| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
10394623 |
STEP, ASST (INCLS 2, 7, 8)
| CK157 (06) (BVE, X88, Z88) |
2005-2006 |
01 |
|
| 001 |
10394624 |
STEP, ASST (INCLS 2, 7, 8)
| CK157 (06) (BVE, X88, Z88) |
2005-2006 |
01 |
|
| 002 |
88961653 |
ГАЙКА, ASST STEP BRKT (INSERT) (PART OF 1) (M12X1.5X11.69, M6X1X11.69, 360 BRASS) |
CK1, 2 (06) (BVE, X88, Z88) |
2005-2006 |
10 |
| 003 |
11609997 |
БОЛТ, ASST STEP FRT EXTN
| CK1, 2 (06) (BVE) |
2005-2006 |
02 |
|
| 004 |
11519742 |
БОЛТ, WASHER, M8X1.25X40, 33.4 THD, 39 OD, 9.8, 7114M, 2.5-3.5 THK FL WA (ASST STEP)
|
2005-2006 |
02 |
|
| 005 |
10380604 |
EXTENSION, ASST STEP FRT
| CK1, 2 (06) (BVE, X88, Z88) |
2005-2006 |
01 |
|
| 005 |
10380605 |
EXTENSION, ASST STEP FRT
| CK1, 2 (06) (BVE, X88, Z88) |
2005-2006 |
01 |
|
| 006 |
11609733 |
БОЛТ, HEX W/CON WA, M8X1.25X30, 20 THD, 24 OD, 10.9, GMW4205, MAT POINT (ASST STEP)
|
2005-2006 |
12 |
|
| 007 |
11609997 |
БОЛТ, ASST STEP (PART OF 1)
| CK1, 2 (06-36) |
2005-2006 |
08 |
|
| 008 |
15203597 |
BRACKET, ASST STEP (PART OF 1)
| CK1, 2 (06) (BVE, X88, Z88) |
2005-2006 |
08 |
|
| 009 |
11514519 |
ГАЙКА, HEX W/23.75 OD CON WA, M8X1.25, 7.32THK, 9, PZOR (ASST STEP)
|
2005-2006 |
04 |
|
| 010 |
03540325 |
STUD, ASST STEP (9.173) |
CK1, 2 (06) (ARL, MSL) |
2005-2006 |
04 |
