| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
20960665 |
RESTRAINT, R/SEAT HD (EBONY) |
CK107, 109, 2 (06) (AM8, 193) (EXC KB6, Y91) |
2011-2013 |
02 |
| 001 |
20960666 |
RESTRAINT, R/SEAT HD (CASHMERE) |
CK107, 109, 2 (06) (AM8, 333) (EXC KB6, Y91) |
2011-2013 |
02 |
| 001 |
20960667 |
RESTRAINT, R/SEAT HD (TITANIUM) |
CK107, 109, 2 (06) (AM8, 833) (EXC KB6, Y91) |
2011-2013 |
02 |
| 002 |
15279353 |
GUIDE, R/SEAT H/RST (TITANIUM) (W/O BUTTON) |
CK1, 2, 3 (83I) |
2009-2013 |
02 |
| 002 |
25851751 |
GUIDE, R/SEAT H/RST (COCOA) (W/O BUTTON) |
CK1 (06-36) (41I) |
2009-2013 |
02 |
| 002 |
15279347 |
GUIDE, R/SEAT H/RST (EBONY) (W/BUTTON) |
CK1, 2 (06) (19I) |
2009-2013 |
02 |
| 002 |
20912677 |
GUIDE, R/SEAT H/RST (COCOA) (W/BUTTON) |
CK1 (06) (AM8, 41I) |
2009-2013 |
02 |
| 002 |
20912675 |
GUIDE, R/SEAT H/RST (CASHMERE) (W/BUTTON) |
CK1, 2 (06-36) (33I) |
2009-2013 |
02 |
| 002 |
20912675 |
GUIDE, R/SEAT H/RST (CASHMERE) (W/BUTTON) |
CK1, 2 (06-36) (39I) |
2009-2013 |
02 |
| 002 |
20912679 |
GUIDE, R/SEAT H/RST (EBONY) (W/O BUTTON) |
CK1, 2 (06) (AM8, 19I) |
2009-2013 |
02 |
| 002 |
20912680 |
GUIDE, R/SEAT H/RST (CASHMERE) (W/O BUTTON) |
CK1, 2 (06) (33I, 39I) |
2009-2013 |
02 |
| 002 |
20912676 |
GUIDE, R/SEAT H/RST (TITANIUM) (W/BUTTON) |
CK1, 2 (06) (83I) |
2009-2013 |
02 |
| 003 |
15269763 |
FRAME, R/SEAT BK |
CK1, 2 (06) (AM8) |
2009-2013 |
01 |
| 004 |
11562378 |
BOLT, HFH, M10X1.5X30, 18 THD, 22.3 OD, 10.9, GMW3359, W/ADH GM6175M (R/SEAT LAT) |
|
2009-2013 |
12 |
| 005 |
25784336 |
RETAINER, R/SEAT BK OPG FIN CVR (PUSH IN) (16.720) |
CK1, 2 (06) (AM8, HP2) |
2009-2013 |
12 |
| 006 |
11570116 |
SCREW, PAN HD, M6X1X10, 10 THD, 12 OD, STL SAE J1237, S424, TAPTITE ITE (R/SEAT LAT FIN CVR) (8.913) |
|
2009-2013 |
07 |
| 007 |
25816481 |
PANEL, R/SEAT CUSH TR (EBONY) (I/B INNER) |
CK107 (06) (AM8, HP2, 194, 197) |
2009-2013 |
01 |
| 007 |
25816481 |
PANEL, R/SEAT CUSH TR (EBONY) (I/B INNER) |
CK107 (06) (AM8, HP2, 193) |
2009-2013 |
01 |
| 007 |
25816481 |
PANEL, R/SEAT CUSH TR (EBONY) (I/B INNER) |
CK107 (06) (AM8, HP2, 195) |
2009-2013 |
01 |
| 007 |
25816482 |
PANEL, R/SEAT CUSH TR (CASHMERE) (I/B INNER) |
CK107 (06) (AM8, HP2, 333, 394, 397) |
2009-2013 |
