| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
|
HARNESS, RF WRG (СМ. ГРУППУ 2.000 ЖГУТ ПРОВОДОВ/КРЫША FOR DETAILED ILLUSTRATED VIEW) |
|
2007-2009 |
|
| 002 |
|
HARNESS, I/P WRG (СМ. ГРУППУ 02.000 ЖГУТ ПРОВОДОВ/ПАНЕЛЬ ПРИБОРОВ FOR DETAILED ILLUSTRATED VIEW) |
|
2007-2009 |
|
| 003 |
15220450 |
CABLE, RDO ANT CBL EXTN RDO END (1250 MM) (ACDelco #15220450) |
CK1, 2 (U84, X88, Z88) |
2007-2009 |
01 |
| 004 |
15127940 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (WV9) (EXC D07, UE1) |
2007-2007 |
01 |
| 004 |
15127940 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1 (06-36-43) (STZ, US8, US9, UVA, UVB) (EXC UBS, UE1, U2K, Y91) |
2007-2009 |
01 |
| 004 |
15127940 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UQ3, US8, US9) (EXC STZ, UBS, UE1, U2K, UK6, U42, Y91) |
2007-2009 |
01 |
| 004 |
15127940 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (YQ3) (EXC UE1) |
2007-2009 |
01 |
| 004 |
15824078 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) (INFOTAINMENT) |
CK1, 2 (06-36) (UE1, UQA, UVA, U42) (EXC U2K, Y91) |
2007-2007 |
01 |
| 004 |
15824078 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) (INFOTAINMENT) |
CK1, 2 (06-36) (UE1, UQA, UVA, U42) (EXC UVC, U2K, Y91) |
2007-2007 |
01 |
| 004 |
15824078 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) (INFOTAINMENT) |
CK1, 2 (06-36) (UE1, UQA, UVB, U42) (EXC U2K, Y91) |
2007-2007 |
01 |
| 004 |
15824078 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) (INFOTAINMENT) |
CK1, 2 (06-36) (UE1, UQA, UVB, U42) (EXC UVC, U2K, Y91) |
2007-2007 |
01 |
| 004 |
15824078 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) (INFOTAINMENT) |
CK1, 2 (06-36) (UE1, UQA, UVB, UVC, U42) (EXC U2K, Y91) |
2007-2007 |
01 |
| 004 |
15824082 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UQA, UVA, U2K, U42) (EXC UVC, Y91, UE1) |
2007-2007 |
01 |
| 004 |
15824082 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UQA, UVA, UVB, U2K, U42) (EXC UE1, Y91) |
2007-2007 |
01 |
| 004 |
15824082 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UQA, UVB, U2K, U42) (EXC Y91, UVC, UE1) |
2007-2007 |
01 |
| 004 |
15824082 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UQA, UVB, UVC, U2K, U42) (EXC Y91, UE1) |
2007-2007 |
01 |
| 004 |
15857139 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UK6, UQ3, US8, US9, U2K) (EXC UE1, U42, Y91) |
2007-2007 |
01 |
| 004 |
15857142 |
HARNESS, I/P WRG HARN EXTN (INFOTAINMENT) (INCLS 5) |
CK1, 2 (06-36) (UQ3, US8, US9, UK6) (EXC UE1, U42, Y91, U2K) |
2007-2007 |
01 |
| 004 |
15859187 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UQ3, US8, US9, U2K) (EXC UE1, UK6, U42, Y91) |
2007-2007 |
01 |
| 004 |
15859189 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UQA, U2K, U3U) (EXC UE1, U42, Y91) |
2007-2007 |
01 |
| 004 |
15859189 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UQA, US8, US9, UVA, U2K) (EXC UE1, UVC, U42, Y91) |
2007-2007 |
01 |
| 004 |
25788646 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06) (D07, WV9) (EXC UE1) |
2007-2007 |
01 |
| 004 |
25788647 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06) (D07, UE1, WV9) |
2007-2007 |
01 |
| 004 |
25797135 |
HARNESS, I/P WRG HARN EXTN (INFOTAINMENT) (INCLS 5) |
CK1, 2 (06-36) (UE1, UK6, UQ3, US8, US9) (EXC U2K, U42, Y91) |
2007-2007 |
01 |
| 004 |
25797137 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UE1, UK6, UQ3, US8, US9, U2K) (EXC U42, Y91) |
2007-2007 |
01 |
| 004 |
25797141 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UQA, UVB, U42) (EXC UE1, U2K, Y91) |
2007-2007 |
01 |
| 004 |
25797141 |
HARNESS, I/P WRG HARN EXTN (INFOTAINMENT) (INCLS 5) |
CK1, 2 (06-36) (UQA, UVA, U42) (EXC UE1, UVC, U2K, Y91) |
2007-2007 |
01 |
| 004 |
25797141 |
HARNESS, I/P WRG HARN EXTN (INFOTAINMENT) (INCLS 5) |
CK1, 2 (06-36) (UQA, UVB, U42) (EXC UE1, UVC, U2K, Y91) |
2007-2007 |
01 |
| 004 |
