| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15879113 |
VALVE, BRK PRESS MOD (INCL 2-5, 20-23) |
CK107 (06) (J92, X88, Z88) |
2008-2008 |
01 |
| 002 |
|
SEAL, BRK PRESS MOD VLV FLTR (PART OF 1) |
|
2008-2008 |
|
| 003 |
|
FILTER, BRK PRESS MOD VLV (PART OF 1) |
|
2008-2008 |
|
| 004 |
15879115 |
ACCUMULATOR, P/B BOOS PUMP FLUID (PART OF 1) |
CK107 (06) (J92, X88, Z88) |
2008-2008 |
01 |
| 005 |
15879116 |
SEAL, P/B BOOS PUMP FLUID ACCUM (O RING) (PART OF 1) (TWO-MODE HYBRID) |
CK107 (06) (J92, X88, Z88) |
2008-2008 |
01 |
| 006 |
25808788 |
BRACKET, BRK PRESS MOD VLV LWR |
CK107 (06) (J92, X88, Z88) |
2008-2008 |
01 |
| 007 |
15297115 |
INSULATOR KIT, BRK PRESS MOD VLV (INCLS 12, 13) |
CK1 (06-36) |
2008-2008 |
01 |
| 007 |
25810186 |
INSULATOR KIT, BRK PRESS MOD VLV (INCLS 12, 13) (SCB HCU MOUNTING KIT) |
CK1 (J92) |
2008-2008 |
01 |
| 008 |
11589407 |
БОЛТ, HWH, M8X1.25X35, 23.5 THD, 24 OD, 10.9, GMW3359, M-PT. (BRK PRESS MOD VLV BRKT)
|
2008-2008 |
03 |
|
| 009 |
15879119 |
BRACKET, BRK PRESS MOD VLV |
CK107 (06) (J92, X88, Z88) |
2008-2008 |
01 |
| 010 |
11609540 |
БОЛТ, HWASH, M6X1X20, 16.15 THD, 17 OD, 8.8, GMW4205, HDR PT. (BRK PRESS MOD VLV)
|
2008-2008 |
02 |
|
| 011 |
11561026 |
BOLT-HFH, M6X1X25, 22 THD, 14.2 OD, 9.8, GMW3200, MACH, HDR-PT (BRK PRESS MOD VLV BRKT BR) |
|
2008-2008 |
03 |
| 012 |
|
SLEEVE, BRK PRESS MOD VLV INSL (PART OF 7) |
|
2008-2008 |
|
| 013 |
|
INSULATOR, BRK PRESS MOD VLV (PART OF 7) |
|
2008-2008 |
|
| 014 |
|
PIPE, BRK PRESS MOD VLV FLUID TRFER (PART OF 19) |
|
2008-2008 |
|
| 015 |
|
SEAL, BRK PRESS MOD VLV FLTR (PART OF 19) |
|
2008-2008 |
|
| 016 |
25909777 |
MODULE, ELEK BRK CONT (ECU W/SEAL) |
CK107 (06) (J92) |
2008-2008 |
01 |
| 017 |
11570354 |
BOLT-HFH, M5X0.8X40, 16 THD, 11.4 OD, 8.8 , GMW3179-A. (ELEK BRK CONT MDL) |
|
2008-2008 |
04 |
| 018 |
11519038 |
BOLT-HFH, M6X1X30, 24 THD, 13.2 OD, 10.9, GMW3359, W/ADHESIVE ON THREADS (BRK PIPE MANIF)
|
2008-2008 |
04 |
|
| 019 |
25906823 |
MANIFOLD KIT, BRK PIPE (INCLS 14, 15, 20, 21) |
CK107 (06) (J92) |
2008-2008 |
01 |
| 020 |
|
FITTING, BRK PRESS MOD VLV PIPE (PART OF 1, 19) |
|
2008-2008 |
|
| 021 |
|
FITTING, BRK PRESS MOD VLV PIPE (PART OF 1, 19) |
|
2008-2008 |
|
| 022 |
25906827 |
SENSOR KIT, ELEK BRK CONT POSN (PART OF 1) (INCLS 23) |
CK107 (06) (J92) |
2008-2008 |
01 |
| 023 |
|
БОЛТ, ELEK BRK CONT POSN SEN (PART OF 1, 22) |
|
2008-2008 |
|
