| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
12548430 |
TUBING, BRK, 1/4 X 16 FT ROLL, STL (RR BRK FRT)
|
2003-2006 |
AR |
|
| 002 |
11588804 |
NUT-TUBE, 7/16-24X0.36, 0.30 THD, 0.56 LONG, 1/4 TUBE, SAE 1008 STL, GMW (RR BRK FRT PIPE) |
|
2006-2006 |
01 |
| 003 |
15086468 |
CLIP, RR BRK FRT PIPE (HOLDS (2) 06.35 TUBES) |
CK157 (06) (JL4) |
2003-2006 |
01 |
| 004 |
15071414 |
CLIP, RR BRK FRT PIPE |
CK157 (06) (JL4) |
2003-2006 |
03 |
| 005 |
15183048 |
CLIP, RR BRK FRT PIPE |
CK157 (06) (JL4) |
2003-2006 |
01 |
| 006 |
15091486 |
CLIP, BRK PIPE |
CK157 (06) (JL4) |
2003-2006 |
01 |
| 007 |
11588803 |
ГАЙКА, RR BRK PIPE (1/2-20X.40, .32 THD) (INVERTED FLARED TUBE) (.62 LONG, 1/4 TUBE)
| CK1, 2, 3 |
2003-2006 |
01 |
|
| 008 |
|
MODULE, ELEK BRK CONT (СМ. ГРУППУ 04.000 BRAKE MODULE FOR DETAILED ILLUSTRATED VIEW) |
|
2003-2006 |
|
| 009 |
|
PIPE, RR BRK C/OVR (СМ. ГРУППУ 04.000 BRAKE LINES-REAR FOR DETAILED ILLUSTRATED VIEW) |
|
2003-2006 |
|
