| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15791230 |
INDICATOR, TRANS FLUID LVL (874MM)
| CK1, 2, 3 (MN8, MT1, M30, M32, M70) |
2006-2006 |
01 |
|
| 002 |
15832205 |
TUBE, TRANS FLUID FIL |
CK1, 2, 3 (MN8, MT1) |
2002-2006 |
01 |
| 002 |
25789571 |
TUBE, TRANS FLUID FIL |
CK1 (M30, M32, M70) |
2006-2007 |
01 |
| 003 |
11516780 |
ГАЙКА, HEX W/CON WA, M8X1.25, 10THK, 19 O.D., 10, 7111M (TRANS FLUID FIL TUBE) (8.917)
|
1999-2007 |
01 |
|
| 004 |
01259475 |
SEAL, TRANS FLUID FIL TUBE (ACDelco #1259475) |
CK1, 2, 3 (MN8, MT1, M30, M32, M33, M70) |
2006-2006 |
01 |
| 005 |
15820590 |
HOSE, TRANS VENT |
CK1, 2, 3 (MN8, MT1, M30, M32, M33, M70) |
2006-2006 |
01 |
| 006 |
15769074 |
BRACKET, TRANS VENT HOSE CLIP (4.510) |
CK1, 2, 3 (MN8, MT1) |
2002-2006 |
01 |
| 006 |
15854320 |
BRACKET, TRANS VENT HOSE CLIP |
CK1 (M30, M32, M33, M70) |
2006-2007 |
01 |
| 007 |
11514596 |
ГАЙКА, HFH, M8X1.25, 17.9 OD, 738 THK, 13MM HEX, 10, ZF (8.915) (ACDelco #11514596)
|
1999-2007 |
01 |
|
| 008 |
15045202 |
SHIELD, TRANS HT |
CK1 (M30, M33) |
2004-2007 |
01 |
| 008 |
15045202 |
SHIELD, TRANS HT |
CK1 (M70) |
2006-2007 |
01 |
| 009 |
15029928 |
БОЛТ, TRANS H/SHLD (M8X1.25X12) |
CK1 (M30, M33) |
2004-2007 |
02 |
| 009 |
15029928 |
БОЛТ, TRANS H/SHLD (M8X1.25X12) |
CK1 (M70) |
2006-2007 |
02 |
