| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
20927279 |
SUPPORT, RAD (INCLS 2-9) |
CK1 (06-36) (EXC UHT, VD1) |
2010-2013 |
01 |
| 001 |
20927280 |
SUPPORT, RAD (INCLS 2-9) |
K1 (06) (UHT) |
2011-2013 |
01 |
| 001 |
20927280 |
SUPPORT, RAD (INCLS 2-9) |
K1 (06) (VD1) (EXC UHT) (EXPORT) |
2011-2013 |
01 |
| 002 |
25870919 |
SUPPORT, F/END UPR TIE BAR (INCLS 3, 6) (PART OF 1) |
CK1 (06-36) |
2010-2013 |
01 |
| 003 |
11561407 |
NUT, INSERT , M6X1, 10MM HOLE, 1.7-5.25 PANEL, 19 LONG, 12.9 OD, 1008, GMW3 (PART OF 1, 2, 8) (8.921) |
|
2007-2013 |
46 |
| 004 |
11516932 |
BOLT, HEX HD, W/CON WA, M6X1X25, 9.8, 6138M (PART OF 1) |
|
2007-2013 |
06 |
| 005 |
11609989 |
BOLT, HEX W/FLAT WASHER, M6X1X25, 15 THD, 17 OD, 6202M STL, GMW3200, TAPTITE (PART OF 1, 8) |
|
2007-2013 |
02 |
| 006 |
11561916 |
NUT, INSERT, M8X1.25, 13.5 HOLE, 0.7-3.8 GRIP, 24 LONG, 17.4 OD, 1008, GMW (PART OF 1, 2) |
|
2007-2013 |
12 |
| 007 |
15744933 |
BOLT, HEX HD, W/CON WA, M6X1X45 (PART OF 1) (1.267) |
|
2007-2013 |
04 |
| 008 |
20968548 |
BRACE, F/END SH MET RAD OPG (INCLS 3, 5, 9) (PART OF 1) |
K1 (06) (UHT) |
2011-2013 |
01 |
| 008 |
20968548 |
BRACE, F/END SH MET RAD OPG (INCLS 3, 5, 9) (PART OF 1) |
K1 (06) (VD1) (EXC UHT) |
2011-2013 |
01 |
| 008 |
20968547 |
BRACE, F/END SH MET RAD OPG (INCLS 3, 5, 9) (PART OF 1) |
CK1 (06-36) (EXC UHT, VD1) |
2010-2013 |
01 |
| 009 |
25870918 |
BRACE, F/END SH MET CR (PART OF 1, 8) |
CK1, 2 (06) |
2007-2013 |
01 |
