| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 530 |
|
ORIFICE, 4TH CLU (*KIT3) |
|
2001-2007 |
|
| 537 |
|
VALVE, OVERRUN CLU BALL CHK (*KIT2) |
|
2001-2007 |
|
| 601 |
08628202 |
BEARING, O/D CARR THR (4.176) (ACDelco #8628202) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 602 |
24234155 |
HOUSING, FWD CLU (INCLS 685) (ACDelco #24234155) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 606 |
24204957 |
PISTON, FWD CLU (ACDelco #24204957) |
CK1, 2, 3 (LQ4, MT1) |
2003-2007 |
01 |
| 607 |
08661764 |
ПРУЖИНА, DIR CLU (ACDelco #8661764) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 607 |
08661764 |
ПРУЖИНА, FWD CLU (ACDelco #8661764) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 608 |
08623105 |
RING, DIR CLU SPR RET (ACDelco #8623105) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 608 |
08623105 |
RING, FWD CLU SPR RET (ACDelco #8623105) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 609 |
24205560 |
PLATE, FWD CLU (WAVED) (12 TOOTH REPLACED 14 TOOTH) (ACDelco #24205560) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 609 |
24205561 |
PLATE, DIR CLU (WAVED) (14 TEETH) (ACDelco #24205561) |
CK1, 2, 3 (MT1) |
2003-2007 |
01 |
| 610 |
08623849 |
PLATE, FWD CLU (FLAT STL) (.0775 THK) (ACDelco #8623849) |
CK1, 2, 3 (MT1) |
2001-2007 |
05 |
| 611 |
24202646 |
PLATE, DIR CLU (FLAT) (FIBER) (*KIT1) (ACDelco #24202646) |
CK1, 2, 3 (MT1) |
2001-2007 |
05 |
| 611 |
24202646 |
PLATE, FWD CLU (FLAT) (FIBER) (*KIT1) (ACDelco #24202646) |
CK1, 2, 3 (MT1) |
2001-2007 |
05 |
| 612 |
08624196 |
WASHER, FWD CLU HSG THR (ACDelco #8624196) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 613 |
08677091 |
HUB, FWD CLU (ACDelco #8677091) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 614 |
08624781 |
WASHER, DIR CLU HSG THR (ACDelco #8624781) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 615 |
08661837 |
HUB, DIR CLU (ACDelco #8661837) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 616 |
08623112 |
RING, DIR CLU BKG PLT RET (6.24OD X .062) (ACDelco #8623112) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 616 |
08623112 |
RING, DIR CLU HUB RET (6.24OD X .062) (ACDelco #8623112) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 617 |
08675557 |
PLATE, DIR CLU BKG (ACDelco #8675557) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 618 |
08625197 |
PLATE, DIR CLU (.0915 THK) (ACDelco #8625197) |
CK1, 2, 3 (MT1) |
2001-2007 |
05 |
| 619 |
24204961 |
PISTON, DIR CLU (ACDelco #24204961) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 622 |
|
SEAL, CLU CTR (*KIT1) |
|
2001-2007 |
|
| 623 |
|
HOUSING, DIR CLU (*KIT2) |
|
2001-2007 |
|
| 624 |
08633173 |
SPRAG, INTER CLU (*KIT6) (ACDelco #8633173) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 625 |
|
RACE, INPUT CLU RLR OTR (*KIT6) |
|
2001-2007 |
|
| 626 |
08627334 |
RETAINER, INTER CLU RLR (*KIT6) (ACDelco #8627334) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 627 |
08675558 |
RING, INTER CLU RLR RET RET (*KIT2, KIT6) (4.167) (ACDelco #8675558) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 628 |
24228967 |
BAND, MAN 2-1 (ACDelco #24228967) |
CK1, 2, 3 (MT1) |
2005-2007 |
01 |
| 629 |
08623149 |
RING, INTER CLU BKG PLT RET (4.164) (ACDelco #8623149) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 630 |
24205827 |
PLATE, INTER CLU BKG (ACDelco #24205827) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 631 |
24202966 |
PLATE, INTER CLU (47 TEETH) (*KIT1) (4.164) (ACDelco #24202966) |
CK1, 2, 3 (MT1) |
2001-2007 |
04 |
| 632 |
08675522 |
PLATE, INTER CLU (22 TEETH) (ACDelco #8675522) |
CK1, 2, 3 (MT1) |
2001-2007 |
04 |
| 633 |
08623437 |
RING, CTR SUPT RET (ACDelco #8623437) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
| 634 |
08623153 |
RING, INTER CLU SPR RET (SNAP) (ACDelco #8623153) |
CK1, 2, 3 (MT1) |
2001-2007 |
01 |
