| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
11515704 |
БОЛТ, HEX, W/CON WA, M6X1X16, 13THD, 17 O.D., MACH, 9.8, 7111M (I/P INFL RST MDL)
|
2004-2005 |
04 |
|
| 002 |
10399600 |
MODULE, I/P INFL RST (CODE 9600, 0398) (PEWTER) |
CK1, 2 (06) (Y91, 92I) (EXC WSD) |
2005-2005 |
01 |
| 002 |
10399601 |
MODULE, I/P INFL RST (CODE 9601, 0399, 7353, 2350) (NEUTRAL) |
CK1 (52I) |
2005-2005 |
01 |
| 002 |
10399602 |
MODULE, I/P INFL RST (CODE 9602, 0400, 2351, 7354) (PEWTER) (4-WAY CONNECTOR)
| CK1, 2 (06) (92I) (EXC Y91) |
2004-2005 |
01 |
|
| 002 |
10399603 |
MODULE, I/P INFL RST (SHALE) |
CK1, 2 (06) (Y91, 15I) (EXC ULT, WSD) |
2005-2005 |
01 |
| 003 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 4)
|
2004-2005 |
04 |
|
| 004 |
15207926 |
COMPARTMENT, I/P (USED ON RH SIDE OF I/P CLUSTER FULL STOR CMPT) (INCLS 3, 5) |
CK1, 2, 3 |
2004-2005 |
01 |
| 005 |
15756881 |
MAT, I/P CSTR COMPT (PART OF 4) (EBONY) |
CK1, 2, 3 |
2004-2005 |
01 |
| 006 |
17988488 |
ГАЙКА, I/P CARR (SILVER) (4.2 X 1.41) (PUSH-IN FOR 12MM SQ HOLE) (10.252) |
CK1, 2, 3 |
2004-2005 |
AR |
| 007 |
|
RADIO, AM/FM STEREO CLK CD PLYR (СМ. ГРУППУ 09.000 АУДИОСИСТЕМА/ПЕРЕДНЯЯ FOR DETAILED ILLUSTRATED VIEW) |
|
2004-2005 |
|
| 007 |
|
RADIO, AM/FM STEREO CLK (СМ. ГРУППУ 09.000 АУДИОСИСТЕМА/ПЕРЕДНЯЯ FOR DETAILED ILLUSTRATED VIEW) |
|
2004-2005 |
|
| 008 |
11589012 |
БОЛТ, HWH, M4.2X1.41X25, 16.4 THD, 12.5 OD, GM6010M STL, GMW4205 (RDO) (9.665)
|
2004-2005 |
03 |
|
| 009 |
15069408 |
ALARM, ST BELT IGN KEY LPS T/SIG |
CK1, 2, 3 (9R3) |
2004-2005 |
01 |
| 009 |
15069408 |
ALARM, ST BELT IGN KEY LPS T/SIG (2.195) |
CK1, 2, 3 (9R3) |
2004-2005 |
01 |
| 009 |
15069408 |
ALARM, ST BELT IGN KEY LPS T/SIG (2.195) |
CK1, 2, 3 (9R3) |
2004-2005 |
01 |
| 010 |
15177695 |
COMPARTMENT, I/P CTR |
CK1, 2, 3 (9R3) |
2004-2005 |
01 |
| 011 |
11589012 |
БОЛТ, HWH, M4.2X1.41X25, 16.4 THD, 12.5 OD, GM6010M STL, GMW4205 (I/P CTR) (9.665)
|
2004-2005 |
03 |
|
| 012 |
15042047 |
CLIP, I/P CSTR TR PLT BZL (PART OF 13) (STEEL)
| CK1, 2, 3 |
2004-2005 |
11 |
|
| 013 |
15804934 |
BEZEL, I/P CSTR TR PLT (INCLS 12, 14) (NEUTRAL) |
CK1, 2 (06) (52I) (EXC Y91) |
2004-2005 |
01 |
| 013 |
15804935 |
BEZEL, I/P CSTR TR PLT (INCLS 12, 14) (PEWTER)
| CK1, 2 (06) (92I) (EXC Y91) |
2004-2005 |
01 |
|
| 014 |
25603681 |
INSULATOR, I/P CSTR TR PLT (PART OF 13) (BLACK/RUBBER) |
CK1, 2, 3 |
2004-2005 |
AR |
| 015 |
11589012 |
БОЛТ, HWH, M4.2X1.41X25, 16.4 THD, 12.5 OD, GM6010M STL, GMW4205 (HTR A/C CONT) (9.665)
|
2004-2005 |
02 |
|
| 016 |
|
CONTROL, HTR (СМ. ГРУППУ 08.000 HEATER CONTROL ASM FOR DETAILED ILLUSTRATED VIEW) |
|
2004-2005 |
|