01 |
| 007 |
25816483 |
PANEL, R/SEAT CUSH TR (TITANIUM) (I/B INNER) |
CK107 (06) (AM8, HP2, 833) |
2009-2013 |
01 |
| 008 |
25816411 |
LATCH, R/SEAT BK (INBOARD) |
CK107 (06) (AM8, HP2) |
2009-2013 |
01 |
| 009 |
20963265 |
KNOB, R/SEAT LAT (EBONY) (INNER) |
CK1, 2 (06) |
2011-2013 |
02 |
| 010 |
20761401 |
PANEL, R/SEAT CUSH TR (INCLS 29) (EBONY) (I/B INNER COVER) |
CK107 (06) (AM8, HP2, 193) |
2009-2013 |
01 |
| 010 |
20761401 |
PANEL, R/SEAT CUSH TR (INCLS 29) (EBONY) (I/B INNER COVER) |
CK107 (06) (AM8, HP2, 194, 197) |
2009-2013 |
01 |
| 010 |
20761401 |
PANEL, R/SEAT CUSH TR (INCLS 29) (EBONY) (I/B INNER COVER) |
CK1 (06) (AM8, HP2, 195) |
2009-2013 |
01 |
| 010 |
20761402 |
PANEL, R/SEAT CUSH TR (INCLS 29) (CASHMERE) (I/B INNER COVER) |
CK107 (06) (AM8, HP2, 333, 394, 397) |
2009-2013 |
01 |
| 010 |
20761403 |
PANEL, R/SEAT CUSH TR (INCLS 29) (TITANIUM) (I/B INNER COVER) |
CK107 (06) (AM8, HP2, 833) |
2009-2013 |
01 |
| 011 |
19121596 |
BELT KIT, R/SEAT (BKL SI) (SINGLE BKL) (TITANIUM) |
CK1, 2 (06) (AM8, 83I) |
2009-2013 |
01 |
| 011 |
19121595 |
BELT KIT, R/SEAT (BKL SI) (CASHMERE) |
CK1, 2 (06) (AM8, 33I, 39I) |
2009-2013 |
01 |
| 011 |
19121593 |
BELT KIT, R/SEAT (BKL SI) (SINGLE BKL) (EBONY) |
CK1, 2 (06) (AM8, 19I) |
2009-2013 |
01 |
| 012 |
11570520 |
BOLT, R/SEAT LAT (M12X1.75X64) |
CK1, 2 (06) (AM8, HP2) |
2009-2013 |
02 |
| 013 |
25816412 |
LATCH, R/SEAT BK (INBOARD FLOOR) |
CK107 (06) (AM8, HP2) |
2009-2013 |
01 |
| 014 |
11562384 |
NUT, HFH, M4X.7 THD, 4.75 THK, 10.5 OD, GM510M (9)STL, GM4435M-CODE A (R/SEAT FLR FIL T/PNL) |
|
2009-2013 |
02 |
| 015 |
22772283 |
PANEL, R/SEAT CUSH TR (EBONY) (FLOOR LATCH 40% RR CTR) |
CK1 (06) (AM8, HP2, 19I) |
2012-2013 |
01 |
| 015 |
22772284 |
PANEL, R/SEAT CUSH TR (CASHMERE) (FLOOR LATCH 40% RR CTR) |
CK1 (06) (AM8, HP2, 33I, 39I) |
2012-2013 |
01 |
| 015 |
22772401 |
PANEL, R/SEAT CUSH TR (TITANIUM) (FLOOR LATCH 40% RR CTR) |
CK107 (06) (AM8, HP2, 833) |
2012-2013 |
01 |
| 016 |
25944145 |
RISER, R/SEAT |
CK107 (06) (AM8, HP2) |
2009-2013 |
01 |
| 017 |
20825904 |
RETAINER, R/SEAT CUSH SI FAC (EBONY) |
CK107 (06) (AM8, HP2, 19I) |
2009-2013 |
01 |
| 017 |
20825905 |
RETAINER, R/SEAT CUSH SI FAC (CASHMERE) |