25797141 |
HARNESS, I/P WRG HARN EXTN (INFOTAINMENT) (INCLS 5) |
CK1, 2 (06-36) (UQA, UVB, U42, UVA) (EXC UE1, U2K, Y91) |
2007-2007 |
01 |
| 004 |
25797141 |
HARNESS, I/P WRG HARN EXTN (INFOTAINMENT) (INCLS 5) |
CK1, 2 (06-36) (UQA, UVB, UVC, U42) (EXC UE1, U2K, Y91) |
2007-2007 |
01 |
| 004 |
25797142 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UQA, U3U) (EXC UE1, U2K, U42, Y91) |
2007-2007 |
01 |
| 004 |
25797142 |
HARNESS, I/P WRG HARN EXTN (INFOTAINMENT) (INCLS 5) |
CK1, 2 (06-36) (UQA, US8, US9, UVA) (EXC UE1, UVC, U2K, U42, Y91) |
2007-2007 |
01 |
| 004 |
25797144 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UE1, UQA, U2K, U3U) (EXC U42, Y91) |
2007-2007 |
01 |
| 004 |
25797144 |
HARNESS, I/P WRG HARN EXTN (INFOTAINMENT) (INCLS 5) |
CK1, 2 (06-36) (UE1, UQA, U2K, U3U) (EXC UVC, U42, Y91) |
2007-2007 |
01 |
| 004 |
25797144 |
HARNESS, I/P WRG HARN EXTN (INFOTAINMENT) (INCLS 5) |
CK1, 2 (06-36) (UE1, UQA, US8, US9, UVA, U2K) (EXC UVC, U42, Y91) |
2007-2007 |
01 |
| 004 |
25797144 |
HARNESS, I/P WRG HARN EXTN (INFOTAINMENT) (INCLS 5) |
CK1, 2 (06-36) (UE1, UQA, UVC, U2K, U3U) (EXC U42, Y91) |
2007-2007 |
01 |
| 004 |
25797147 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UE1, UQA, U3U) (EXC U2K, U42, Y91, UVC) |
2007-2007 |
01 |
| 004 |
25797147 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UE1, UQA, U3U, US8, US9, UVA) (EXC U2K, Y91, U42) |
2007-2007 |
01 |
| 004 |
25797147 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UE1, UQA, US8, US9, UVA) (EXC UVC, U2K, U42, Y91) |
2007-2007 |
01 |
| 004 |
25797147 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UE1, UQA, UVC, U3U) (EXC U2K, U42, Y91) |
2007-2007 |
01 |
| 004 |
25797148 |
HARNESS, I/P WRG HARN EXTN (INFOTAINMENT) (INCLS 5) |
CK1, 2 (06-36) (UE1, UQ3, US8, US9, U2K) (EXC UK6, U42, Y91) |
2007-2007 |
01 |
| 004 |
25797149 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UE1, UQ3, US8, US9) (EXC UK6, U2K, U42, Y91, WV9) |
2007-2007 |
01 |
| 004 |
25797149 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UE1, WV9) (EXC D07) |
2007-2007 |
01 |
| 004 |
25797150 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UE1, UQA, UVA, U2K, U42) (EXC UVC, Y91) |
2007-2007 |
01 |
| 004 |
25797150 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UE1, UQA, UVB, U2K, U42) (EXC Y91, UVC) |
2007-2007 |
01 |
| 004 |
25797150 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UE1, UQA, UVB, UVC, U2K, U42) (EXC Y91) |
2007-2007 |
01 |
| 004 |
25797150 |
HARNESS, I/P WRG HARN EXTN (INCLS 5) |
CK1, 2 (06-36) (UQA, UVA, UVB, U2K, U42, UE1) (EXC Y91) |
2007-2007 |
01 |
| 005 |
19115815 |
CABLE, DIGITAL RDO АНТЕННА (PART OF 4) (IN I/P WRG EXTN) (ACDelco #19115815) |
CK1, 2 (06-36) (U2K) (EXC UE1, Y91) |
2007-2007 |
01 |
| 005 |
19115816 |
CABLE, M/TEL NAVN ANT COAX (PART OF 4) (IN I/P WRG EXTN) (ACDelco #19115816) |
CK1, 2 (06-36) (UE1) (EXC U2K, Y91) |
2007-2007 |
01 |
| 005 |
19115816 |
CABLE, M/TEL NAVN ANT COAX (PART OF 4) (IN I/P WRG EXTN) (ACDelco #19115816) |
CK1, 2 (06-36) (UE1, WV9) (EXC D07) |
2007-2007 |
01 |
| 005 |
19115817 |
CABLE, RDO MOBILE TEL NAVIGATION ANT (PART OF 4) (IN I/P WRG EXTN) (ACDelco #19115817) |
CK1, 2 (06-36) (UE1, U2K) (EXC Y91) |
2007-2007 |
01 |
| 006 |
|
RECEIVER, DIGITAL RDO (СМ. ГРУППУ 9.000 АНТЕННА/ЦИФРОВАЯ АУДИОСИСТЕМА FOR DETAILED ILLUSTRATED VIEW) |
|
2007-2009 |
|
| 007 |
|
HARNESS, BODY WRG (СМ. ГРУППУ 02.000 ЖГУТ ПРОВОДОВ/КУЗОВ FOR DETAILED ILLUSTRATED VIEW) (2.483) |
|
2007-2009 |
|
| 008 |
|
MODULE, COMN INTERFACE (W/MOBILE TEL XCVR) (СМ. ГРУППУ 9.000 СИСТЕМА СВЯЗИ FOR DETAILED ILLUSTRATED VIEW) (2.480) |
|
2007-2009 |
|
| 009 |
|
BLOCK, BODY WRG HARN JUNC (СМ. ГРУППУ 02.000 БЛОК-I/P MID BLOCK FOR DETAILED ILLUSTRATED VIEW) |
|
2007-2009 |
|
| 010 |
|
HARNESS, RF ACSRY WRG (СМ. ГРУППУ 16.000 ВНУТРЕННЯЯ ОТДЕЛКА - КРЫША FOR DETAILED ILLUSTRATED VIEW) |
|
2007-2009 |
|
