| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
12476008 |
FRAME, BK BODY OPG UPR (INCLS 4) (16.160) |
CK1, 2 (06) (E52) |
2005-2006 |
01 |
| 002 |
15134524 |
HINGE, L/GATE |
CK1, 2 (06) (E52) |
2005-2006 |
02 |
| 003 |
15134513 |
LOCATOR, L/GATE HGE |
CK1, 2 (06) (E52) |
2005-2006 |
01 |
| 003 |
15134514 |
LOCATOR, L/GATE HGE |
CK1, 2 (06) (E52) |
2005-2006 |
01 |
| 004 |
|
REINFORCEMENT, L/GATE HGE (BODY SI) (PART OF 1) |
|
2005-2006 |
|
| 005 |
12475571 |
PANEL, BK BODY OPG INR UPR |
CK1, 2 (06) |
2005-2006 |
01 |
| 006 |
11516780 |
ГАЙКА, HEX W/CON WA, M8X1.25, 10THK, 19 O.D., 10, 7111M (L/GATE HGE (BODY SI)) (8.917)
|
2005-2006 |
02 |
|
| 007 |
11570082 |
БОЛТ, HFH, M8X1.25X22, 19 THD, 18 OD, 10.9, GMW3359 (L/GATE HGE (BODY SI)) (ACDelco #11570082)
|
2005-2006 |
04 |
|
| 008 |
15043000 |
PLUG, R/CMPT SILL TR PLT HOLE (38.0 X 17.0 X 18.0MM) (OBLONG) (16.600) |
CK1, 2 (06) |
2005-2005 |
11 |
| 009 |
12475570 |
PANEL, BODY RR INR LWR (16.570) |
CK1, 2 (06) (E52) |
2005-2006 |
02 |
| 009 |
12476006 |
PANEL, BODY RR INR LWR |
CK1, 2 (06) (ZW9) |
2005-2006 |
01 |
| 010 |
12476009 |
SUPPORT, L/GATE STRUT (BODY SI) (INCLS 26) (16.227) |
CK1, 2 (06) (E52) |
2005-2006 |
01 |
| 011 |
15152086 |
STUD, L/GATE STRUT (BODY SI) |
CK1, 2 (06) (E52) |
2005-2006 |
02 |
| 012 |
15120322 |
BRACKET, L/GATE STRUT (BODY SI) |
CK1, 2 (06) (E52) |
2005-2006 |
01 |
| 012 |
15120323 |
BRACKET, L/GATE STRUT (BODY SI) |
CK1, 2 (06) (E52) |
2005-2006 |
01 |
| 013 |
11570082 |
БОЛТ, HFH, M8X1.25X22, 19 THD, 18 OD, 10.9, GMW3359 (L/GATE STRUT SUPT (BODY SI)) (ACDelco #11570082)
|
2005-2006 |
06 |
|
| 014 |
15205398 |
SEAL, BK BODY OPG LWR FRM FIL (TO INTER FLR PNL) |
CK1, 2 (06) |
2005-2006 |
01 |
| 015 |
|
BRACKET, BODY RR MT (PART OF 18) |
|
2005-2006 |
|
| 016 |
|
REINFORCEMENT, BODY MT BRKT (PART OF 18) |
|
2005-2006 |
|
| 017 |
|
BRACKET, BODY RR MT (PART OF 18) |
|
2005-2006 |
|
| 018 |
12476012 |
FRAME, BK BODY OPG LWR (USED AS OUTER) (INCLS 15-17) (RR BODY MT BRACKET COMES WITH THIS РАМА) (16.160) |
CK1, 2 (06) |
2005-2006 |
01 |
| 019 |
15227301 |
PANEL, BK BODY OPG FRM SI FIL LWR |
CK1, 2 (06) |
2005-2006 |
01 |
| 020 |
15195766 |
FILLER, BK BODY OPG FRM SI (USED AS LOWER) |
CK1, 2 (06) |
2005-2006 |
01 |
| 021 |
21996698 |
PANEL, BK BODY OPG FRM SI FIL UPR |
CK1, 2 (06) |
2005-2006 |
01 |
| 022 |
15227302 |
PANEL, BK BODY OPG FRM SI FIL LWR |
CK1, 2 (06) |
2005-2006 |
01 |
| 023 |
15195765 |
FILLER, BK BODY OPG FRM SI (USED AS LOWER) |
CK1, 2 (06) |
2005-2006 |
01 |
| 024 |
15205397 |
SEAL, BK BODY OPG LWR FRM FIL (TO INTER FLR PNL) |
CK1, 2 (06) |
2005-2006 |
01 |
| 025 |
12476010 |
SUPPORT, L/GATE STRUT (BODY SI) (INCLS 26) (16.160) |
CK1, 2 (06) (E52) |
2005-2006 |
01 |
| 026 |
|
SUPPORT, L/GATE STRUT (BODY SI) (PART OF 10, 25) |
|
2005-2005 |
|
| 027 |
21996699 |
PANEL, BK BODY OPG FRM SI FIL UPR |
CK1, 2 (06) |
2005-2006 |
01 |