CK107 (06) (AM8, HP2, 33I, 39I) |
2009-2013 |
01 |
| 017 |
20825906 |
RETAINER, R/SEAT CUSH SI FAC (TITANIUM) |
CK107 (06) (AM8, HP2, 83I) |
2009-2013 |
01 |
| 017 |
20825907 |
RETAINER, R/SEAT CUSH SI FAC (COCOA) |
CK1 (06) (AM8, HP2, 41I) |
2009-2013 |
01 |
| 018 |
11562380 |
BUSHING, R/SEAT HGE |
CK1, 2 (06) (AM8) |
2009-2013 |
08 |
| 019 |
15275903 |
SPRING, R/SEAT RECL (MANDREL) |
CK1, 2 (06) (AM8) |
2009-2013 |
02 |
| 020 |
25816414 |
SPRING, R/SEAT RECL |
CK1 (06) (AM8, HP2) |
2009-2013 |
02 |
| 022 |
15275914 |
CABLE, R/SEAT LAT (FLOOR LATCH) |
CK1, 2 (06) (AM8) |
2009-2013 |
02 |
| 023 |
25816415 |
CABLE, R/SEAT LAT (OUTBOARD MASTER SYNC) |
CK107 (06) (AM8, HP2) |
2009-2013 |
01 |
| 024 |
25816416 |
CABLE, R/SEAT LAT (INBOARD) (INBOARD MASTER SYNC) |
CK1, 2 (06) (AM8, HP2) |
2009-2013 |
01 |
| 025 |
11562379 |
BOLT, R/SEAT HGE (M10X1.5X92) |
CK1, 2 |
2009-2013 |
02 |
| 026 |
25816485 |
PANEL, R/SEAT CUSH TR (EBONY) (HINGE COVER) |
CK107 (06) (AM8, HP2, 193) |
2009-2013 |
02 |
| 026 |
25816485 |
PANEL, R/SEAT CUSH TR (EBONY) (HINGE COVER) |
CK1 (06) (AM8, HP2, 194) |
2009-2013 |
02 |
| 026 |
25816485 |
PANEL, R/SEAT CUSH TR (EBONY) (HINGE COVER) |
CK107 (06) (AM8, HP2, 195) |
2009-2013 |
02 |
| 026 |
25816486 |
PANEL, R/SEAT CUSH TR (CASHMERE) (HINGE COVER) |
CK107 (06) (AM8, HP2, 333, 394, 397) |
2009-2013 |
02 |
| 026 |
25816487 |
PANEL, R/SEAT CUSH TR (TITANIUM) (HINGE COVER) |
CK107 (06) (AM8, HP2, 833) |
2009-2013 |
02 |
| 027 |
20761387 |
FRAME, R/SEAT CUSH (FOR 2008 EARLY 2009 VEHICLES IT MAY BE NECESSARY TO CUT A SLIT IN THE SEAT COVER FOR THE BRACKET) |
CK107 (06) (AM8, HP2) |
2009-2013 |
01 |
| 029 |
|
RETAINER, R/SEAT FLR FIL T/PNL (PART OF 10, 30) |
|
2009-2013 |
|
| 030 |
25816465 |
PANEL, R/SEAT CUSH TR (INCLS 29) (EBONY) (SIDE SHIELD OUTER) |
CK107 (06) (AM8, HP2, 193) |
2009-2013 |
01 |
| 030 |
25816465 |
PANEL, R/SEAT CUSH TR (INCLS 29) (EBONY) (SIDE SHIELD OUTER) |
CK1 (06) (AM8, HP2, 194, 197) |
2009-2013 |
01 |
| 030 |
25816465 |
PANEL, R/SEAT CUSH TR (INCLS 29) (EBONY) (SIDE SHIELD OUTER) |
CK1 (06) (AM8, HP2, 195) |
2009-2013 |
01 |
| 030 |
25816466 |
PANEL, R/SEAT CUSH TR (INCLS 29) (CASHMERE) (SIDE SHIELD OUTER) |
