ACDelco #8661701) |
CK1, 2, 3 (MT1) |
2001-2007 |
05 |
| 208 |
|
ORIFICE, TCC REG VLV FEEDBACK (PART OF 206) |
|
2001-2007 |
|
| 209 |
08681185 |
PLUG, A/TRNS FLUID PUMP CVR (PART OF 206) (EXT BUSH LUBE) (.33 DIA) |
CK1, 2, 3 (MT1) |
2001-2007 |
02 |
| 210 |
|
PLUG, A/TRNS FLUID PUMP CVR (PART OF 206) |
|
2001-2007 |
|
| 211 |
08661838 |
PIN, PRESS REG VLV BORE PLUG (PART OF 206) (ACDelco #8661838) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 211 |
08661838 |
PIN, TCC REG VLV BORE PLUG (PART OF 206) (ACDelco #8661838) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 212 |
24243484 |
PLUG, TCC REG VLV BORE (PART OF 206) (ACDelco #24243484) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 213 |
08678258 |
ПРУЖИНА, TCC REG VLV (PART OF 206) (ACDelco #8678258) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 214 |
08678257 |
VALVE, TCC REG (LIMIT) (PART OF 206) (ACDelco #8678257) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 215 |
08661768 |
PIN, TCC C/VLV SPR (PART OF 206) (ACDelco #8661768) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 216 |
08661767 |
ПРУЖИНА, TCC C/VLV (PART OF 206) (ACDelco #8661767) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 217 |
08661766 |
VALVE, TCC CONT (PART OF 206) (4.265) (ACDelco #8661766) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 218 |
08677571 |
WASHER, OVERRUN CLU HSG THR (BLUE) (.059 THK) (4.226) (ACDelco #8677571) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 218 |
08677572 |
WASHER, OVERRUN CLU HSG THR (RED) (.075 THK) (4.226) (ACDelco #8677572) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 218 |
08677573 |
WASHER, OVERRUN CLU HSG THR (BROWN) (.091 THK) (4.226) (ACDelco #8677573) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 218 |
08677574 |
WASHER, OVERRUN CLU HSG THR (GREEN) (.107 THK) (4.226) (ACDelco #8677574) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 218 |
08677575 |
WASHER, OVERRUN CLU HSG THR (BLACK) (.123 THK) (4.226) (ACDelco #8677575) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 219 |
24205833 |
RING, OVERRUN CLU HSG FLUID SEAL (*KIT1) (ACDelco #24205833) |
CK1, 2, 3 (MT1) |
2001-2007 |
02 |
| 220 |
24206031 |
БОЛТ, A/TRNS FLUID PUMP (W/SEAL) (ACDelco #24206031) |
CK1, 2, 3 (MT1) |
2001-2007 |
07 |
| 221 |
00274267 |
RING, TYPE TA INT RET .000X.68X.037PL (PART OF 206) (ACDelco #274267) |
|
1999-2007 |
01 |
| 223 |
08681070 |
VALVE, TCC SHFT (PART OF 206) (ACDelco #8681070) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 224 |
08681069 |
ПРУЖИНА, TCC SHFT VLV (PART OF 206) (ACDelco #8681069) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 225 |
08682857 |
SEAT, TCC SHFT VLV SPR (PART OF 206) (4.216) (ACDelco #8682857) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 226 |
|
RING, REV BOOST VLV BUSH RET (PART OF 206) |
|
2001-2007 |
|
| 227 |
24202645 |
BUSHING, REV BOOST VLV (USE T/W 24202644 VALVE) (PART OF 206) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 228 |
24202644 |
VALVE, REV BOOST (PART OF 206) (ACDelco #24202644) (USE T/W 24202645 BUSHING) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 229 |
08680548 |
RETAINER, PRESS REG VLV SPR (PART OF 206) (4.216) (ACDelco #8680548) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 230 |
08661798 |
ПРУЖИНА, PRESS REG VLV OTR (PART OF 206) (4.216) (ACDelco #8661798) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 231 |
08680547 |
VALVE, PRESS REG (PART OF 206) (4.216) (ACDelco #8680547) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 232 |
08682855 |
PLUG, PRESS REG VLV BORE (PART OF 206) (4.216) (ACDelco #8682855) |
CK1, 2, 3 (MT1) |
2001-2007 |
02 |
| 233 |
|
BUSHING, TURB SHF FRT (PART OF 206) |
|
2001-2007 |
|
| 234 |
|
BUSHING, TURB SHF RR (PART OF 206) |
|
2001-2007 |
|
| 235 |
|
SHAFT, STAT (PART OF 206) |
|
2001-2007 |
|
| 236 |
|
ORIFICE, PRESS REG VLV FEED (PART OF 206) |
|
2001-2007 |
|
| 237 |
|
ORIFICE, TCC REG VLV FEED (PART OF 206) |
|
2001-2007 |
|
| 238 |
08680551 |
ПРУЖИНА, PRESS REG VLV INR (PART OF 206) (4.218) (ACDelco #8680551) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 239 |
24200357 |
SHIELD, A/TRNS VENT PASG SPH (ACDelco #24200357) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| K01 |
24210954 |
TRANSMISSION KIT, AUTO (SERV OVERHAUL W/PLT, GSKT, SEAL) (INCLS 5, 201, 219) (ACDelco #24210954) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| K02 |
24210955 |
GASKET KIT, A/TRNS SERV (INCLS 5, 201) (ACDelco #24210955) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| K03 |
24211287 |
НАСОС, A/TRNS FLUID (INCLS 5, 201-205) (ACDelco #24211287) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
