| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
88891577 |
CASE, AUX A/C EVPR BLO UPR (INCLS LEFT/RIGHT CASES W/ DOORS)
| CK157 (06) (CJ2, CJ3, C36, C69) |
2003-2006 |
01 |
|
| 002 |
12475857 |
MOTOR, AUX BLO (IMPLR) (ACDelco #15-8791)
| CK157 (06) |
2003-2006 |
01 |
|
| 003 |
19167663 |
БОЛТ, AUX A/C EVPR BLO CASE (M4.8X1.59, 10, 51 OD) |
CK157 (06) |
2003-2006 |
AR |
| 004 |
12472431 |
CLIP, AUX A/C EVPR BLO MDL CVR |
CK157 (06) |
2003-2006 |
17 |
| 005 |
12477713 |
EVAPORATOR, AUX A/C (INCLS 18-21) (INCL EXPAND VALVE) (ACDelco #15-62105) |
CK157 (06) |
2003-2006 |
01 |
| 006 |
12477710 |
CASE, AUX A/C EVPR BLO LWR |
CK157 (06) |
2003-2006 |
01 |
| 007 |
19180862 |
STUD, A/C EVPR BLO MDL (USE T/W ADHESIVE 89021297) |
CK157 (06) |
2003-2006 |
02 |
| 008 |
89040368 |
SEAL KIT, HTR BLO MDL A/C EVPR DRN TUBE (INCLS 9) (ACDelco #15-31164) |
CK157 (06) |
2003-2006 |
01 |
| 009 |
|
SEAL, A/C EVPR CASE DRN TUBE (PART OF 8) |
|
2003-2006 |
|
| 010 |
89024926 |
MODULE, AUX HTR A/C CONT (LABELED VENDER P/N Z940GR03A03) (FOR 1ST DES SEE 93803634) (ACDelco #15-73535) |
CK157 (06) (CJ2, C36, C69) |
2006-2006 |
01 |
| 010 |
93803634 |
MODULE, AUX HTR A/C CONT (LABELED VENDER P/N Z940GR03A02) (FOR 2ND DES SEE 89024926) (ACDelco #15-80568)
| CK157 (06) (CJ2, C36, C69) |
2006-2006 |
01 |
|
| 011 |
89024919 |
CORE, AUX HTR (ACDelco #15-62104) |
CK157 (06) |
2003-2006 |
01 |
| 012 |
12477715 |
COVER, AUX HTR (HEATER CORE) |
CK157 (06) |
2003-2006 |
01 |
| 013 |
89022558 |
HARNESS, AUX HTR A/C WRG |
CK157 (06) (CJ2, C36, C69) |
2003-2006 |
01 |
| 014 |
11609461 |
БОЛТ, HX W/FL WA, M4.2X1.41X16, 9 THD, 12.5 OD, 6010M STL, GMW4205, SELFTA (AUX HTR A/C CONT MDL)
|
2003-2006 |
02 |
|
| 015 |
15832319 |
MODULE, AUX HTR A/C CONT (MTG ON RR AUX HVAC MDL) (ACDelco #15-73506)
| CK1, 2 (06) (CJ2, C36, C69) |
2003-2006 |
01 |
|
| 016 |
89018375 |
ACTUATOR, TEMP VLV (AUX) (ACDelco #15-72972)
| CK157 (06) (CJ2, C36, C69) |
2003-2006 |
02 |
|
| 017 |
15650071 |
VALVE, AUX A/C EVPR BLO MDL DRN (ACDelco #15650071) |
CK157 (06) (C69) |
2003-2006 |
01 |
| 018 |
89022575 |
VALVE, AUX A/C EVPR THERMAL EXPN (PART OF 5) (INCLS 20, 21) (ACDelco #15-50171) |
CK157 (06) |
2003-2006 |
01 |
| 019 |
19130022 |
SEAL, A/C EVPR TXV (O RING) (5/16 INCH) (PART OF 5) (ACDelco #15-33772) |
CK157 (06) |
2003-2006 |
01 |
| 020 |
89022576 |
FILTER, A/C EVPR AIR (AUX) (PART OF 5, 18) (ACDelco #15-63060)
| CK157 (06) |
2003-2006 |
01 |
|
| 021 |
19130023 |
SEAL, A/C EVPR TXV (O RING) (1/2 INCH) (PART OF 5) (ACDelco #15-33773) |
CK157 (06) |
2003-2006 |
01 |