CK107 (06) (AM8, HP2, 333, 394, 397) |
2009-2013 |
01 |
| 030 |
25816467 |
PANEL, R/SEAT CUSH TR (INCLS 29) (TITANIUM) (SIDE SHIELD OUTER) |
CK107 (06) (AM8, HP2, 833) |
2009-2013 |
01 |
| 031 |
15279429 |
HANDLE, R/SEAT RECL (INCLS 32) (TITANIUM) |
CK1, 2 (06) (83I) |
2009-2013 |
01 |
| 031 |
25858446 |
HANDLE, R/SEAT RECL (INCLS 32) (COCOA) |
CK1 (06) (AM8, 41I) |
2009-2013 |
01 |
| 031 |
15279419 |
HANDLE, R/SEAT RECL (INCLS 32) (EBONY) |
CK1, 2 (06) (19I) |
2009-2013 |
01 |
| 031 |
15279420 |
HANDLE, R/SEAT RECL (INCLS 32) (CASHMERE) |
CK1, 2 (06) (33I) |
2009-2013 |
01 |
| 031 |
15279420 |
HANDLE, R/SEAT RECL (INCLS 32) (CASHMERE) |
CK1 (06) (39I) |
2009-2013 |
01 |
| 032 |
|
RETAINER, R/SEAT ADJR RLR (PART OF 31) |
|
2009-2013 |
|
| 033 |
25816401 |
LATCH, R/SEAT BK (OUTBOARD) |
CK107 (06) (AM8, HP2) |
2009-2013 |
01 |
| 034 |
25816469 |
PANEL, R/SEAT CUSH TR (EBONY) (O/B INNER) |
CK107 (06) (AM8, HP2, 193) |
2009-2013 |
01 |
| 034 |
25816469 |
PANEL, R/SEAT CUSH TR (EBONY) (O/B INNER) |
CK1 (06) (AM8, HP2, 194, 197) |
2009-2013 |
01 |
| 034 |
25816469 |
PANEL, R/SEAT CUSH TR (EBONY) (O/B INNER) |
CK1 (06) (AM8, HP2, 195) |
2009-2013 |
01 |
| 034 |
25816470 |
PANEL, R/SEAT CUSH TR (CASHMERE) (O/B INNER) |
CK107 (06) (AM8, HP2, 333, 394, 397) |
2009-2013 |
01 |
| 034 |
25816471 |
PANEL, R/SEAT CUSH TR (TITANIUM) (O/B INNER) |
CK107 (06) (AM8, HP2, 833) |
2009-2013 |
01 |
| 035 |
15824761 |
HEATER, R/SEAT CUSH |
CK1, 2 (06) (KA6) |
2009-2013 |
01 |
| 036 |
25816418 |
PAD, R/SEAT CUSH |
CK107 (06) (AM8, HP2) |
2009-2013 |
01 |
| 037 |
25816429 |
COVER, R/SEAT CUSH (EBONY) |
CK107 (06) (AM8, HP2, 193) |
2009-2013 |
01 |
| 037 |
25816431 |
COVER, R/SEAT CUSH (TITANIUM) |
CK107 (06) (AM8, HP2, 833) |
2009-2013 |
01 |
| 037 |
25816430 |
COVER, R/SEAT CUSH (CASHMERE) |
CK107 (06) (AM8, HP2, 333) |
2009-2013 |
01 |
| 038 |
15865525 |
COVER, R/SEAT BK (EBONY) |
CK1, 2 (06) (AM8, 193) (EXC KB6) |
2009-2013 |
01 |
| 038 |
15865526 |
COVER, R/SEAT BK (CASHMERE) |
CK1, 2 (06) (AM8, 333) (EXC KB6) |
2009-2013 |
01 |
| 038 |
15865527 |
COVER, R/SEAT BK (TITANIUM) |
CK1, 2 (06) (AM8, 833) (EXC KB6) |
2009-2013 |
01 |
| 039 |
15291598 |
PAD, R/SEAT BK |
CK1, 2 (06) (AM8) |
2009-2013 |
01 |
