| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
09596050 |
WHEEL, 17X7.5 |
CK1 (P46) |
2007-2008 |
04 |
| 002 |
19209740 |
WEIGHT, WHL BAL (CLIP-ON REPLACEMENT) (TRIM AS REQUIRED) (WHL BAL) |
|
2007-2008 |
AR |
| 003 |
19212925 |
ГАЙКА, WHL (SERV CMP OF NUT PKGS) (5.813) (PREFERRED USE ON WHLS W/EXPOSED LUGS W/O NEED TO RETAIN A WHL CAP/COVER) |
CK1 |
2007-2008 |
20 |
| 004 |
09595469 |
CAP, HUB (INCLS 5) |
CK1 (N56, N93, P46) |
2007-2008 |
04 |
| 005 |
12472839 |
CAP, WHL NUT (PART OF 4) (BLACK) (PLASTIC)
| CK1 (N56, N93, P46, X88) |
2007-2008 |
24 |
|
| 006 |
|
CAP, ШИНА VLV STEM (PART OF 7) |
|
2007-2007 |
|
| 007 |
|
STEM, ШИНА VLV (СМ. ГРУППУ 05.000 ШТОК КЛАПАНА ШИНЫ И ДАТЧИК ДАВЛЕНИЯ В ШИНЕ FOR DETAILED ILLUSTRATED VIEW) |
|
2007-2008 |
|
| 007 |
|
ДАТЧИК, ШИНА PRESS IND (INCLS 6) (СМ. ГРУППУ 05.000 ШТОК КЛАПАНА ШИНЫ И ДАТЧИК ДАВЛЕНИЯ В ШИНЕ FOR DETAILED ILLUSTRATED VIEW) |
|
2007-2008 |
|
| 008 |
09595453 |
WHEEL, 17X7.5 |
CK1 (N93) |
2007-2008 |
04 |
| 009 |
09595246 |
WHEEL, 17X7.5 (CODE UTX) (STEEL) (ACDelco #9595246) |
CK1 (NX7) |
2007-2008 |
04 |
| 010 |
09596667 |
CAP, HUB (INCLS 11) (PAINTED) |
CK1 (NX7, X88) (EXC P03) |
2007-2008 |
04 |
| 011 |
15045768 |
CAP, WHL NUT (PART OF 10) (CHROME) (M27X2) (5.813) (SERV CMP OF CAP PKGS 12499427-48) |
CK1 (X88, Z88) (EXC HP2, PPV) |
2007-2008 |
24 |
| 012 |
09596468 |
WHEEL, 17X7.5 (CODE BFM) (ACDelco #9596468) |
C1 (QV9) |
2007-2008 |
04 |
| 013 |
09596070 |
ГАЙКА, WHL (M14X1.5) (SS CAP) (TOTAL LENGTH 20.22MM)
| CK1 (QF8, QV9, RDP) |
2007-2008 |
24 |
|
| 013 |
19212925 |
ГАЙКА, WHL (SERV CMP OF NUT PKGS) (5.813) (PREFERRED USE ON WHLS W/EXPOSED LUGS W/O NEED TO RETAIN A WHL CAP/COVER) |
CK1 |
2007-2008 |
20 |
| 014 |
09597673 |
CAP, HUB (INCLS SPACER RETAINERS) |
C1 (QV9) |
2007-2008 |
04 |
| 015 |
11515756 |
БОЛТ, HFH, M8X1.25X20, 17THD, 18 O.D., 10.9, 7114M (HUB CAP)
|
2007-2008 |
03 |
|
| 016 |
09595987 |
WHEEL, 18X8 |
CK1 (N87, X88) |
2007-2007 |
04 |
| 017 |
09595174 |
ГАЙКА, WHL (M14X1.5)
| CK1 (N87, PD5, PW2, P41, P56, P58, RCP, RCS) |
2007-2007 |
24 |
|
| 017 |
19212925 |
ГАЙКА, WHL (SERV CMP OF NUT PKGS) (5.813) (PREFERRED USE ON WHLS W/EXPOSED LUGS W/O NEED TO RETAIN A WHL CAP/COVER) |
CK1 |
2007-2008 |
20 |
| 018 |
09597991 |
CAP, HUB |
CK1 (N87, P58) |
2007-2008 |
04 |
| 019 |
09597195 |
WHEEL, 20X8.5 |
CK1 (RCS) |
2007-2008 |
04 |
| 019 |
09597680 |
WHEEL, 20X8.5 |
CK1 (RCP) |
2007-2008 |
04 |
| 020 |
09596007 |
CAP, HUB
| CK1 (RCS) |
2007-2008 |
04 |
|
| 020 |
09597681 |
CAP, HUB
| CK1 (RCP) |
2007-2008 |
04 |
|
