| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15792635 |
CALIPER, RR BRK (INCLS 2-8) (INCLS CALIPER ATTACH BOLTS) (4.667) (ACDelco #15792635) |
CK1 (JD9, J92) |
2010-2013 |
01 |
| 001 |
15792636 |
CALIPER, RR BRK (INCLS 2-8) (INCLS CALIPER ATTACH BOLTS) (4.667) (ACDelco #15792636) |
CK1 (JD9, J92) |
2010-2013 |
01 |
| 002 |
25823358 |
BOLT, RR BRK CLPR GDE PIN (PART OF 1) (*KIT1, KIT3) |
CK1 |
2007-2013 |
04 |
| 003 |
|
SEAL, RR BRK CLPR BLEDR VLV (O RING) (PART OF 1) (*KIT2) |
|
2007-2013 |
|
| 004 |
|
VALVE, RR BRK CLPR BLEDR (PART OF 1) (*KIT2) |
|
2007-2013 |
|
| 005 |
|
COVER, RR BRK BLEDR BOLT (PART OF 1) (*KIT2) |
|
2007-2013 |
|
| 006 |
|
SEAL, RR BRK CLPR PSTN (PART OF 1) |
|
2007-2013 |
|
| 007 |
|
PISTON, RR BRK CLPR (PART OF 1) |
|
2007-2013 |
|
| 008 |
|
BOOT, RR BRK CLPR PSTN (PART OF 1) |
|
2007-2013 |
|
| 009 |
|
BOOT, RR BRK CLPR GDE PIN (*KIT1) |
|
2007-2013 |
|
| 010 |
|
PIN, RR BRK CLPR GDE (*KIT1) |
|
2007-2013 |
|
| 011 |
|
PAD, RR DISC BRK INR (*KIT3) |
|
2007-2013 |
|
| 012 |
15265833 |
BRACKET, RR BRK CLPR |
CK1 |
2009-2013 |
02 |
| 013 |
|
SHIM, RR BRK CLPR MT PLT (*KIT1, KIT3) |
|
2007-2013 |
|
| 014 |
|
PAD, RR DISC BRK OTR (*KIT3) |
|
2007-2013 |
|
| K01 |
15792650 |
PIN KIT, RR BRK CLPR GDE (INCLS 2, 9, 10, 13) (ACDelco #15792650) |
CK1 |
2007-2013 |
02 |
| K02 |
88967108 |
VALVE KIT, RR BRK BLEDR (INCLS 3-5) (ACDelco #88967108) |
CK1 |
2009-2013 |
02 |
| K03 |
25949454 |
PAD KIT, RR DISC BRK (INCLS 2, 11, 13, 14) (ACDelco #171-0999) |
CK1 (06-36) |
2010-2013 |
01 |
